Paper Detailed Settings Dialog Box

• Print Adjustment Pattern button
When this button is clicked, printing the adjustment pattern is executed. The Adjustment pattern setting dialog
box does not close even after executing the printing.
The adjustment values are printed at the top of each image. If both the Horizontal Axis and Vertical Axis are
configured, the adjustment value for the Horizontal Axis is displayed on the right and the adjustment value for the
Vertical Axis is displayed on the left.
Each of the setting values for the paper type, print mode, and output profile as well as the adjustment values con-
figured in the Color Settings sheet (color or monochrome) are printed at the bottom of the paper. However, the
adjustment values for the Curves are not printed.
• The job name when printing the adjustment pattern is "Original Image Name + Pattern-Print". For example, the print job
name for the image "ABC.jpg" is "ABC_Pattern-Print.jpg".
Note

Paper Detailed Settings Dialog Box

Paper Detailed Settings Dialog Box
This dialog box appears when you click the Advanced Settings button on the Main Sheet. You can set Drying Time
and Roll Paper Margin for Safety by media type.
• Drying Time
Between Pages
This sets the wait time for the ink to dry between each completely printed sheet and the output of the sheet.
Printer Default
None
30sec. / 1min. / 3min. / 5min. /
10min. / 30min. / 60min.
Between Scans
This sets the wait time between line scans during printing.
Printer Default
None
1sec. / 3sec. / 5sec. / 7sec. / 9sec.
262
• Roll Paper Margin for Safety
Near End Margin
Setting
The settings of the printer operating panel are applied.
The paper is ejected immediately after printing.
The sheet is ejected when the specified time after printing has elapsed.
Setting
The settings of the printer operating panel are applied.
The printing continues to the next line immediately after the last line.
The printing continues to the next line after the set time.
*For the media type that has problems, such as ink smears on the page or colors that seem un-
even during borderless printing etc., increase the value for this setting.
Details
Details
