Bellavista
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-009f
B36XTCE
®
Gas Fireplace
ANSI Z21.88-2017
CSA 2.33-2017
Installer: Please complete the details on the back cover and leave
this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODEL: B36XTCE-11
Medium DV Gas Fireplace
Bellavista
B36XTCE Video
www.regency-fire.com
06.18.21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bellavista B36XTCE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency Bellavista B36XTCE

Summary of Contents for Regency Bellavista B36XTCE

  • Page 1 Gas Fireplace MODEL: B36XTCE-11 Medium DV Gas Fireplace Bellavista B36XTCE Video www.regency-fire.com WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: On Demand Pilot Light (Seven Day Safety Timer)

    To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The Bellavista™ B36XTCE has been designed to ® provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The Bellavista™ B36XTCE has been approved by Warnock Hersey/Intertek for both safety and efficiency.
  • Page 3 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: to Vented Gas ® Fireplace Heaters ANSI Z21.88-2017 • CSA 2.33-2017 and Gas-fired Appliances for Use at High Altitudes CSA 2.17-2017.

  • Page 4: Table Of Contents

    table of contents OWNER'S INFORMATION Three (3) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") ....43 Venting Arrangements - Vertical Terminations ..44 On Demand Pilot Light ....2 (seven day safety timer) Vertical Terminations ..........45 Copy of Safety Decal .............5 Three (3) 90 Elbows (Rigid Pipe 4"...

  • Page 5: Copy Of Safety Decal

    This is a copy of the label that accompanies each Bellavista™ B36XTCE Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency ® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.

  • Page 6: Ma Code - Co Detector

    requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...

  • Page 7: Unit Dimensions

    dimensions UNIT DIMENSIONS 33" (838mm) 40-5/8" (1032mm) 7-7/16" (188mm) 3-1/4" (79mm) 29-7/8" (759mm) 32-7/8" (759mm) ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Bellavista® B36XTCE-11 Gas Fireplace...

  • Page 8: Installer's Information Gas Installation Checklist

    This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority.
  • Page 9 REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed?

  • Page 10: Important Message

    owner's information IMPORTANT MESSAGE YOUNG CHILDREN SHOULD BE CARE- 3. See general construction and assembly in- SAVE THESE FULLY SUPERVISED WHEN THEY ARE structions. The appliance and vent should be INSTRUCTIONS enclosed. IN THE SAME AREA AS THE APPLI- ANCE. TODDLERS, YOUNG CHILDREN The B36XTCE Gas Fireplace must be installed 4.

  • Page 11: Lighting Procedure

    owner's information LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has 3. After approximately 4 seconds the spark ignition system will spark for 60 several options for starting/operating the appliance using the power button seconds to light the pilot. and ON/OFF key on the hand held transmitter.

  • Page 12: Copy Of Lighting Plate Instructions

    owner's information COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 13: Proflame I Remote Control Operating Instructions

    owner's information PROFLAME I REMOTE CONTROL OPERATING INSTRUCTIONS PROFLAME I REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 1 is an integrated part of the TECHNICAL DATA Proflame 1 System, which consists of these elements: • Proflame 1 Transmitter, to be used in conjunction with: REMOTE CONTROL •...
  • Page 14 owner's information Temperature indication Display Remote‑Flame Control With the system in the "OFF" position, press the Thermostat Key and The Proflame has six (6) flame levels. With the system on, and the flame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the flame height by one step until the flame is turned off.
  • Page 15 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual room to the AUX icon (fig.
  • Page 16 owner's information LOW BATTERY POWER DETECTION Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (Fig.

  • Page 17: Installation Checklist

    owner's information INSTALLATION This includes: 4. This appliance is Listed for bedroom instal- CHECKLIST 1. Clocking the appliance to ensure the correct lations using the standard Remote (millivolt firing rate (rate noted on label 31,000 Btu/h thermostat system). Some areas may have 1.

  • Page 18: Clearances

    installation CLEARANCES The clearances listed below are minimum distances unless otherwise stated. A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. WARNING Caution Requirements Fire hazard is an extreme risk...

  • Page 19: Mantel Clearances

    installation MANTEL CLEARANCES Due to the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of front facing are shown in the Diagram on the right. Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non- combustible board.

  • Page 20: Mantel Leg Clearances

    installation MANTEL LEG CLEARANCES TopView Side opening of fireplace 3.5” 6.5" Allowable mantel leg projection. 12" NON- COMBUSTIBLE REQUIREMENTS: 40-5/8" 9-1/4" [1032mm] [235mm] Non combustible - supplied w/unit No Combustible 8-3/8" Materials in this Area [213mm] NO FACING OR FINISHING MATERIAL IN THIS AREA 4-1/8"...

  • Page 21: Framing

    installation FRAMING Framing Dimensions Description B36XTCE Framing Width 41-1/4"(1048mm) Framing Height 46-3/4" (1213mm) O (Rear Vent) Framing Depth - Rear Vent 23-7/8" (606mm) O (Top Vent) Framing Depth - Top Vent 23-7/8" (606mm) P (Top Vent) Corner Facing Wall Width 53-1/4"...

  • Page 22: Framing & Finishing

    installation FRAMING & FINISHING 1. Frame in the enclosure for the unit with framing material. Note: When constructing the framed opening, please ensure there is access to install the gas lines when the unit is installed. 2. For exterior walls, insulate the enclosure to the same degree as the rest of the house; apply vapour barrier and drywall, as per local installation codes. (Do not insulate the fireplace itself.) WARNING: Failure to insulate and add vapor barriers to the inside of the exterior wall will result in operational and performance problems including, but not limited to: excessive condensation on glass doors, poor flame package, carbon, blue flames etc.
  • Page 23 installation 7. Non-combustible material (ie. tile, slate, etc) may be brought up to the edge of the glass door of the unit. Minimum clearances must be adhered to, this will assure ease of glass door removal and access to the lower panel. NOTE: Non-combustible finishing materials may be of any thickness desired.

  • Page 24: Unit Assembly Prior To Installation

    installation UNIT ASSEMBLY PRIOR TO INSTALLATION The Top Nailing Support, the Side Nailing Strips, the 2 Top Standoffs and the Flue Collar must be correctly positioned and attached before the fireplace is moved into position. TOP STANDOFF ASSEMBLY STANDOFF SLOT LOCATION The top standoffs are shipped in a flat position and must be folded into shape and attached.

  • Page 25: Conversion To Top Vent

    installation CONVERSION TO TOP VENT Note: This conversion must be done prior to the unit being placed in position. The unit comes equipped as a rear vent unit. These instructions are to be used, only if the unit is going to be top vented. Top Collar Assembly Kit Exhaust Assembly Intake Cover Plate...
  • Page 26 installation 5. From the outside rear of the firebox, remove the intake collar assembly. Remove the 4 - 1/4" x 1/2" screws. See Diagram 5. Diagram 9 Exhaust Assembly Intake Collar Assembly 9. From the outside top of the firebox, install the intake collar assembly. Secure with 4 - 1/4"...

  • Page 27: Vent Restrictor, Baffle & Heat Deflector Installation

    installation VENT RESTRICTOR, BAFFLE & HEAT DEFLECTOR INSTALLATION Note: The vent restrictor & baffle must be installed prior to Optional Panel Installation. 1. Determine the venting configuration. 2. Remove top heat deflector and baffle plate (reverse of steps 5 & 6). 3.

  • Page 28: Exterior Vent Termination Requirements

    installation EXTERIOR VENT TERMINATION REQUIREMENTS Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 24"(60cm) 24"(60cm) from the center line of the terminal (check with the local code)

  • Page 29: Top Vent Reducer Installation-From 5"X8" To 4"X6-5/8

    installation TOP VENT REDUCER INSTALLATION (FLEX VENT ONLY) — FROM 5" X 8" TO 4" X 6-5/8" (PART #946-758) VENTING INTRODUCTION 5" X 8" OR 4"X 6-5/8 " The B36XTCE can be vented with either 5"x 8" or 4" x 6-5/8" venting depending on the vent configuration. Please see examples below and this manual to determine which venting options will be required for your customers application.

  • Page 30: Venting - Direct Vent System (Flex)

    Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in the "Exterior Vent Termination Loca- tions" section. Regency Direct Vent (Flex) System Termination Kit (Part # 946-515) includes all the parts needed to install the B36XTCE with a maximum run of 4 feet. 6-7/8" dia. flexible liner (4 ft. length) 4"...
  • Page 31 installation VERTICAL TERMINATION 4" X 6-7/8" VENTING - VERTICAL FLEX VENT KIT (946-755) 1. Maintain the 1-½” (38 mm) clearance (air space) to combustibles when 11. Secure inner fl ex pipe to pipe adaptor by using Mill-Pac over the adaptor. passing through ceilings, walls, fl...

  • Page 32: Vertical Flue Extension Kit (Part #946-756)

    installation VERTICAL FLUE EXTENSION KIT (PART #946-756) VERTICAL FLUE EXTENSION KIT (PART # 946-756) 20 foot (6.1 m) Flex pipe Extension (Used in conjunction with the 946-755 Vertical Flex kit and 948-367/P flex 4" (102 mm) inner to flex adaptor). CEILING FIRESTOP/FIRESTOP SPACER pipe 20ft.

  • Page 33: Rigid Pipe Cross Reference Chart Only

    Components from different manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: Olympia Ventis DV venting chart is only approved for certain models. See list of approved models in cross-reference chart.
  • Page 34 46DVA-WFS TM-4TR VDV-FS04 * Not available from Regency ***Olympia Ventis DV application for the following units only when using 4" x 6-5/8" vent system: B36XTE, B36XTCE, all City Series 40 models, CV72E/CB72E (power-vented models only), G800C, G800EC, P36, P36E, RC500E.
  • Page 35 Components from different manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart.
  • Page 36 TM-5ST14 Snorkel Termination 36" 58DVA-SNK36* TM-5ST36 Restrictor Disk Colinear Flex Connectors * Not available from Regency 946-604/P Simpson Direct Vent or Astro Cap -Vent Guard (Optional) 946-623/P AstroCap XL Horizontal Cap 770-994 Rigid Pipe Adaptor (Must use with all rigid piping)

  • Page 37: Venting Arrangements - Horizontal Terminations

    FLEX VENT OR RIGID PIPE 5" X 8" The Diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes.

  • Page 38: Horizontal Terminations

    Notes: 1. Liner sections should be continuous without any joints or seams. 2. Only Flex pipe purchased from Regency may be used for Flex installations. 3. Regency® Direct Vent System (Flex) is only approved for horizontal terminations. Bellavista® B36XTCE-11 Gas Fireplace...

  • Page 39: Rigid Pipe 5" X 8

    installation HORIZONTAL TERMINATIONS RIGID PIPE 5" X 8" Vinyl Siding Standoff (Optional) Horizontal Termination Wall Thimble Pipe Length 90 Elbow Rigid Pipe Adaptor Pipe Length Rigid Pipe Adaptor Horizontal Termination Top Vent - No Vertical Rise • When venting with a 90° elbow directly off the unit, must use 5"...

  • Page 40: Astrocap Xl & Rigid Rear Vent Kit - Corner Install

    installation B36X/XT HORIZONTAL TERMINATIONS ASTROCAP XL & RIGID REAR VENT KIT FOR CORNER INSTALLATIONS HORIZONTAL 5” X 8” RIGID REAR VENT KIT RIGID PIPE 5" X 8" FOR CORNER INSTALLA TIONS Designed for a minimum vent confi guration when using a rear vent application with a horizontal termination in a corner installation.

  • Page 41: Venting Arrangements Horizontal Terminations

    installation VENTING ARRANGEMENTS FOR HORIZONTAL TERMINATIONS RIGID PIPE 4" X 6-5/8" (MUST USE REDUCER & RIGID PIPE ADAPTOR (PARTS # 946-606 & 770-994) The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 (two 45 elbows equal one 90 elbow).

  • Page 42: Horizontal Or Vertical Terminations

    (1092 mm) Rigid Pipe Adaptor The Regency AstroCap and Regency Riser Vent terminal are certified for installations using Regency venting systems as well as any specific chimney systems listed in this manual. AstroCap is a proprietary trademark of Regency Fireplace Products.

  • Page 43: Horizontal Terminations

    installation HORIZONTAL TERMINATIONS TWO (2) 90 ELBOWS (RIGID PIPE 4" X 6 - 5/8") One 90 elbow = Two 45 elbows. Option H + H1 W i t h t h e s e o p t i o n s, maximum total pipe length 0' Min.

  • Page 44: Venting Arrangements - Vertical Terminations

    installation VENTING ARRANGEMENTS FOR VERTICAL TERMINATIONS RIGID PIPE 4" X 6-5/8" (MUST USE REDUCER PART # 946-606 & 770-994 RIGID PIPE ADAPTOR) The shaded area in the Diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two 90 elbows, with Rigid Pipe Venting Systems for Propane and Natural Gas.

  • Page 45: Vertical Terminations

    installation VERTICAL TERMINATIONS THREE (3) 90 ELBOWS (RIGID PIPE 4" X 6 - 5/8") One 90 elbow = Two 45 elbows. Option H + H1 V + V1 With these options, max. total pipe 0' Min. 2' Max. 2' Min. length is 30 feet with min.

  • Page 46: Venting Arrangements

    installation VENTING ARRANGEMENTS WITH CO-LINEAR FLEX SYSTEM Masonry chimneys may take various contours which the flexible liner will accommodate. However, THE APPLIANCE MUST NOT BE keep the flexible liner as straight as possible, avoid unnecessary bending. CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE SOLID FUEL The Air Intake pipe must be attached to the inlet air collar of the termination cap.

  • Page 47: Vertical Terminations

    installation VERTICAL TERMINATIONS CO-LINEAR FLEX SYSTEM INTO MASONRY FIREPLACES FOR BOTH RESIDENTIAL & MANUFACTURED HOMES The shaded area in the Diagrams show the allowable vertical terminations. Bellavista® B36XTCE-11 Gas Fireplace...

  • Page 48: Unit Installation With Horizontal Termination

    installation Note: For best results and optimum performance UNIT INSTALLATION WITH HORI- **Riser Vent Termination with each approved venting system, it is ZONTAL TERMINATION highly recommended to apply “Mill-Pac” 4" X 6-5/8" OR 5" X 8" VENTING sealant (supplied) to every inner pipe connection.

  • Page 49: Unit Installation With Horizontal Termination

    installation ASTROCAPXL 8. Before connecting the horizontal run of vent pipe 2. Level the fireplace and fasten it to the framing to the vent termination, slide the Wall Thimble DIMENSIONS (946-623/P) using nails or screws through the nailing strips. over the vent pipe. The wall thimble is required 3.

  • Page 50: Unit Installation With Vertical Termination

    installation UNIT INSTALLATION WITH 5. Cut a hole in the roof centered on the small drilled hole placed in the roof in Step 2. The hole VERTICAL TERMINATION should be of sufficient size to meet the minimum 4" X 6-5/8" VENTING requirements for clearance to combustibles of 1-1/2".

  • Page 51: Pilot Adjustment

    1. Make sure the valve is in the "OFF" position. B36XTCE - LP11 System Data Note: If you have an incorrect flame 2. Loosen the "IN" and/or "OUT" pressure tap(s), turning pattern, contact your Regency ® For 0 to 4500 feet altitude counterclockwise with a 1/8" wide flat screwdriver.

  • Page 52: Conversion Kit #578-977 From Ng To Lp

    installation B36XTCE/ B36XTE-11 CONVERSION KIT #578-977 FROM NG TO LP for B36XTCE using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 6. Remove the pilot shield by removing 2 9.

  • Page 53: Brick Panel Installation

    B36X/XT installation BRICK PANEL INSTALLATION BRICK PANEL INSTALLATION Dangerous operating conditions may occur if the panels are broken. Handle with care. DO NOT FORCE INTO POSITION. 1) Unwrap the Brick Panels from the protective wrapping. 2) Ensure that the logs are not in the unit. Top Panel Back Panel Left Panel...

  • Page 54: Optional Black Enamel Panel Installation

    B36X / XT installation OPTIONAL BLACK ENAMEL PANEL INSTALLATION BLACK ENAMEL PANEL INSTALLATION Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. •...

  • Page 55: Log Set Installation

    installation B36XT LOG SET INSTALLATION LOG SET INSTALLATION Installation of Optional Panels must be completed before installing the log set. Read the instructions below carefully and refer to the images. If the 2) Spread vermiculite along the base of the fi rebox. logs are broken do not use the unit until they are replaced.
  • Page 56 B36XT installation 6) Position Log D with the fl at side toward Log E. 5) Place Log A on the front right side of the burner. Position the notch Fit Log D into right peg on Log E. on the bottom right side of the log into the right side of the grate. Slide Log A back towards Log E until the fl...
  • Page 57 B36XT installation 8) Place the lava rocks on the front of the burner tray in the places shown in the photo. Separate platinum embers and place on the front of the burner tray in and around the lava rocks. Avoid stacking platinum embers. Platinum embers may be placed over burner ports.

  • Page 58: Aeration Adjustment

    installation AERATION ADJUSTMENT The burner aeration is factory set but may need adjusting due to either the local gas supply or altitude. Open the air shutter for a blue flame or close for a more yellow flame. Minimum Air Shutter Opening: CAUTION: Carbon will be produced if air shutter is tightly closed.

  • Page 59: Installing The Optional Fan

    B36XTCE / B36XTE installation FAN INSTALLATION INSTALLING THE OPTIONAL FAN Important: 120 Volt AC power is needed for the 7. Plug in the fan power cord to the Fan Con- 5. Slide the thermodisc/cover assembly into blower. The receptacle box will be installed on the bracket clip on the underside of the trol Module into the outlet marked “Fan”.

  • Page 60: Wiring Diagram With Optional Fan

    installation WIRING DIAGRAM WITH OPTIONAL FAN SureFire™ Switch 0.584.622 Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.

  • Page 61: Optional Wall Thermostat Installation

    installation OPTIONAL WALL THERMOSTAT INSTALLATION 4) Connect the other thermostat lead to male connector disconnected A wall thermostat may be installed if desired. from Step 1 using a female spade connector - see picture below. Recommended: The Wall Thermostat should be mounted beside the Re- mote/Unit Receiver which comes standard with the appliance.

  • Page 62: Safety Screen Removal / Installation

    installation SAFETY SCREEN REMOVAL / INSTALLATION 1. To remove the safety screen, grasp safety screen on both sides from the bot- 2. When hooks are clear of the bracket–tilt mesh frame out slightly from the tom. Lift up and out slightly to release from bottom magnets and to release bottom and manoeuvre mesh out.

  • Page 63: Flush Glass Door Installation

    installation FLUSH GLASS DOOR INSTALLATION 1. Line up slots on flush glass door with tabs in firebox. Hook slots on to tabs and lower door slowly (See Diagram 1). Tabs in Firebox Diagram 1 2. Lower the flush door, then hook the 2 adjustable tension latches - close the latches to secure the flush door (See Diagram 2). Adjustable Tension Latch location Diagram 2...

  • Page 64: Operating Instructions

    operating instructions NORMAL OPERATING OPERATING SOUNDS OF GAS APPLIANCES INSTRUCTIONS It is possible that you will hear some sounds from 1. Read and understand these instructions before your gas appliance. This is perfectly normal due to operating this appliance. the fact that there are various gauges and types of steel used within your appliance.

  • Page 65: Copy Of Lighting Plate Instructions

    operating instructions COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 66: Maintenance Instructions

    The position of these logs must be as shown tant paint. Regency® uses StoveBright Paint in the Diagrams under Log Installation. - Metallic Black #6309.

  • Page 67: Removing Valve

    maintenance REMOVING VALVE 8. Disconnect the inlet gas line. 9. Disconnect the EV1, EV2, and ground wires 1. Shut off the gas and electrical supply. from the valve - as shown below. 2. Remove the mesh barrier. 3. Open the flush door and remove the door. 4.

  • Page 68: Gas Maintenance

    Gas Maintenance maintenance GAS MAINTENANCE - RECOMMENDED ANNUAL ROUTINE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) •...

  • Page 69: Main Assembly

    parts list MAIN ASSEMBLY Part # Description Part # Description 578-917 Fan Assembly 576-084F Top Insulation Plate 910-215/P Fan Motor (120 Volts) 576-099 Top Insulation 911-030 Fan Control Module 556-524 Flue Collar Outer Assembly 911-159 Power Cord (120 Volts) 556-095 Flue Collar Gasket 910-142 Thermodisc - Fan Auto...
  • Page 70 parts list MAIN ASSEMBLY Bellavista® B36XTCE-11 Gas Fireplace...

  • Page 71: Burner Assembly

    parts list BURNER ASSEMBLY Part # Description Part # Description 911-265 Ignition Board (DBC) 576-077 Rear Log Tray 911-013 Wiring Harness -Switch 576-525 B36XTCE Burner Assembly NG/LP 911-018 Battery Holder 576-057 B36XTCE Grate Assembly 911-037 Flame Sensor 911-038 Flame Electrode 911-039 Pilot Hood 904-644...

  • Page 72: Warranty

    FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: February 2019 Regency Gas Products Warranty Bellavista® B36XTCE-11 Gas Fireplace...
  • Page 73 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Bellavista® B36XTCE-11 Gas Fireplace Revision Date: February 2019 Regency Gas Products Warranty...
  • Page 74 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
  • Page 75 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 76 warranty Bellavista® B36XTCE-11 Gas Fireplace...
  • Page 77 notes Bellavista® B36XTCE-11 Gas Fireplace...
  • Page 78 notes Bellavista® B36XTCE-11 Gas Fireplace...
  • Page 79 Bellavista® B36XTCE-11 Gas Fireplace...
  • Page 80 Dealer Name & Address: ________________________________________ _____________________________________________________________ Installer: _____________________________________________________ Phone #: _____________________________________________________ Date Installed: ________________________________________________ Serial #: ______________________________________________________ Printed in Canada Regency®, Bellavista®, Surefire™, and AstroCap™ are trademarks of FPI Fireplace Products International Ltd. © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
