Sensor (Lower Media Exit) Lag Jam - Lexmark X95x Series Service Manual

7558-xxx
Step Action and questions
POR the machine.
9
Does the error continue?

486.05 Sensor (lower media exit) lag jam

Step Action and questions
Check the media path.
1
Is the media path free of any
media fragments?
Check the sensor (lower media
2
exit) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
3. Touch Sensor (lower media
exit).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Check the sensor (lower media
3
exit) for proper connection.
Is the above component
properly connected?
Check the entrance/paddle motor
4
for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Entrance/paddle
motor.
Does the above component
operate properly?
Check the entrance/paddle motor
5
for proper connection.
Is the above component
properly connected?
Service Manual
2-236
Yes
Replace the finisher controller
PCBA.
Go to
"Finisher PCBA removal"
on page 4-356.
Yes
Go to step 2.
Go to Step 4.
Replace the sensor (lower media
exit).
Go to
"Sensor (lower media
exit) removal" on page 4-396.
Go to step 6.
Replace the entrance/paddle
motor.
Go to
"Stepper motor
(entrance/paddle) and belt
(entrance/paddle) removal" on
page 4-419.
No
Problem resolved
No
Remove any media or media
fragments.
Go to Step 3.
Replace connections.
Go to step 5.
Replace the connection.
