Symbol Usage

This manual uses the following icon symbols with text to convey important information and tips.
WARNING
CAUTION
IMPORTANT
NOTE
Visual Action

Section Descriptions

1 Introduction
Introduction is a general description of system configurations of the EX 5/7/11RT, and its mechanical
electrical characteristics. Additionally there is an optional accessories section with important information on MGE
products that will enhance the performance of the EX 5/7/11RT. Please contact your MGE representative for
detailed information on these options.
2 Setup and Installation
Setup and Installation guides the user through tools and equipment required for connecting the EX 5/7/11RT and
battery installation or replacement. Included are assembly instructions, power cable connections with wire diagrams
for configuring the product to hardware specifications.
3 Operation
Operation describes the EX 5/7/11RT systems characteristics of indicators and controls, modes and specifications.
The user procedures include performing software programming that will maintain optimal performance.
4 Maintenance
Maintenance includes a troubleshooting guide of symptoms and possible solutions, hot swapping the Power
module, Battery module, and testing scenarios.
5 Appendix
Electrical and Mechanical specifications for the EX 5/7/11RT.
86-86000-00 B00
Indicates information provided to protect the user and service personnel
against safety hazards and/or possible equipment damage.
Indicates information provided to protect the user and service personnel
against possible equipment damage.
Indicates information provided as an operating instruction, or as an
operating tip.
Indicates information provided as an operating tip or an equipment feature.
