Regency Bellavista
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
919-377
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Fireplace
B41XTE
™
Owners &
Installation Manual
MODELS: B41XTE-NG10
B41XTE-LP10
www.regency-fire.com
09.30.14
Advertisement
Table of Contents
Related Manuals for Regency B41XTE-NG10
Summary of Contents for Regency B41XTE-NG10
- Page 1 Owners & B41XTE Regency Bellavista ™ Installation Manual Gas Fireplace MODELS: B41XTE-NG10 B41XTE-LP10 www.regency-fire.com WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The Bellavista™ ® B41XTE has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The Bellavista™ B41XTE has been approved by Warnock Hersey/ Intertek for both safety and efficiency.
-
Page 3: Manufactured Mobile Home Requirements
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. Ensure that structural members are not cut or weakened during installation. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 4: Table Of Contents
Main Assembly ............59 Two (2) 90 Elbows (Rigid Pipe 5" x 8") ....29 Burner Assembly ............60 Horizontal terminations ..........29 Accessories ..............61 Three (3) 90 Elbows (Rigid Pipe 5" x 8") ....29 The Warranty: Limited Lifetime ........63 Regency Bellavista™ B41XTE -10 Gas Fireplace... - Page 5 The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back up in the same room where the gas appliance is installed. Regency Bellavista™ B41XTE -10 Gas Fireplace...
-
Page 6: Ma Code - Co Detector
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 7: Unit Dimensions
UNIT DIMENSIONS 46 9/16" 1183mm 41 11/16" 1059mm 38 3/8" 974mm 2 7/16" 61mm 43 7/16" 1103mm 1 15/16" 49mm 35" WINDOW 39 7/8" 1012mm SCREEN FRAME Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 8: Important Message
National Electrical Code, ANSI/ NFPA 70 or CSA C22.1 Canadian Electrical Code. 3) See general construction and assembly instructions. The appliance and vent should be enclosed. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 9: Installation Checklist
Inner Panels or Brick Panels (Required) c. Log Set Installation d. Standard Flush Door e. Fan Installation (Optional) f. Light Installation (Optional) g. Finishing Trim (Optional) 7) Final check. Diagram 1 Flat on Wall Corner Recessed into Wall/Alcove Corner Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 10: Clearances
NOTE: A 16" deep non-combustible hearth pad is recommended for hardwood flooring and carpet. Alcove Minimum Vent Clearances to Combustibles Horizontal Top 3" (76mm) Horizontal Side 2 " (51mm) Horizontal Bottom 2" (51mm) Vertical Vent 2" (51mm) 10 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 11: Mantel Clearances
Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour. Mantel Clearances B41XT From Top of 35-1/4" 23-1/4" 19-1/2" 15" Fireplace Opening (895mm) (591mm) (495mm) (381mm) Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 12: Mantel Leg Clearances
Fireplace Opening) 4” 7” Allowable mantel leg projection. NON-COMBUSTIBLE REQUIREMENTS Non-combustible Header (steel stud) 48-3/4" on edge (1238mm) Non-combustible Non-combustible Material 41-3/4" (1060mm) 47-1/4" (1200mm) Framing Min. 3-1/2” Min. 3-1/2” (89mm) (89mm) 12 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 13: Framing
Non-Combustible Drywall, Wood Header (or other facing) (steel stud) on edge Non-Combustible Header (steel stud) on edge Non-Combustible Facing 11" (279mm) dia. Hole through wall Vent. Top Vent Rear Vent Opening for gas connection Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 14: Wall Mount On / Off Switch Receiver Installation
11. Using the two (2) screws provided secure the cover plate to the Receiver. Low Voltage Junction Box Profl ame Receiver J-Box Receiver Slider Switch Wall Plate 10 ft. wire harness with 12 pin connector Diagram 1 14 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 15: Finishing
Alternatively, you can use J Style Trim or Metal Corner Bead to cover cut edges of the non-combustible facing material. Non-combustible Material J-style Trim or metal corner bead may be used to finish these edges Diagram 2 " Diagram 3: Shown with optional Finishing Trim Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 16: Unit Assembly Prior To Installation
Nailing Strip Top Facing Support Screw holes for Top Facing Support 3.eps Nail4.eps 16 | Regency Bellavista™ B41XTE -10 Gas Fireplace Top Facing Support Side Nail6.eps is reversed Nailing for “C” hole position... -
Page 17: Conversion To Top Vent
3) From the inside of the firebox, remove the exhaust assembly by remov- ing the 10 screws. Before proceeding to Step 8, inspect condition of all gaskets. DO NOT install parts with damaged gaskets. Replace if necessary with spare gaskets supplied. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 18: Baffle Plate Diagram
Leave loose - until rear screws installed. See Diagram 3. Baffle Plate Diagram 3 Note: Reuse existing screw holes - do not make new holes. Tighten screws. Diagram 2 18 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 19: Venting Introduction
6) From inside the firebox, install the baffle plate with 4 - 1/4" x 1/2 " AT 1-1/2” screws. Ensure all screws are tightly secure, but do not over tighten. Diagram 1 Baffle Plate Diagram 3 Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 20: Exterior Vent Termination Requirements
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally 20 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 21: 5" X 8" Rigid Pipe
5” X 8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Description... - Page 22 • A Vent Guard is required when the AstroCap is installed above grade at 7 feet or lower. • The Simpson Dura-Vent and Selkirk Direct Temp horizontal termination caps cannot be used in any applications. • Only the AstroCap XL and Snorkels are certifi ed for horizontal terminations. 22 | Regency Bellavista™ B41XTE -10 Gas Fireplace...
-
Page 23: Venting Arrangements For Horizontal Terminations
FLEX VENT OR RIGID PIPE 5" X 8" The diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes. -
Page 24: Horizontal Terminations
Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency may be used for Flex installations. 3) Regency Direct Vent System (Flex) is only approved for horizontal terminations. -
Page 25: Rigid Pipe 5" X 8
Vinyl Siding Standoff (Optional) Horizontal Termination Wall Thimble Pipe Length 90 Elbow Rigid Pipe Adaptor Pipe Length Rigid Pipe Adaptor IMPORTANT Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 26: Astrocap Xl & Rigid Rear Vent Kit
948-128 3” Vinyl Siding Standoff (Optional) Astrocap 85-3/16” Wall Thimble Pipe Length 45 elbow Rigid Pipe Adaptor IMPORTANT Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. 26 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 27: Venting Arrangements
A wall thimble is mandatory for all horizontal terminations due to high temperatures. Horizontal (Feet) Restrictor 1-1/2” Open Set 3 Restrictor 2-1/2” Open Set 2 Restrictor 3-1/2” Open Set 1 47-1/2" (1207mm) Minimum Height Requirement Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 28: Rigid Pipe Venting Systems
Direct Vent Pro, ICC Excel and Selkirk ® Direct-Temp. AstroCap XL is a proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. 28 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 29: Horizontal Terminations
6' Min. 5' Max. 11' Min. 8' Max. elbows is required. 7' Min. 6" Max. 12' Min. 9' Max. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use rigid pipe adaptor #770-994. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 30: Venting Arrangements For Vertical Terminations
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting to 3-1/2" opening, 2-1/2"opening and to 1-1/2" opening. Note: Must use optional flue adapter when using Rigid Pipe (Part # 770-994). 30 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 31: Vertical Terminations
5' Min. 8' Min. 6' Max. 6' Min. 9' Min. 7' Max. 10' Min. 8' Max. 7' Min No Vent Restrictor Installed Lengths do not include elbow indicated. Must use rigid pipe adaptor #770-994 Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 32: Unit Installation With Horizontal Termination
Diagram 7 Diagram 2 IMPORTANT Diagram 1 Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. 32 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 33: Unit Installation With Horizontal Termination
Apply Mill Pac or high temperature Vinyl Siding silicone to the outer flex pipe and slip it over Wall Thimble the outer flue collar of the vent terminal at Screws least 1-3/8"(35mm) and fasten with the 3 screws. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 34: Unit Installation With Vertical Termination
Important: Always check for gas leaks with a soap and water solution or gas leak detector. vent height may solve the problem. Do not use open flame for leak testing. 34 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 35: Pilot Adjustment
Note: Screw should be snug, but do not over tighten. 885 S.I.T. VALVE DESCRIPTION 1) 6 Stage flame adjustment 2) Pilot adjustment 3) Outlet Pressure Tap 4) Inlet Pressure Tap 5) Pilot Outlet 6) Main Gas Outlet 7) Main Gas Inlet Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 36: Brick Panel Installation
fi rebox wall (left side shown). Position the left brick panel in place and secure with the brick panel clip and screw removed from the fi rebox as shown below. 36 | Regency Bellavista™ B41XTE -10 Gas Fireplace 918-865a 11/09/09... -
Page 37: Optional Black Enamel Panel Installation
fi rebox. See diagram below. panel is centered when installed. Install the right side panel - secure with panel clip and 1 screw. See step 3. Top Panel Bracket Back Panel Right Side Panel Regency Bellavista™ B41XTE -10 Gas Fireplace 05/29/12 918-866b... - Page 38 Stainless Steel Panels 5) Slide top panel under the top of the back and right side panels as shown below. 6) Install left side panel - repeat step 4. 38 | Regency Bellavista™ B41XTE -10 Gas Fireplace 918-866b 05/29/12...
-
Page 39: Log Set Installation
4) Place Log F on the right side of the burner, directly in front of Log A. Position Log F so it fi ts into the pin on the burner as shown below. Diagram 2 Vermiculite Diagram 4–Log F Regency Bellavista™ B41XTE -10 Gas Fireplace 09/23/09 918-863... - Page 40 10) Slide the right side of Log H back until it touches the tab on the burner shown below. Tab on Burner Back of Log H Diagram 9 Diagram 6–Log G 40 | Regency Bellavista™ B41XTE -10 Gas Fireplace 918-863 09/23/09...
- Page 41 13) Position Log B on top of Log A. Log B fi ts into the pin in Log A. Ensure Log B sits upright 90 degrees with the left side of the log resting on the notch in Log E. See next 2 diagrams. Diagram 15 Diagram 12 Regency Bellavista™ B41XTE -10 Gas Fireplace 09/23/09 918-863...
- Page 42 19) Test fi re to ensure proper lighting (make sure fl ame fl ows smoothly from one end of the burner to the other). If there is any fl ame hesitation, check that area for any blockage of the burner ports. 42 | Regency Bellavista™ B41XTE -10 Gas Fireplace 918-863 09/23/09...
-
Page 43: Wiring Diagram
CAUTION: Label all wires prior to disconnection Caution: Ensure that the wires do not touch any when servicing controls. Wiring errors can cause hot surfaces and are away from sharp edges. improper and dangerous operation. 1 of 10 Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 44: Ac Adaptor Installation
2. Tuck any loose wires neatly underneath the firebox–inside the fireplace. Note: Ensure that wires do not touch the underside of the fire box (Keep wires away from heat as much as possible). AC adaptor Wire adaptor 44 | Regency Bellavista™ B41XTE -10 Gas Fireplace 10/09/14 919-063... -
Page 45: Optional Fan Installation
8) Plug fan power cord into the Fan Control Module (FCM) then plug in the FCM. The switch is on when pushed to the left. (Shown in OFF position above) 09.30.14 919-439 Regency Bellavista™ B41XTE -10 Gas Fireplace... - Page 46 46 | Regency Bellavista™ B41XTE -10 Gas Fireplace...
-
Page 47: Wiring Diagram With Optional Fan
Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 48: Optional Accent Light Installation
Diagram 2: Slide burner assembly to the right and then remove. 8) Remove the 2 screws securing the rear log tray and lift out. Diagram 3 Diagram 3 48 | Regency Bellavista™ B41XTE -10 Gas Fireplace 09/23/09 918-864... - Page 49 Note: Glass is longer than diffuser for ease of removal. Note: Oils from hands will shorten the life of the bulbs, do not handle bulbs with bare hands. 19) Reverse steps 9 - 1. Regency Bellavista™ B41XTE -10 Gas Fireplace 918-864 09/23/09...
- Page 50 B41XT LINE VOLTAGE WIRING TO RECEPTACLE IN UNIT TO MAKE OUTLETS INDEPENDENT OF EACH OTHER AC Adaptor ELECTRICAL WORK MUST BE PERFORMED BY A QUALIFIED ELECTRICIAN 50 | Regency Bellavista™ B41XTE -10 Gas Fireplace 08/12/14 918-864a...
-
Page 51: Flush Glass Door Installation
Slide the Finishing Trim Top over the Side Trim pieces and fit the bottom bracket slots over the screws. Tighten the 2 screws to secure in place. B41XTE B36XTE 43-3/8" 40-1/2" Edge of Unit Finishing Trim 37-5/8" 35-3/4" Regency Bellavista™ B41XTE -10 Gas Fireplace 918-791a 09/10/14... -
Page 52: Vignette Frame And Mesh Installation
4. Line up Vignette Frame to unit and hook the frame on to the appliance. Slide the top of the frame (See Detail AA above) on to the screws. (See Detail A shown above) 7. Reverse the steps to remove. 52 | 919-464 Regency Bellavista™ B41XTE -10 Gas Fireplace 10.07.14... -
Page 53: Operating Instructions
The glass should be cleaned or the film will bake on and become very difficult to remove. Use a non-abrasive cleaner and NEVER clean the glass while it is hot. Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 54: Lighting Procedure
2. Press and release the ON/OFF button on the remote handheld transmit- ter (see Diagram 2). An audible beep should be heard from the receiver. ON/OFF Button Diagram 2 Remote shown in Manual Mode on Hi 54 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 55: Copy Of Lighting Plate Instructions
Utilisez l'interrupteur murale ON/OFF du Brûleur ou du contrôle à distance pour éteindre le brûleur. Si le service est effectuée–vous devez débrancher l'alimentation et coupez le gaz à l'unité. DO NOT REMOVE THIS INSTRUCTION PLATE 919-401a Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 56: Maintenance Instructions
In the event that you break your glass by impact, air is not obstructed. purchase your replacement from an authorized Regency dealer only. Replacement glass (Part Note: Never operate the appliance without #940-362/P) is shipped already installed into the glass properly secured in place. -
Page 57: Accent Light Bulb Replacement
Diagram 2: Slide burner assembly to the right and then remove. 11) Reverse steps 9 - 1. 8) Remove the 2 screws securing the rear log tray and lift out. Diagram 3 Diagram 3 09/23/09 918-864 Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 58: Valve Replacement
Diagram 3 Diagram 3 11) Remove the 14 screws securing the valve tray assembly in place (Diagram 7) and then lift the entire assembly out Also remove the valve gasket. Diagram 7 58 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 59: Main Assembly
911-012 Ignition Module 919-377 Manual 12) 948-259 Spring Handle Lever 13) 948-025 Spring Door Extension * Not available as a replacement part. 14) 940-362/P Ceramic Glass 15) 509-083 Door Frame Outerbox Assembly Firebox Assembly Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 60: Burner Assembly
Flame Sensor 911-030 Fan Control Module 911-038 Flame Electrode 910-100 Pilot Orifice - NG 910-101 Pilot Orifice - LP 946-721 AC Adaptor 578-972 Conversion Kit LP 15) 506-062 Base Tray 506-930 Log Set 60 | Regency Bellavista™ B41XTE -10 Gas Fireplace... -
Page 61: Accessories
ACCESSORIES Part # Description 509-946 3-Sided Finishing Trim 506-901 Brick Panels - Standard Brown 506-902 Brick Panels - Standard Red 506-905 Brick Panels - Standard Charcoal Gray 506-908 Inner Panels - Black Enamel Regency Bellavista™ B41XTE -10 Gas Fireplace... - Page 62 62 | Regency Bellavista™ B41XTE -10 Gas Fireplace...
-
