5.34 Display Management Layout

In the Active area of the display, the first 2 rows can show 12 characters each (default). It is
possible to extend the number of rows/characters to be displayed in idle mode/during a call
up to 3 rows with 16 characters each. When extending the rows/characters, the System
name or Owner ID will be hidden in order to allocate space for system dependent
information instead.
NOTE: All settings except the default setting require an IP-DECT system with software
version 5.0.x or higher.
1 Select System X.
2 In the Display Management Layout drop-down list, select one of the following:
• 2x12 characters
• 2x16 characters
• 3x16 characters, remove Owner ID
• 3x16 characters, remove system name

5.35 Owner identification in the Idle Display

It is possible to add owner identification in standby mode of the handset. In a template or
Number in PDM/Device Manager, the parameter is found at:
Settings > Owner ID
Note: The Owner ID might not be displayed depending on the setting in
Management
Tip: It is also possible to configure the Owner ID via the handset menu. See User Manual,
Ascom d62 DECT Handset, TD 92477GB.

5.36 Profiles

5.36.1 User Profiles

It is possible to set up an own profile for incoming calls, message alerts, message volume,
vibrating alerts, key sound etc. This can be useful when there are many users on the same
handset, and they want different sound profiles. It can also be used for temporarily settings,
for example while in a meeting, incoming calls should be silent.
1 Select User Profiles > User Profile X (where X represents 1 - 4).
2 In the Name text field, enter the name of the profile.
The name will be visible in the handset and will also be a selectable option in User
Profiles > Active Profile.
3 Select the settings to be edited. For example Sound and alerts, Soft keys etc.
4 If wanted, select the profile to be activated in the handset by selecting User Profiles >
Active Profile.
Tip: It is also possible to configure profiles via the handset menu. See User Manual, Ascom
d62 DECT Handset, TD 92477GB.

5.36.2 System Profiles

Note: This feature is applicable for d62 Messenger and d62 Protector only.
