EX 5/7/11RT Systems
1.5.8

CLA Charger Module

Extended back-up time (up to 8 hours at full load) requires a high power battery cabinet connected to the EX
5/7/11RT via the CLA Module.
IMPORTANT
Figure 1-12: CLA Module Contents and Connections.
CLA Module Contents
15A Utility
~
AC Source
(cable not included)
(see section 2.10 for cable
connection information)
Table 1-7: Battery backup time chart.
Total battery voltage : 240 VDC (20 x 12VDC, one string).
Battery Backup Time
2 hours
4 hours
8 hours
IMPORTANT
1 — 12
The CLA can not be used to charge the Battery Module (EXB). It is designed to
charge the customer provided high power battery cabinet.
CLA Module Quick Start
rme r
Tra nsfo
R T
E X
m
mgeu ps.co
www.
CLA
EX 5/7/11RT
EX 5RT
50 Ah
100 Ah
200 Ah
The battery capacity must be set within the UPS (5 Ah increment)
See UPS Personalization section 3.2.
Introduction
Tower Stand Expanders
Battery Power Cable
Battery Detection Cable
Typical High Power
Battery Cabinet
(not included)
(cable not included)
Recommended Batteries
EX 7RT
65 Ah
130 Ah
260 Ah
Transformer Rail Kit
41
Stabilizer Bracket
(4 screws included)
5 0 A
EX 11RT
100 Ah
200 Ah
400 Ah
86-86000-00 B00
