iPF8400S
8
Lower the Ejection Guide and close the Top Cover.
• To load new paper in the printer at this point, see "Loading Rolls in the Printer."
Note • Clean inside the top cover before loading paper.
(See "Cleaning Inside the Top Cover.")

Removing the Roll Holder from Rolls

Removing the Roll Holder from Rolls

1
Lift the Holder Stopper lever (a) from the shaft side to un-
lock it. Holding the Holder Stopper at the position indica-
ted (b), remove it from the Roll Holder.
2
Remove the Roll Holder from the roll.
User's Guide
P.907
➔
Removing the Roll Holder from Rolls
P.510
➔
519
