MGE UPS Systems EX-11RT Installation And User Manual page 65

Table 5-3: Battery Recharge time to recover 90% of the rated backup time after discharge at full load.
EX 5RT
EX 7RT
EX 11RT
Table 5-4: Efficiency online (RL load) and batteries fully charged.
kVA / kW
5kVA /
4kWatts
7kVA /
4.9kWatts
11kVA /
8kWatts
Table 5-5: Efficiency online (RCD load) and batteries fully charged.
kVA / kW
5kVA /
4kWatts
7kVA /
4.9kWatts
11kVA /
8kWatts
Table 5-6: Efficiency on battery (RCD load).
kVA / kW
5kVA /
4kWatts
7kVA /
4.9kWatts
11kVA /
8kWatts
86-86000-00 B00
Configuration for Configuration for
2 hours backup time 4 hours backup time
7 hours 15 hours
5 hours 12 hours
7 hours 15 hours
25% 50% 75%
90 91 91
89 90 91
90 91 91
89 90 91
90 91 90
89 90 90
25% 50% 75%
90 91 91
89 91 91
90 91 91
89 91 91
90 92 91
89 91 90
25% 50% 75%
87 89 89
87 88 89
87 89 89
87 88 89
89 90 89
88 90 89
Configuration for
8 hours backup time
24 hours
20 hours
24 hours
100% Output load percentage
91 Output: 220 / 230 / 240 Volts
91 Output: 200 / 208 / 250 Volts
91 Output: 220 / 230 / 240 Volts
90 Output: 200 / 208 / 250 Volts
90 Output: 220 / 230 / 240 Volts
89 Output: 200 / 208 / 250 Volts
100% Output load percentage
92 Output: 220 / 230 / 240 Volts
91 Output: 200 / 208 / 250 Volts
92 Output: 220 / 230 / 240 Volts
91 Output: 200 / 208 / 250 Volts
91 Output: 220 / 230 / 240 Volts
90 Output: 200 / 208 / 250 Volts
100% Output load percentage
88 Output: 220 / 230 / 240 Volts
88 Output: 200 / 208 / 250 Volts
88 Output: 220 / 230 / 240 Volts
88 Output: 200 / 208 / 250 Volts
87 Output: 220 / 230 / 240 Volts
88 Output: 200 / 208 / 250 Volts
Appendix
Installation and User Manual
5 — 3
