Battery Integration Kit with Casters

(Part number 86005)
Battery Integration Kit is a cart, designed to hold up to 8 modules. It has swivel wheels with brakes, leveling feet,
seismic floor mount panels, plates to lock modules and hardware included. Modules not included.
Figure 1-10: Typical Battery Integration kit with casters setup.
(Modules Not Included In Kit)
1.5.6

Input/Output Box

- I/O Box 5/7kVA Part number 86009
- I/O Box 11kVA Part number 86010
1 — 10

TRANSFORMER MODULE

(optional)

POWER MODULE

BATTERY MODULES

(up to 6)
OF F
O
