LPOD Outdoor Amplifier / Block Up Converter (BUC)
Introduction
1.4.7

Block Up Converter (BUC) Input

The LPOD translates an L-Band input carrier to the desired output frequency (C-, X-, or Ku-Band).
LO frequencies are as follows:
Band
C-Band
Insat C-Band
Ku-Band
Ku-Band-W
X-Band
Unlike most BUCs, no DC bias voltage should be provided on the center conductor of the L-Band
coax. In addition, the LPOD is available with an internal 10 MHz reference. As, such, no 10 MHz
reference is required on the center conductor of the L-Band coax. If a reference is provided on
the coax, the internal reference will detect and lock to it.
BUC C, Ku, X LO Frequencies
Frequency LO Frequency
5850 to 6650 MHz 4900 MHz
5950 to 6700 MHz 5000 MHz
6725 to 7025 MHz 5760 MHz
14.00 to 14.50 GHz 13.050 GHz
13.75 to 14.50 GHz 12.800 GHz
7900 to 8400 MHz 6950 MHz
Inverting
No
No
No
No
No
No
1–7
