UPS Personalization

WARNING
IMPORTANT
3.2.1

Accessing personalization with front panel buttons

◗
Press "scroll down"
◗
Press the function button
LCD messages using the buttons now defined as select keys. See Tables: 3-1, 3-2, 3-3, and 3-4 for
settings.
Figure 3-2: Control Panel with scroll up and down buttons.
OFF
3 — 2
Before changing items from Tables, 3-1, 3-2, 3-3, and 3-4, the UPS system
must be turned OFF.
If specific settings are required, it is recommended to enter the UPS
personalization mode at this stage.
It is possible to enter this mode through the front panel buttons or the
Solution-Pac 2 software for Windows included in the MGE UPS
SYSTEMS, INC. Solution-Pac 2 CD-ROM.
21 22
and "scroll up"
22
placed under the "ENT" word to enter the set up mode and follow the
UPS SET UP
EXIT ENT
ON
21 22
Operation
function buttons together for more than 3 seconds.
