Furuno Felcom 250 Service Manual page 6

FELCOM 250/500
How to Update Communication Unit Software
The communication unit is update by following the steps below.
Preparation
1. Download the program, folder "FelcomUpdate_1650207-2.02" from the Technet.
2. Install "Java (any version)" onto your PC. The Java software is downloadable
from the following URL.
http://java.com/ja/download/windows_ie.jsp?locale=ja&host=java.com:80&bhcp=1
3. Ensure that "Obtain an IP address automatically" is selected in the Internet
Protocol. (New software does not need to set up TCP/IP on your PC.)
4. Connect your PC to the communication unit via LAN without a hub.
Update Procedure
1. Execute "FelcomUpdate.jar" in the FelcomUpdate folder. The software update
wizard is displayed.
2. Select Comm Unit.
3. Click Update. The software is uploaded automatically.
4. Wait until "Done" is displayed on the PC.
5. Ensure that the update is done correctly through Web MMI display: Main menu
> System information. Fig.2 shows the current program numbers of the
communication unit.
6. Read the handset software number: Info > Software. Fig.3 shows the current
software number of the handset.
Step 2
Fig.1 Software update wizard on PC Screen
Step 3
2/4
