ASCOM d62 Configuration Manual page 44

Configuration Manual
Ascom d62 DECT Handset
Prio 7
14:04
Figure 5. Describing how queing and prioritizing for messages with equal messages
In figure 5, a message with priority 2 is received at 13:59 and is displayed in the handset.
Another message with equal priority is received at 14:02 and will be placed in the queue. If
no messages with higher priority are received, the user needs to close the current displayed
message to show the next message in the queue. In this case, the message received at
14:02. The closed message will be indicated as a read message in the Messaging Inbox.
Example 2
This example describes the message handling with the following message settings:
• TTP= 20 seconds
• TTR= Close manually
Tip: It is recommended to use these settings if the user shall not be interrupted during 20
seconds while reading a message, unless a message with higher priority is received. When
the user has read a message, its priority is no longer important, that is when TTP expires.
New messages
Prio 2
Prio 2
TTP started
10 sec.
Figure 6.
In figure 6, a message with prio 2 is received and displayed in the handset, TTP for the
message is started.
After 10 seconds, a second message with priority 1 is received and displayed while the
message with priority 2 is put in the queue. TTP for the message with priority 2 is paused,
and TTP for the message with priority 1 is started.
08 December 2012 / Ver. H
New messages
Prio 7
14:04
Prio 4
14:03
Prio 2
14:02
Prio 2
13:59
Prio 4
14:03
Prio 4
13:58 Prio 2
Prio 2 13:59
14:02
works
New messages
Prio 1
Prio 1
TTP started
Prio 2
TTP paused
20 sec.
Prio 7
14:04
Prio 4
14:03
Prio 4
13:58
The user closes
the message
Prio 2
TTP
Prio 1 continues
TTP expired
10 sec.
TD 92639EN
Prio 2
14:02
Prio 1
TTP expired
Prio 2
TTP expired
39
