Chapter 4-6
the expansion window can be adjusted in the Setup display.
Zoom display This feature will provide an expanded view of the
5
area near the *Variable Range Marker which will give a better sepa-
ration of echoes. The actual range of the expansion window can be
adjusted in the Setup display.
*) see section 4.4.
Shift display This feature can be applied when operating in deep
6
waters. Select the range for an expansion window. The expansion
window can automatically follow a changing bottom or be set manu-
ally by the +/- keys.
Transmit power off Stop transmission in order to observe noise
ECHO
picked up by the transducer.
Abandon the Echo quick menu without making any changes
MENU

4.6 Plot waypoint or event mark via PLOT menu

From active echo display:
Call up the PLOT menu with the following to choose from:
PLOT
Set vertical mark will plot a vertical marker (line) at the current
9
ping.
- or you can plot the position of a given echo on the chart:
Insert waypoint will activate a cursor on the echo display
3
Move cursor to the echo which position you wish to place as a way-
point
Press [ENT] to register the waypoint on the echo display
ENT
A new info window will open where you can change the name of the
waypoint, adjust the position if necessary, change symbol and color
of the waypoint. When satisfied with the information in the info
window:
Press [ENT] to save waypoint
ENT
CE34/44/54 Echo menu
