Chapter 1-2
quick introduction to some of the features you have access to in your new chart
sounder. The display examples shown in this manual are not always an exact
copy of what you will see on the screen, as the presentation depends on your
system configuration and choices of setup.
How to interpret special marked key symbols etc. in the manual:
Either the + (plus) or - (minus) key may be applied.
+/-
Alpha-numeric keys for insertion of figures.
0-9
Alpha-numeric keys for insertion of letters.
A-Z
Emphasizes important points.
Indicates that you should press the keys [1] and [3] to obtain what is
1,3
written in italic next to the key.

1.2 Safety summary

Precaution: Do not open the equipment, only qualified persons should work
inside the equipment. If the glass in the screen breaks, be carefull not to get cut
on the sharp edges of the glass pieces.
The lifetime of the internal battery is minimum 5 years. If not exchanged
before it goes flat, all data in the unit's memory will be lost. We strongly
recommend that you frequently store your data on a Simrad DataCard. For
exchange of battery, call your local Simrad workshop.
Power source, fuse and power cable: Check that the DC power supplied to the
unit is within the range of 10 to 32 volts. Note that the appropriate fuse must
be employed (see the fuse rating in section 9.4 Specifications). Ensure that the
power cord is firmly attached.
Grounding: To reduce electrical interference and risk of electrical shock, prop-
erly ground the unit to the ship's ground using the ground screw at the rear of the
unit. Good grounding should also be exercised for connected equipment, refer to
separate Installation manual.
Cleaning: Do not use any kind of strong solvents e.g. spirit, alcohol, gasoline or oils.
Software: The software version of the main unit (see start-up display) should
always be informed in a service situation, or when ordering a Dual Station.
CE34/44/54 Introduction and safety summary
