1.2.2

Rack Configuration

Figure 1-2: Rack Configuration with Power Module, Battery Module, and optional Transformer Module.
Standard Configuration
Table 1-6: System Dimensions and Weights.
Model
EX 5/7RT Power Module
EX 11RT Power Module
EXB 5/7RT Battery Module
EXB 11RT Battery Module
EX RT Transformer Module
CLA Charger Module
(*) For depth constraint applications, a shorter version of I/O Box for Power Module is available. With this
version of I/O Box, the overall depth of the EX 5/7/11RT is only 24.75" (629mm). Call Customer Care
Center at 1-800 438-7373 for more details.
86-86000-00 B00
POWER MODULE
(EX 5/7/11 RT)
BATTERY MODULE
(EXB 5/7/11 RT)
Dimensions (HxWxD)
(3U) 5.16" x 17.49" x 26.25"(*)
(131 x 444 x 667mm)
(3U) 5.16" x 17.49" x 26.25"(*)
(131 x 444 x 667mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.49" x 25"
(131 x 444 x 635mm)
(3U) 5.16" x 17.5" x 25
Introduction
Installation and User Manual
Configuration with Transformer
ns fo rm er
EX RT Tra
geups. com
www.m
EX 11 RT
OFF
geups. com
www.m
EX B RT
geups. com
www.m
Weights
49.6 lbs (22.5 kg)
60.6 lbs (27.6 kg)
142 lbs (64.5 kg)
151 lbs (68.5 kg)
173 lbs (78.5 kg)
26.5 lbs (12 kg)
TRANSFORMER MODULE
POWER MODULE
(EX 5/7/11 RT)
ON
BATTERY MODULE
(EXB 5/7/11 RT)
1 — 5
