- Page 1 MUST READ BEFORE FRAMING IMPORTANT INFORMATION Regency City Series San Francisco Bay 72 CB72EPV-NG / CB72EPV-LP FRAMING DIMENSIONS SPECIFICATIONS HEAT RELEASE REQUIREMENTS QR LINK FOR PDF DIGITAL COPY OF SPECIFICATIONS:...
- Page 2 1/16" when converted, when greater accuracy is required, use the metric dimensions. Note: These units are non-load bearing. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. | City Series CB72EPV...
- Page 3 1/16" when converted, when greater accuracy is required, use the metric dimensions. Note: These units are non-load bearing. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. City Series CB72EPV |...
-
Page 4: Gas Connection - Back Of Unit
2 " 2 " 5" 2 " 5" 2 " 5" 2 " 2 " 4 " 5" 4 " 4 " 5" 4 " 2 " 2 " Right Side Left Side 2 " | City Series CB72EPV 39"... -
Page 5: Electrical Connection - Bottom Of Unit
2 " 5" 2 " 4 " 5" 4 " 2 " 2 " 2 " 39" Gas Valve Front of Unit Opening at unit base 2 " City Series CB72EPV | Back of Unit 4 " 5" 4 "... - Page 6 Ventilation Openings (Three-sided/Bay Installation) • For right/left two-sided corner, see next page. Regency's patented Cool Wall system releases warmth at ceiling level. This system reduces excessive radiant heat in front of the fireplace so you can enjoy your fireplace more often.
- Page 7 Ventilation Openings (Right/Left Corner) Regency's patented Cool Wall system releases warmth at ceiling level. This system reduces excessive radiant heat in front of the fireplace so you can enjoy your fireplace more often. • Design your own chase vent solution to suit your home •...
-
Page 8: Chase Enclosure
40” (1016 mm) Chase Vent Stud Stud In the example above, the ceiling does not meet the requirement as it is higher than the specified minimum. Top of chase enclosure is sealed off to meet the 0-2'' (51mm) requirement. | City Series CB72EPV... - Page 9 Fire hazard is an extreme risk if these clearances (air space) to combustible materials are not adhered to. It is of greatest importance that this fireplace and vent system be installed only in accordance with these instructions. City Series CB72EPV |...
-
Page 10: Installation
Low framing with vents in front/2 sides or top Bottom of fireplace Bottom of fireplace opening opening Full framing with low vents in front or 2 sides Full framing with vents in front or 2 sides | City Series CB72EPV... - Page 11 Fire hazard is an extreme risk if these clearances (air space) to combustible materials are not adhered to. It is of greatest importance that this fireplace and vent Top View system be installed only in accordance with these instructions. Alcove City Series CB72EPV |...
-
Page 12: Mantel Leg Clearances
1/2" (13mm) Drywall, wood, wood panel, etc. 12" (305mm) 9” (229mm) 5-1/8" (130mm) To Bottom of Top of Fireplace Fireplace 15-1/16" Opening Opening (382mm) Mantel Leg Clearances Combustible mantel leg clearances as per diagram: MANTEL LEG 8" (203mm) | City Series CB72EPV... - Page 13 The framing depth will need to change based on the thickness of the material (example: 20 5/8 framing depth + 1/2 drywall = 21 1/8") City Series CB72EPV |...
- Page 14 2'' x 4'' or 2'' x 6''. Note: This appliance must be in- stalled on a level and solid surface such as a plywood floor which must be the full width and depth of the appliance. | City Series CB72EPV...
- Page 15 Note: Studs in back and side such as a plywood floor which must can be either wood 2'' x 4'' be the full width and depth of the or 2'' x 6''. appliance. City Series CB72EPV |...
- Page 16 CB72 CORNER CB72 CORNER CONVERSION - ASSEMBLY STEPS Corner Conversion - Assembly Steps 1. Decide on Left or Right install - Install outer panel of corner conversion 2. Install trim guide for left or right install to the outer side panel. before placing unit in framing. LEFT RIGHT | City Series CB72EPV 02.20.19 920-068...
- Page 17 CB72 CORNER installation 3. Bend tabs closest to the finishing trim inwards 90 degrees on the outer 5. Slide outer side panel down onto screws that remain from removable side panel. trim. Tighten screws with offset screwdriver. 6. Screw in the two self-tapping screws to the top of the outer side panel. Unit can be placed in framing at this point. 4. Loosen screws using offset screwdriver and remove trim guides from side of unit and recycle them. 7. See inner panel install section. Once firebox panels are installed, then install corner conversion liner panel inside of side barrier glass. Note: Gasket side of panel sits against the glass and the flange sits at top. 920-068 02.20.19 City Series CB72EPV |...
- Page 18 CB72 CORNER installation 8. Once all framing and wall finishing is complete, use offset screwdriver 11. Slide corner piece up to outer side panel until contact with magnet is and remove finishing trim guides. made. 9. Install outer liner panels and then recycle unused side and back panel. 12. Once corner conversion is installed, continue regular install of barrier glass. Discard unused side glass barrier. 10. Slide corner piece in right up to firebox glass. | City Series CB72EPV 02.20.19 920-068...
-
Page 19: City Series
3. Place unit against wall in desired location. Level the unit by adjusting 4 leveling bolts on unit. 4. Install venting before proceeding further with framing kit construction. Refer to manual for venting instructions. Framing Kit with unit - Overall dimensions City Series CB72EPV | 01.24.19 919-951a... - Page 20 10. Install Part A (x2) to Part G on each side with 2 screws on each end. 7. Attach the 4 x end pieces (Part J) to the upper and lower Part B of the back frame with two screws each. Part A Part J | City Series CB72EPV 919-951a 01.24.19...
- Page 21 (installed from the top). at each end. Part K Part D 12. Install 4 front supports (Part C) to upper and lower Part A with 2 screws on each end. Part C Part ID overview City Series CB72EPV | 11.07.18 919-951...
- Page 22 The top of the chase vent opening must be 2” or less from the top of the chase enclosure. Min 74.25” Opening for vent 5”-5.5” Ceiling Ceiling Stud Max 2” Top of chase enclosure Max 2” 72” Chase Vent 72” Chase Vent Stud Stud | City Series CB72EPV...
- Page 23 CITY SERIES installation Finish edges of drywall with trim or corner bead. Edge nish must not decrease opening area below 306in (4.25”x72”) 919-830b 01.23.18 City Series CB72EPV |...
- Page 24 Frame wall with nishing material If necessary, mark where the Cut hole in nishing material chase vent is located before around inside of chase vent. fixing dr wall in place Finish edges around opening 01.23.18 919-830b | City Series CB72EPV...
- Page 25 Follow paint manufacturer’s instructions for paint and primer application. No Screw Zones No screw zones (in shaded areas) as shown below must be adhered to. " 425mm " 87mm " " 13mm " " 13mm 191mm 298mm 9" 229mm City Series CB72EPV |...
- Page 26 Ensure that no material encroaches anywhere in the area of the glass as it is defined by the finishing lip surrounding the appliance. | City Series CB72EPV...
-
Page 27: Flush Install
1/2” . Adhere to “No Screw” zones painted on unit. Max 36” Glue can be used Hearth as an alternative. 1/2” drywall directly framing in front of unit 1/2” onto unit. plus nishing material. City Series CB72EPV |... -
Page 28: Maximum Tv Recess
Note: The TV mounting bracket can not be secured directly to the appliance. It must be secured to framing. The TV depicted in the picture may need to be higher depending on the style of TV mounting bracket used. The mounting bracket shown is a simple single strip TV secured to framing. | City Series CB72EPV... - Page 29 Firebox Glass will not be Screwdriver and remove bottom and - Finish up to trim on all 4 sides possible side trim pieces - Bottom edge should be ush with top surface of Inner Liner Panel Recess Install Example City Series CB72EPV |...
