HORIZONTAL TERMINATIONS

TWO (2) 90 ELBOWS (RIGID PIPE 5" X 8")
O
One 90 elbow = Two 45
o
Option V H + H1
A) 0' Min. 2' Max.
B) 1' Min. 3' Max.
C) 2' Min. 4' Max.
D) 3' Min. 5' Max.
E) 4' Min. 6' Max.
F) 5' Min. 7' Max.
G) 6' Min. 8' Max.
No Vent Restrictor Installed
Lengths do not include elbow indicated.
Must use rigid pipe adaptor #770-994.
HORIZONTAL TERMINATIONS

THREE (3) 90

ELBOWS (RIGID PIPE 5" X 8")
O
One 90 elbow = Two 45
o
Option V
H
A) 0' Min. 1' Max.
B) 1' Min. 2' Max.
C) 2' Min. 2' Max.
D) 3' Min. 2' Max.
E) 4' Min. 3' Max.
F) 5' Min. 4' Max.
G) 6' Min. 5' Max.
H) 7' Min. 6" Max.
No Vent Restrictor Installed
Lengths do not include elbow indicated.
Must use rigid pipe adaptor #770-994.
H1
elbows.
o
With these options,
maximum total pipe
length is 30 feet with
minimum of 6 feet total
vertical and maximum 8
feet total horizontal.
Please note minimum
1 foot between 90
o
elbows is required.
H1
elbows.
o
V + V1 H + H1
W i t h
options, maximum
1' Min. 2' Max.
total pipe length
3' Min. 3' Max. is 30 feet with
minimum of 6 feet
5' Min. 4' Max.
total vertical and
7' Min. 5' Max. maximum 8 feet
total horizontal.
9' Min. 6' Max.
Please note mini-
mum 1 foot be-
10' Min. 7' Max.
tween 90
11' Min. 8' Max.
elbows is
required.
12' Min. 9' Max.
H
V1
t h e s e
o
installation
V
V
