2.4.3

Power, Battery, Transformer, and CLA Charger Module Rack Mounting

The following steps apply to all modules. For simplicity, only Power Module is shown.
Proceed as follows:
1. Attach both front mounting ear brackets
adjust the position of both front mounting brackets.)
2. Attach rear support brackets
26
3. Attach rails
4. Attach both rails to rear and front of rack with supplied flathead screws (as shown).
5. Use caution when sliding unit into rack. Temporarily secure unit to rack with thumb screws on front mounting
brackets.
6. Secure rear support brackets to rails.
Figure 2-6: Rack mounting of the Power Module onto the rails.
3
6
86-86000-00 B00
24
25
to module. These brackets prevent the module from sliding out of the rack.
together and secure with wing nuts, and finger tighten. (both sides).
4
4
6
to module with supplied screws. (For this step, it is possible to
4
4
2
5
1
Installation
Installation and User Manual
2
1
4
4
6
6
2 — 7
