Bellavista
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-377a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
®
Gas Fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
B41XTE
Owners &
Installation Manual
MODELS: B41XTE-NG10
B41XTE-LP10
www.regency-fire.com
10.01.15
Advertisement
Table of Contents
Related Manuals for Regency bellavista b41xte
Summary of Contents for Regency bellavista b41xte
- Page 1 ® Installation Manual Gas Fireplace MODELS: B41XTE-NG10 B41XTE-LP10 www.regency-fire.com WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The Bellavista™ ® B41XTE has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The Bellavista™ B41XTE has been approved by Warnock Hersey/ Intertek for both safety and efficiency.
-
Page 3: Manufactured Mobile Home Requirements
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. Ensure that structural members are not cut or weakened during installation. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 4: Table Of Contents
Two (2) 90 Elbows (Rigid Pipe 5" x 8") ....31 Accessories ..............68 Horizontal terminations ..........31 The Warranty: Limited Lifetime ........71 Three (3) 90 Elbows (Rigid Pipe 5" x 8") ....31 venting arrangements For Vertical TerminationS .32 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 5: Copy Of The Safety Decal
The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back up in the same room where the gas appliance is installed. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 6: Ma Code - Co Detector
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 7: Unit Dimensions With Vignette
UNIT DIMENSIONS WITH VIGNETTE 46 9/16" 1183mm 41 11/16" 1059mm 38 3/8" 974mm 2 7/16" 61mm 43 7/16" 1103mm 1 15/16" 49mm 35" WINDOW 39 7/8" 1012mm 21-15/16" SCREEN FRAME 533mm Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 8: Dimensions With Vignette And Vignette Finishing Trim
DIMENSIONS WITH VIGNETTE AND VIGNETTE FINISHING TRIM DIMENSIONS WITH FLUSH PANELS AND SAFETY SCREEN Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 9: Important Message
National Electrical Code, ANSI/ NFPA 70 or CSA C22.1 Canadian Electrical Code. 3) See general construction and assembly instructions. The appliance and vent should be enclosed. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 10: Installation Checklist
Vignette Front i. Vignette Finishing Trim (Optional) j. Safety Screen (Optional) and k. Flush Panels (Optional) 7) Final check. Diagram 1 Flat on Wall Flat on Wall Corner Recessed into Wall/Alcove Corner 10 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 11: Clearances
NOTE: A 16" deep (by the width of the appliance) non-combustible hearth pad is recommended when using hardwood flooring and carpet. Alcove Minimum Vent Clearances to Combustibles Horizontal Top 3" (76mm) Horizontal Side 2 " (51mm) Horizontal Bottom 2" (51mm) Vertical Vent 2" (51mm) Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 12: Mantel Clearances
(744mm) (624mm) Flush Note: The Vignette Finishing trim can not be used in conjunction with the flush panels and Safety Screen A separate 3 sided finishing trim is offered for this application. 12 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 13: Mantel Leg Clearances
FACEPLATE/VIGNETTE TRIM STEPPED FINISH Non-combustible Header (steel stud) 48-3/4" on edge (1238mm) Non-combustible Non-combustible Material 3 sided Vignette trim 4 sided Vignette Trim = 38-1/2" 41-3/4" (1060mm) 47-1/4" (1200mm) Framing Min. 3-1/2 Min. 3-1/2 (89mm) (89mm) Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 14: Framing With Vignette
Non-Combustible Top Height 13-1/2" (343mm) ** Important: Framing height requires consideration of the hearth depth. Dimension N = N + the thickness of the installed hearth. Optional Flush Panels and Safety Screen Vignette 14 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 15: Framing With Vignette Finishing Trim Finished Flush
Non-Combustible Drywall, Wood Header (or other facing) (steel stud) on edge Non-Combustible Header (steel stud) on edge Non-Combustible Facing 11" (279mm) dia. Hole through wall Vent. Top Vent Rear Vent Opening for gas connection Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 16: Wall Mount On / Off Switch And Remote Receiver Installation
11. Using the two (2) screws provided secure the cover plate to the Receiver. Low Voltage Junction Box Profl ame Receiver J-Box Receiver Slider Switch Wall Plate 10 ft. wire harness with 12 pin connector Diagram 1 16 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 17: Finishing
Alternatively, you can use J Style Trim or Metal Corner Bead to cover cut edges of the non-combustible facing material. Non-combustible Material J-style Trim or metal corner bead may be used to finish these edges Diagram 2 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 18: Top Facing Support (If Not Using Vignette Finishing Trim)
S c r e w Facing Material depth Top Facing Position Support 2-3/8" A,B,C 2-3/4" Nailing strip 3-1/8" supplied with Nail5.eps trim 1/2" to 1-7/8" Top Facing Support 18 | Regency Bellavista® B41XTE -10 Gas Fireplace Screw holes for Top Facing Support... -
Page 19: Conversion To Top Vent
3) From the inside of the firebox, remove the exhaust assembly by remov- ing the 10 screws. Before proceeding to Step 8, inspect condition of all gaskets. DO NOT install parts with damaged gaskets. Replace if necessary with spare gaskets supplied. Regency Bellavista® B41XTE -10 Gas Fireplace... - Page 20 Leave loose - until rear screws installed. See Diagram 3. Baffle Plate Diagram 3 Note: Reuse existing screw holes - do not make new holes. Tighten screws. Diagram 2 20 | Regency Bellavista® B41XTE -10 Gas Fireplace...
-
Page 21: Venting Introduction
6) From inside the firebox, install the baffle plate with 4 - 1/4" x 1/2 " AT 1-1/2 screws. Ensure all screws are tightly secure, but do not over tighten. Diagram 1 Baffle Plate Diagram 3 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 22: Exterior Vent Termination Requirements
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally 22 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 23: 5" X 8" Rigid Pipe
5” X 8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Description... - Page 24 • A Vent Guard is required when the AstroCap is installed above grade at 7 feet or lower. • The Simpson Dura-Vent and Selkirk Direct Temp horizontal termination caps cannot be used in any applications. • Only the AstroCap XL and Snorkels are certifi ed for horizontal terminations. 24 | Regency Bellavista® B41XTE -10 Gas Fireplace...
-
Page 25: Venting Arrangements For Horizontal Terminations
FLEX VENT OR RIGID PIPE 5" X 8" The diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes. -
Page 26: Horizontal Terminations
Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency may be used for Flex installations. 3) Regency Direct Vent System (Flex) is only approved for horizontal terminations. -
Page 27: Rigid Pipe 5" X 8
Vinyl Siding Standoff (Optional) Horizontal Termination Wall Thimble Pipe Length 90 Elbow Rigid Pipe Adaptor Pipe Length Rigid Pipe Adaptor IMPORTANT Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 28: Astrocap Xl & Rigid Rear Vent Kit
6" Galvanized Rigid Pipe 58DVA-06 8-1/2" Galvanized Pipe Extension 58DVA-08A 45º Galvanized Elbow 58DVA-E45 90ml MillPac 948-128 85-3/16 IMPORTANT Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. 28 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 29: Venting Arrangements
A wall thimble is mandatory for all horizontal terminations due to high temperatures. Horizontal (Feet) Restrictor 1-1/2 Open Set 3 Restrictor 2-1/2 Open Set 2 Restrictor 3-1/2 Open Set 1 47-1/2" (1207mm) Minimum Height Requirement Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 30: Rigid Pipe Venting Systems
Direct Vent Pro, ICC Excel and Selkirk ® Direct-Temp. AstroCap XL is a proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. 30 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 31: Horizontal Terminations
6' Min. 5' Max. 11' Min. 8' Max. elbows is required. 7' Min. 6" Max. 12' Min. 9' Max. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use rigid pipe adaptor #770-994. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 32: Venting Arrangements For Vertical Terminations
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting to 3-1/2" opening, 2-1/2"opening and to 1-1/2" opening. Note: Must use optional flue adapter when using Rigid Pipe (Part # 770-994). 32 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 33: Vertical Terminations
5' Min. 8' Min. 6' Max. 6' Min. 9' Min. 7' Max. 7' Min 10' Min. 8' Max. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use rigid pipe adaptor #770-994 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 34: Unit Installation With Horizontal Termination
Diagram 7 Diagram 2 IMPORTANT Diagram 1 Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. 34 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 35: Unit Installation With Horizontal Termination
Apply Mill-Pac to the outer flex Vinyl Siding pipe and slip it over the outer flue collar of the vent terminal at least 1-3/8"(35mm) and Wall Thimble Screws fasten with the 3 screws. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 36: Unit Installation With Vertical Termination
Important: Always check for gas leaks with a vent height may solve the problem. soap and water solution or gas leak detector. Do not use open flame for leak testing. 36 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 37: Pilot Adjustment
Note: Screw should be snug, but do not over tighten. 885 S.I.T. VALVE DESCRIPTION 1) 6 Stage flame adjustment 2) Pilot adjustment 3) Outlet Pressure Tap 4) Inlet Pressure Tap 5) Pilot Outlet 6) Main Gas Outlet 7) Main Gas Inlet Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 38: Brick Panel Installation
fi rebox wall (left side shown). Position the left brick panel in place and secure with the brick panel clip and screw removed from the fi rebox as shown below. 38 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-865a 11/09/09... -
Page 39: Optional Black Enamel Panel Installation
fi rebox. See diagram below. panel is centered when installed. Install the right side panel - secure with panel clip and 1 screw. See step 3. Top Panel Bracket Back Panel Right Side Panel Regency Bellavista® B41XTE -10 Gas Fireplace 05/29/12 918-866b... - Page 40 Stainless Steel Panels 5) Slide top panel under the top of the back and right side panels as shown below. 6) Install left side panel - repeat step 4. 40 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-866b 05/29/12...
-
Page 41: Log Set Installation
4) Place Log F on the right side of the burner, directly in front of Log A. Position Log F so it fi ts into the pin on the burner as shown below. Diagram 2 Vermiculite Diagram 4–Log F Regency Bellavista® B41XTE -10 Gas Fireplace 05/29/15 918-863... - Page 42 10) Slide the right side of Log G back until it touches the tab on the burner shown below. Tab on Burner Back of Log G Diagram 9 Diagram 6–Log G 42 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-863 05/29/15...
- Page 43 13) Position Log B on top of Log A. Log B fi ts into the pin in Log A. Ensure Log B sits upright 90 degrees with the left side of the log resting on the notch in Log E. See next 2 diagrams. Diagram 15 Diagram 12 Regency Bellavista® B41XTE -10 Gas Fireplace 05/29/15 918-863...
- Page 44 19) Test fi re to ensure proper lighting (make sure fl ame fl ows smoothly from one end of the burner to the other). If there is any fl ame hesitation, check that area for any blockage of the burner ports. 44 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-863 05/29/15...
-
Page 45: Wiring Diagram
CAUTION: Label all wires prior to disconnection Caution: Ensure that the wires do not touch any when servicing controls. Wiring errors can cause hot surfaces and are away from sharp edges. improper and dangerous operation. 1 of 10 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 46: Ac Adaptor Installation
2. Tuck any loose wires neatly underneath the firebox–inside the fireplace. Note: Ensure that wires do not touch the underside of the fire box (Keep wires away from heat as much as possible). AC adaptor Wire adaptor 46 | Regency Bellavista® B41XTE -10 Gas Fireplace 10/09/14 919-063... -
Page 47: Optional Fan Installation
8) Plug fan power cord into the Fan Control Module (FCM) then plug in the FCM. The switch is on when pushed to the left. (Shown in OFF position above) 09.30.14 919-439 Regency Bellavista® B41XTE -10 Gas Fireplace... - Page 48 48 | Regency Bellavista® B41XTE -10 Gas Fireplace...
-
Page 49: Wiring Diagram With Optional Fan
Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 50: Optional Wall Thermostat Installation
- see picture below. NOTE: When the remote receiver is set to <ON> position, the remote control transmitter and all of its features are now disabled. CAUTION Do not wire Thermostat wires to 120V wire. 50 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 51: Optional Accent Light Installation
fi rebox base. Left side shown, repeat for right side. Diagram 2: Slide burner assembly to the right and then remove. 8) Remove the 2 screws securing the rear log tray and lift out. Diagram 3 Diagram 3 Regency Bellavista® B41XTE -10 Gas Fireplace 09/23/09 918-864... - Page 52 Note: Glass is longer than diffuser for ease of removal. Note: Oils from hands will shorten the life of the bulbs, do not handle bulbs with bare hands. 19) Reverse steps 9 - 1. 52 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-864 09/23/09...
- Page 53 Green Extension Cord NOTE: Lights can be turned ON and OFF using the remote control AUX function on the hand held transmitter. See Remote Control instructions for details. No switch is required. Regency Bellavista® B41XTE -10 Gas Fireplace 06/16/15 918-864b...
-
Page 54: Flush Glass Door Installation
Slide the Finishing Trim Top over the Side Trim pieces and fit the bottom bracket slots over the screws. Tighten the 2 screws to secure in place. B41XTE B36XTE 43-3/8" 40-1/2" Edge of Unit Finishing Trim 37-5/8" 35-3/4" 54 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-791a 09/10/14... -
Page 55: Vignette Frame And Safety Screen Installation
4. Line up Vignette Frame to unit and hook the frame on to the appliance. Slide the top of the frame (See Detail AA above) on to the screws. (See Detail A shown above) 7. Reverse the steps to remove. 919-464 Regency Bellavista® B41XTE -10 Gas Fireplace 10.07.14... -
Page 56: Optional Vignette Inlay Installation
Inlay through the actual screen. NOTE: Ensure Inlay is in correct position before pushing studs through the safety screen. Stud Nut + washer (supplied) Completed Install Line up Inlay–Push studs on Inlay through screen 56 | Regency Bellavista® B41XTE -10 Gas Fireplace 05.21.15 919-559... -
Page 57: Vignette Finishing Trim Installation
Completed install Hook Vignette Faceplate brackets into place. Line up the screw holes on the finishing trim and Vignette Face- plate bracket with the unit–fasten with 2 screws on each side. Regency Bellavista® B41XTE -10 Gas Fireplace 07.22.15 919-588... -
Page 58: Flush Panel Installation
/ flush panel with the corresponding bracket clip on the inside top of the unit (see below). 3. Flip the hinges down to 90° - line up the lower premium front as shown below. 58 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 59: Safety Screen #509-929 Installation
MUST BE USED WITH OPTIONAL PREMIUM FRONT 1. Hook the safety screen frame onto the unit in locations shown below. 2. Gently lower screen on to glass door frame–two (2) magnets located on inside lower part of the screen frame will secure the screen to the glass door frame. 3. To remove–reverse steps. Magnet locations 07.23.15 919-589 SAFETY SCREEN INSTALLATION - MUST BE USED WITH OPTIONAL PREMIUM FRONT 1. Hook the safety screen frame onto the unit in locations shown below. 2. Gently lower screen on to glass door frame–two (2) magnets located on inside lower part of the screen frame will secure the screen to the glass door frame. 3. To remove–reverse steps. Magnet locations 07.23.15 919-589 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 60: Operating Instructions
The glass should be cleaned or the film will bake on and become very difficult to remove. Use a non-abrasive cleaner and NEVER clean the glass while it is hot. 60 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 61: Lighting Procedure
2. Press and release the ON/OFF button on the remote handheld transmit- ter (see Diagram 2). An audible beep should be heard from the receiver. ON/OFF Button Diagram 2 Remote shown in Manual Mode on Hi Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 62: Copy Of Lighting Plate Instructions
Utilisez l'interrupteur murale ON/OFF du Brûleur ou du contrôle à distance pour éteindre le brûleur. Si le service est effectuée–vous devez débrancher l'alimentation et coupez le gaz à l'unité. DO NOT REMOVE THIS INSTRUCTION PLATE 919-401a 62 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 63: Maintenance Instructions
Regency dealer only. Replacement glass (Part #940-362/P) is shipped already installed into Note: Never operate the appliance without the door frame. Reinstall as per Glass Door the glass properly secured in place. -
Page 64: Accent Light Bulb Replacement
Diagram 2: Slide burner assembly to the right and then remove. 11) Reverse steps 9 - 1. 8) Remove the 2 screws securing the rear log tray and lift out. Diagram 3 Diagram 3 64 | Regency Bellavista® B41XTE -10 Gas Fireplace 918-864 09/23/09... -
Page 65: Valve Replacement
Diagram 3 Diagram 3 11) Remove the 14 screws securing the valve tray assembly in place (Diagram 7) and then lift the entire assembly out Also remove the valve gasket. Diagram 7 Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 66: Main Assembly
Ignition Module 919-377 Manual 12) 948-259 Spring Handle Lever 13) 948-025 Spring Door Extension * Not available as a replacement part. 14) 940-362/P Ceramic Glass 15) 509-083 Door Frame Outerbox Assembly Firebox Assembly 66 | Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 67: Burner Assembly
911-030 Fan Control Module 910-100 Pilot Orifice - NG 910-101 Pilot Orifice - LP 946-721 AC Adaptor 911-010 Stepper Motor - NG 911-011 Stepper Motor - LP 15) 506-062 Base Tray 506-930 Log Set Regency Bellavista® B41XTE -10 Gas Fireplace... -
Page 68: Accessories
Part # Description 509-946 3-Sided Finishing Trim 506-901 Brick Panels - Standard Brown 506-902 Brick Panels - Standard Red 506-905 Brick Panels - Standard Charcoal Gray 506-908 Inner Panels - Black Enamel 68 | Regency Bellavista® B41XTE -10 Gas Fireplace... - Page 69 ACCESSORIES Part # Description 506-916 Flush panels 509-929 Safety Screen 509-925 Vignette Finishing Trim (4pcs) Vignette Inlay (not shown) Regency Bellavista® B41XTE -10 Gas Fireplace...
- Page 70 70 | Regency Bellavista® B41XTE -10 Gas Fireplace...
-
Page 71: The Warranty: Limited Lifetime
Conditions: Any part or parts of this unit which in our judgement show evidence of such defects will be repaired or replaced at Regency's option, through an accredited distributor or agent provid- ed that the defective part be returned to the distributor or agent Transportation Prepaid, if requested. - Page 72 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency Bellavista, AstroCap and SureFire™are trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2015, FPI Fireplace Products International Ltd. All rights reserved.
