MANTEL CLEARANCES

Due to the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of front facing are
shown in the diagram on the right.
Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible
board.
Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour.
Inches
Mantel Clearances
14 12 10 8
12
24
B
C
12
0
A
To Floor
Mantel Clearances
B41XTCE
From Top of
Fireplace Opening
6 4 2
Combustible
7
Non-combustible
1"
6
D
Top of
Fireplace
Opening
A B
32-11/16" 25-13/16"
(830mm) (656mm)
installation
Header
(steel stud)
on edge
Non-combustible
Standoff
C D
22-1/16" 17-9/16"
(560mm) (446mm)
