2.5

Communication Ports

EX 5/7/11RT Power Module provides 3 communication method's that can be used simultaneously:
◗ A female DB9
protocol. This COM Port is compatible with Solution Pac 2 to perform graceful shutdown.
◗ The Dry Contact Port
(formerly AS400) and more.
◗ The slot
1
is compatible with most MGE UPS SYSTEMS, INC. Transverse communication card (see
section 2.7.3 or check www.mgeups.com for the complete list of compatible cards).
2.5.1

Connecting the RS232 Communication Port

1. Connect the RS232
2. Connect the other end of the communications cable
EX 5/7/11RT.
The EX 5/7/11RT systems can now communicate with Solution Pac 2 for power management. UPS configuration
settings are done by Personal Solution Pac for Windows or through the LCD screen on the front panel (see section
3.2).
Figure 2-8: RS232 Communication Cable Connection.
5
86-86000-00 B00
5
provides RS232 communications using MGE Serial HID UPS Transfer (SHUT)
2
is used for basic signaling or for protection of IT systems like IBM iSeries
32
communications cable to the serial port on the computer.
32
1
2
32
to the RS232
Installation
Installation and User Manual
5
communications port on the
2 — 9
