Chapter 9-2
Symptom
Excessive noise in echo
All data is deleted after
turning off the unit and
turning it back on

9.2 Preventive maintenance

Surface cleaning – to keep the CEXX cabinet and display screen clean, wipe
the surfaces with a clean damp cloth. For heavier cleaning, use a clean, damp
cloth which has been dipped in a solution of a mild dish detergent and water.
Wring out firmly before wiping the unit.
Never use cleaning solutions containing spirit, alcohol, gasoline or oils.
Electrical connections – periodically check the electrical connections. Make
sure that connections are tight and that no cables are frayed or worn.
Transducer - periodically clean the face of the transducer with a plastic uten-
sil using a scrubbing action.
Do not use a harsh abrasive or a solvent to clean the transducer.

9.3 Repair and service

The CEXX is sealed and does not contain any user serviceable parts. Opening
of this unit will void its warranty. If the CEXX requires servicing or repair,
call your authorized SIMRAD dealer, but first check Troubleshooting in sec-
tion 9.1.
Spare parts – fuses may be bought from a chandler or a marine supply store.
Use only fuses specified for this unit – see 9.4 Specifications.
If you require a SIMRAD part, please contact your authorized dealer.
CE34/44/54 Troubleshooting, Service and Specifications
Check
Check for correct ground-
ing
Check battery lifetime.
Expected lifetime is min.
5 years
Remedy
Connected equip-
ment must be properly
grounded to the main unit
Internal battery must be
replaced by authorized
dealer
