  • Page 1 MANUAL IS20 Graphic Multifunction instrument 20222576 / A Sw.1.1 English...

  • Page 2: About This Manual

    © 2007 by Navico Egersund AS About this manual This manual is a reference guide for installing and operating the Simrad IS20 Graphic instrument. The manual does not include operator or installation procedures for sensors that can be connected to the system.

  • Page 3: Table Of Contents

    1.2 Instrument layout ........7 1.3 IS20 system examples......8 2 Basic operation ......... 11 2.1 Turning the IS20 on ....... 11 2.2 Backlighting .......... 12 2.3 Scrolling through data pages ....13 2.4 Resetting a data page ......14 2.5 Operating the menu system.....
  • Page 4 5.5 Changing the display settings ....39 5.6 Language selection......... 41 5.7 Changing the units of measure....42 6 IS20 Alarm system ........43 6.1 Alarm indication........43 6.2 Acknowledging an alarm ......44 6.3 Viewing active alarms ......44 6.4 Alarm codes ..........
  • Page 5 10.1 Spares and auxiliaries ......73 10.2 SimNet cables and accessories ....74 11 Specifications ......... 75 11.1 Technical specifications ......75 11.2 Dimensional drawing......76 11.3 Menu flow chart ........77 11.4 Data groups and data items ....78 IS20 Graphic instrument | 5...
  • Page 6 Blank page 6 | IS20 Graphic instrument...

  • Page 7: Introduction

    A race timer is also included in the IS20. 1.2 Instrument layout The IS20 has a 130 * 104 pixels LCD. The display may be set to red or white illumination color, and the contrast and light level are adjustable.

  • Page 8: Is20 System Examples

    The following general softkey symbols are used: Cancel 1.3 IS20 system examples The IS20 may be installed as a stand-alone instrument system, or as part of an advanced instrument or steering system on the boat. The figures below show simplified illustrations for basic and an expanded IS20 system.
  • Page 9 IS20 Graphic, Basic system IS20 Graphic, Basic system with 2 sensors Introduction | 9...
  • Page 10 IS20 Expanded system 10 | Introduction...

  • Page 11: Basic Operation

    2.1 Turning the IS20 on IS20 has no power key, and will be running as long as power is connected. The IS20 includes a power save function. Refer page 19.

  • Page 12: Backlighting

    2.2 Backlighting The display backlight may be adjusted at any time. Press the light key − The Light level overlay window will be displayed on top of the current view Press one of the keys as described below to change the display illumination: a The Light key to increase the light level by one step b The Up/Down softkeys to increase/decrease...

  • Page 13: Scrolling Through Data

    2.3 Scrolling through data pages The IS20 Graphic is pre-configured with 8 instrument pages, of which 2 are disabled. The instrument will scroll through the pages by using the Up and Down keys. Default page at first time turn-on Note that the pages shown with a...

  • Page 14: Resetting A Data Page

    Pressing the Right key will have no effect if the active data page not includes any calculated data! 2.5 Operating the menu system All functions and settings in the IS20 are available from the menu system, activated by pressing the Menu/Enter key. The main menu items give further access to sub menus and various settings.
  • Page 15 Use the keys as shown below to navigate in the menu system: Single press Press and hold Confirm a selection/parameter setting Go to next menu level/ parameter settings Return to normal operation Go to previous menu level/ and the last active data parameter listing page Go to previous/next menu item,...
  • Page 16 The illustration below shows how to change the display contrast from 9 to 6. Press and holding the Left key will always return the display to normal operation and the last active page! 16 | Basic operation...

  • Page 17: Disabling/Enabling Data

    Menu illustrations In this manual, the first steps in a menu operation are illustrated by overlapping menu windows. When more detailed illustrations are required to show key presses and screens, this is shown as below: 2.6 Disabling/enabling data pages By disabling a data page, the number of pages will be reduced when scrolling through the data pages.
  • Page 18 Disabling pages Continue to select pages and repeat the procedure if more pages are to be disabled. Enabling a page Continue to select pages and repeat the procedure if other pages are to be enabled. 18 | Basic operation...

  • Page 19: Locking And Unlocking The Keys

    2.7 Locking and unlocking the keys The IS20 keys may be locked to prevent any unintended operation. The key lock function is enabled by pressing the Menu/Enter and the Light keys simultaneously. A locked instrument has a padlock symbol in the upper left...
  • Page 20 Blank page 20 | Basic operation...

  • Page 21: Advanced Operation

    The advanced features described in this section are not required for basic operation of the instrument.! 3.1 Customizing the data pages IS20 Graphic may display 8 pages. These are pre- configured from factory, but they are all user configurable. The number of pages may be reduced by disabling one or more pages.
  • Page 22 4 windows/ 4 windows/ horizontally square Changing the page layout All data pages are user configurable. The illustration below shows how a 4-window page is configured. Press and hold the Left key to leave the menu and return to normal operation when all windows are defined. For a list of all available data groups and data items, refer to Data groups and data items, page 78 onwards.

  • Page 23: Remote Operation

    Restoring factory default pages All user defined data pages may be restored to factory default layout and content. Use the keys to confirm or cancel and return to the menu. 3.2 Remote operation This function is for future use. 3.3 SimNet group function The SimNet group function provides global control of groups of units.
  • Page 24 Simrad Damping Simrad, None, 1-6 Simrad Alarm Simrad, None, 1-6 Simrad − Simrad: Default group for IS20 − None: Not assigned to a group − 1 – 6: Group numbers The figures on next page illustrates how the instruments on a flybridge and in a cockpit are assigned to separate language-, damping- and display groups, and how this affects the setup for the different instruments.
  • Page 25 LANGUAGE = FLYBRIDGE NONE BACKLIGHT = 1 DAMPING = 1 COCKPIT BACKLIGHT = 2 Advanced operation | 25 Advanced operation | 25...

  • Page 26: Demo Mode

    Changing the SimNet group setup The SimNet groups are normally configured during installation, but may be changed at any time. 3.4 Demo mode The IS20 includes a demo mode useful for demonstrations and on show. Active demo mode is indicated with flashing DEMO text in the upper right corner of the page.

  • Page 27: The Log/Timer Functions

    4 The log/timer functions 4.1 The timer function The timer function is used to measure time and distance after a race start. When a timer page is displayed, basic key operation is replaced by functions indicated by softkeys. The softkey functions are further described in the following pages.

  • Page 28: Starting The Race Timer

    Starting the race timer The race timer will continue to run until the Stop soft key is pressed even if the race timer page is replaced by another page! When the counter turns zero, the race log starts to log the distance, the Synchronize soft key is removed and the timer function will work as a race timer!
  • Page 29 Resetting the timer A stopped or paused timer is reset to the pre-set countdown time by pressing the Reset soft key. Synchronizing the timer The countdown timer may be synchronized to the nearest whole minute at any time by pressing the Sync soft key. The synchronize soft key will not appear if the counter has turned zero! Freezing the display...

  • Page 30: Trip Logging

    4.2 Trip logging The trip log display shows: − total accumulated distance since the instrument was installed or factory reset − distance and time since the trip log was started/reset Resetting the trip log The trip log is reset to zero by pressing the Reset soft key.

  • Page 31: Setting The Time Offset

    4.4 Setting the time offset The time function in IS20 is only available when a GPS is connected to the system. The GPS runs on UTC time, and can be adjusted to show local time by entering a UPC offset value.
  • Page 32 Blank page 32 | The log/timer function...

  • Page 33: Changing The Default Settings

    5 Changing the default settings 5.1 General The factory default settings may all be changed from the Setup command in the Main menu. Updating the settings will affect all instruments in the SimNet group. Refer to SimNet group function, page 5.2 Setting the damping factors The damping factors indicate how fast the display will respond to changes.

  • Page 34: Alarm Setup

    5.3 Alarm setup The IS20 may be set up to sound an alarm if vessel or environmental parameters exceeds preferred values. The alarm monitoring is disabled by setting the value to Off. Boat speed alarm Used to give alarm if the boat speed goes beyond a selected value.
  • Page 35 Depth alarm The depth alarm can be set up for deep and shallow water limits. An anchor alarm can be activated to warn if the boat is drifting. The alarm will sound when during a 40 seconds time period there is a change in depth of 2-3 meters (6 –...
  • Page 36 Wind alarm The wind alarm can be set for high and low wind speeds. The wind shift alarm will monitor the wind angle. The reference angle is set when the alarm is turned on, and reset to present wind angle when an alarm is acknowledged.

  • Page 37: Updating The Data Sources

    The Auto select option will look for all sources connected to the instrument system. If more than one source is available for each item, the IS20 will automatically select from an internal SimNet priority list. 1. Verify that all interfaced units are powered on 2.
  • Page 38 Manual source selection If more than one source is available for each item, the preferred source may be selected manually. As an example, the following illustrations show how the compass source is changed. Select the preferred data source and confirm with the OK soft key.

  • Page 39: Changing The Display Settings

    5.5 Changing the display settings To optimize the readability under different light conditions, the display is controlled by 4 settings: − Display contrast − Display background − Light color − Light level Display background and light are grouped in Day and Night profile settings, making it possible to quickly switch between these settings by using the Light key.
  • Page 40 Day and night profiles The day and night settings control the display background, the light color and light level for the display and the keys. Change Default Setting Range per step value Light level 9 – Off White (Day) Light color White / Red Red (Night) Invert display...

  • Page 41: Language Selection

    5.6 Language selection The language is set when the instrument is turned on for the first time. Refer First time start-up, page 57. It is however possible to change the language at any time. The following languages may be selected: −...

  • Page 42: Changing The Units Of Measure

    5.7 Changing the units of measure Parameter Options Default − kn Boat speed − km/h − mph − kn Wind speed − m/s − mph − nm Distance − mi − km − m Depth − ft − °M Heading °M −...

  • Page 43: Is20 Alarm System

    6 IS20 Alarm system 6.1 Alarm indication The alarm system in IS20 Graphic is activated if any alarm settings are exceeded. Refer to Alarm setup, page 34. When an alarm is notified, the alarm will be indicated with an alarm text and with an audible alarm.

  • Page 44: Acknowledging An Alarm

    If the alarm is received from other units connected to SimNet, the alarm text may not be displayed. The alarm condition will then be indicated with a code. A description for available codes are listed in the table on next page. 44 | IS20 Alarm system...
  • Page 45 Rudder feedback data missing Rudder feedback failure Rudder response failure Rudder drive overload High temperature Bypass/clutch overload Bypass/clutch disengaged High drive supply Low drive supply Autopilot control communication failure Autopilot function communication failure Non volatile memory failure IS20 Alarm system | 45...
  • Page 46 Blank page 46 | IS20 Alarm system...

  • Page 47: Installation

    7 Installation 7.1 Location of the unit The IS20 should be mounted with special regard to the unit’s environmental protection, temperature range and cable length. Refer page 75. Avoid mounting the control unit(s) where it is easily exposed to sunlight, as this may shorten the lifetime of the display.

  • Page 48: Bracket Mounting

    Bracket mounting An optional bracket is available for the IS20. The illustration below shows the mounting details for the bracket. 48 | Installation...

  • Page 49: Cable Connection

    7.3 Cable connection The IS20 may be connected to: − a SimNet network using SimNet cables − an NMEA2000 system − an NMEA0183 output port SimNet/ SimNet/ NMEA2000 NMEA2000 NMEA0183 In SimNet The SimNet cable system with very small plugs in both ends makes it easy to run the cables.
  • Page 50 51, 52 and 53 SimNet must be properly terminated, i.e. unless it is a small system (see the figure on page 51) there must be terminations at each end of the Simrad backbone The SimNet network has to be terminated according to the number and type of products connected.
  • Page 51 SimNet network, small system Installation | 51...
  • Page 52 SimNet network, medium system 52 | Installation...
  • Page 53 SimNet network, expanded system Installation | 53...
  • Page 54 3. Equipment should not be daisy-chained in a drop cable. 4. The wind transducer (*) has a built in terminator. Connecting IS20 to an NMEA2000 network No daisy-chain connection is permitted between SimNet units when connected to an NMEA2000 network! Use the SimNet cable (part no 24005729) to connect the IS20 to an MNEA2000 network.
  • Page 55 Connecting IS20 to an NMEA0183 output unit The IS20 instrument may be used as repeater for data from a device with an NMEA0183 output port (NMEA “talker”). Use a repeater that is dedicated for the type of data you want to present and the way you want it presented, i.e.
  • Page 56 Blank page 56 | Installation...

  • Page 57: Configuration

    8 Configuration 8.1 First time start-up When the IS20 is powered on for the first time, the instrument will run through an automatic start-up sequence presenting: − Product name, software version, release date − Language selection − Automatic data source selection Press the Menu/Enter key when the start-up procedure is completed.

  • Page 58: Calibration

    8.2 Calibration After installation, certain functions in the system must be calibrated to adapt to the physical position and type of sensors installed. All calibration is initiated from the CALIBRATION sub menu. Boat speed The hull shape or the location of the speed sensor may cause incorrect speed readings, and calibration is required to ensure that correct speed and log readings are displayed.
  • Page 59 Calibrate by speed over ground With a GPS connected to the system, the speed may be automatically set identical to the speed over ground value. This adjustment should be made in calm sea with no effect from wind or tidal current. 1.
  • Page 60 Depth The default value for the depth offset is 0.0, which indicates the displayed depth from the transducer to the seabed (b). Refer to the illustration on next page. The value should be increased or decreased, depending on whether the depth reading should be from the water line or from the keel respectively: −...
  • Page 61 The symbol in front of the depth reading will change to indicate that the depth is measured from: the keel the water line Range Changes per step Default value Units -10 - +10 m, ft Configuration | 61...
  • Page 62 (sensor) and calibrated separately. Refer to Manual source selection, page 38. The calibration procedure will have no effect on earlier compass models from Simrad and non-Simrad compasses! 62 | Configuration...
  • Page 63 Compass calibration Before the compass calibration is started, make sure that there is enough open water around the vessel to make a full turn. The calibration should be done in calm sea conditions and with minimal wind to obtain good results. Use about 60- 90 seconds to make a full circle.
  • Page 64 Turn rate too high, Turn rate too low, turning cw turning cw 4. The automatic calibration is completed when the information window disappears from the display Heading offset After compass calibration, the heading should be checked against a known reference, a compensated compass or a bearing.
  • Page 65 Rudder The rudder calibration is used to compensate for any non-linearity in the transmission between the rudder and the rudder feedback unit. Adjusting the maximum rudder angle 1. Select Max starboard and press the Menu/Enter key to start the calibration 2.
  • Page 66 Setting rudder zero position This adjustment should be made in calm sea and side forces from wind or current should be avoided. 1. Bring the boat up to cruising speed, and head directly into the wind 2. If the boat has twin engines, synchronize the engine RPM's 3.

  • Page 67: Simnet Groups

    The instance number is used to identify multiple units of the same model when connected to a SimNet or NMEA2000 network. The instance number is added to the product name e.g. IS20-3 for easy identification of the unit. Range Change per step Default value 0 –...
  • Page 68 Blank page Configuration | 68...

  • Page 69: Maintenance

    9 Maintenance 9.1 General maintenance The IS20 instruments are “repair by replacement” units, and the operator is therefore required to perform only a very limited amount of preventive maintenance. If the unit requires any form of cleaning, use fresh water and a mild soap solution (not a detergent).

  • Page 70: System Data

    NMEA 0183 status The NMEA 0183 status screen lists status information about available data type, checksum error and NMEA 0183 version. System data The System data screen provides status information about the different NMEA messages used by the system. 70 | Maintenance...

  • Page 71: Resetting The Instrument System

    9.3 Resetting the instrument system The reset options will reset the instrument to default settings. The Installation and Setup procedures must be repeated after a reset has been performed! Two different reset options are available: Local reset: Resets the selected instrument Global reset: Resets parameters on the selected instrument and all other units that share...
  • Page 72 Blank page 72 | Maintenance...

  • Page 73: Spare Parts

    10 Spare parts 10.1 Spares and auxiliaries Part no. Description 22096010 IS20 Graphic instrument head Mounting kit including: − 4 screws 22096630 − 4 corners 22096515 Weather cover 22096820 Bracket kit 1 24006355 SimNet blocking plug 22098495 NMEA0183 Interface cable 2.5 m (8’)

  • Page 74: Simnet Cables And Accessories

    10.2 SimNet cables and accessories Art. no. Description 24005829 0.3 m (1') SimNet cable (SDC:0.3M) 24005837 2 m (6.6') SimNet cable (SDC:02M) 24005845 5 m (16.6') SimNet cable (SDC:05M) 24005852 10 m (33') SimNet cable (SDC:10M) 24005860 SimNet T-joiner (SDJ) (3p) 24006298 SimNet Multijoiner (7p) 24006306...

  • Page 75: Specifications

    11 Specifications 11.1 Technical specifications Weight: ..........0,3 kg (1.1 lbs) Power consumption ..........1,3 W Color:............... Black Display: Type:......Backlit LCD matrix display Resolution: ........ 130 x 104 pixels Illumination (Red or white): . Adjustable in 10 steps Environmental protection: Front ............IP56 Back:............IP43 Safe distance to compass: .......

  • Page 76: Dimensional Drawing

    11.2 Dimensional drawing 114 [45.1"] Menu 114 [45.1"] 21 [8.3"] 17 [6.6"] Ø88 [34.6"] 44 [17.2"] 76 | Specifications...

  • Page 77: Menu Flow Chart

    11.3 Menu flow chart Specifications | 77...

  • Page 78: Data Groups And Data Items

    11.4 Data groups and data items DATA GROUP DATA ITEM DESCRIPTION Speed / Depth BOAT SPD Boat speed Speed over ground Velocity made good to wind VMG WPT VMG to waypoint (Waypoint Closure Velocity, WCV) SPD TRIM Speed trim DEPTH Current depth.
  • Page 79 DATA GROUP DATA ITEM DESCRIPTION Vessel HEADING Heading RUDANGLE Rudder angle Course over ground M AGVAR Magnetic variation Direction of current flow DRIFT Speed of current LATITUDE Latitude LONTUDE Longitude Coordinated Universal Time TIME Local time at vessel position Navigation BRG WPT Bearing to next waypoint...
  • Page 80 DATA GROUP DATA ITEM DESCRIPTION vironme SEA TEMP Sea temp erature AIR TEMP Air temperature B ARO PR Barometric pressure HUMIDITY Outdoor humidity 80 | Specifications...
