EX 5/7/11RT Systems
1.5.7

Transformer Module - For use with EX 5/7/11RT Power Module

This module provides isolated 120/208/240Vac outputs.
Figure 1-11: Typical Transformer Module contents and connections.
EX RT Transformer Module Contents
AC NORMAL
INPUT
86-86000-00 B00
Transformer Module
Quick Start Manual
Transformer
Cable
TRANSFORMER MODULE
OUTPUT TO LOAD
Introduction
Installation and User Manual
Tower Stand Expanders
(4 screws included)
Transformer Rail Kit
BATTERY MODULE
EXB RT
POWER MODULE
EX 5/7/11RT
TRANSFORMER
MODULE EX RT
Stabilizer Bracket
41
1 — 11
