CE34/44/54 Chart menu and INFO windows

3.4.9 PLOT menu

The CEXX is designed to make navigation easy and safe. Waypoints
can easily be plotted with a single keystroke, or be inserted via the
keypad. Making routes and drawing lines are done directly on the
chart. Very straightforward, uncomplicated and with a high level of
confidence as you can follow your actions 'live' on the chart.
Call up the PLOT menu with the following to choose from:
PLOT
PLOT
1
2
3
4
5
6
7
8
9
MENU
From any display: Plot and save mark on ship's position, including
PLOT
actual depth indication. Preset name sequence: SHIP 1, SHIP 2 etc.
From any display: Plot and save waypoint. Ship's position is sug-
1
gested, but you can key in a new position from keypad, change the
location name (cf.section 2.6), or change the symbol (cf.section 2.5)
and the color (select with +/- keys). Any changes made will be new
presets for plotting/insertion of ship's position.
From active chart display with cursor on: Plot and save cursor posi-
2
tion as a waypoint. Preset name sequence: WP 1, WP 2 etc.
From any display: Plot and save waypoint. The position coordinates
3
are filled with zeroes, so you can key in the position you want from
PLOT new data
Plot mark - ship
Insert mark - ship
Plot waypoint - cursor
Insert waypoint
Make route
Draw line
Plot target
Start track
Stop track
Set vertical mark
Exit
Chapter 3-15
