Name
SRV_0_SIP_UA_CODE
C_PRIORITY
SRV_0_DTMF_SIGNAL
LING
SRV_0_SIP_UA_DATA
_SERVER_TYPE
SIP Server 1 - Settings regarding the Server that handles INFOPUSH.
SRV_1_SIP_UA_DATA
_DOMAIN
SRV_1_SIP_UA_DATA
_SERVER_PORT
SRV_1_SIP_UA_DATA
_PROXY_ADDR
SRV_1_SIP_UA_DATA
_PROXY_PORT
SRV_1_SIP_UA_DATA
_REREG_TIME
SRV_1_SIP_UA_DATA
_SERVER_IS_LOCAL
Type
Size
Permitted Values
uint8
5
Comma separated
list,terminated with
0xFF:
0 = PCMU (20 ms)
1 = PCMA (20 ms)
4 = G729AB
default is
"0,1,4,0xFF,0xFF"
uint8
1
0 = inband
1 = SIP-Info
2 = RTP Named
Event (see
RFC2833) (default)
uint8
1
positive integer
1 = SIP (default)
2 = Management
server
4 = INFOPUSH
(default)
uint8
32
IP address or URL,
double quoted
default is "" (Null)
uint16
1
port number
default is 5060
uint8
32
IP address or URL,
double quoted
default is "" (Null)
uint16
1
port number
default is 5060
uint16
1
positive integer,
units in seconds
default is 3600
uint8
1
0 = not local (default)
1 = local
Interpretation
Ranking of CodecTypes. Unused entries
must be 0xFF. Entries referring unsupported
entries are ignored.
Codecs are numbered according to
CodecCfg.c.
Parameter specifying how to transmit DTMF
signalling.
The type of server.
The server can be configured for more types
at once. For example, if used for both
Management and INFOPUSH the value
must be 6.
The domain name of the content server.
The port number of the content server.
The content server for INFOPUSH.
Listening port of the outbound proxy. Set to
0 if you are implementing SRV for failover.
Specified the time between re-registration at
registration server.
If set to 1, this server is regarded as being
directly available on the Internet, even
though STUN or other mechanisms have
resolved the system to be behind a
NAT-firewall.
Configuration File
A - 7
