Set Configuration Dialog Box

Set Configuration Dialog Box

Set Configuration Dialog Box
This dialog box appears when you click the Set Configuration button on the Main Sheet. You can set the adjustment
of image sharpness and image enlargement method.
• Sharpen
Performs adjustment of the sharpness (outline) settings.
• Image Enlargement Method
You can select the image enlargement method.
The following settings are available for the image enlargement method.
Nearest Neighbor
Bilinear
Bicubic
• Close Plug-in After Printing
When you place a checkmark here, the plug-in closes after printing finishes.
• If printing does not finish correctly because it was canceled or an error occurred, the plug-in does not close.
Note
• Output Method
You can select the output method.
The following settings are available for the output method.
Print
Save in mail box
Print after reception is complete
264
• Initialize all warning dialog boxes
When this is checked, all of the warning dialog boxes that have been set to "Do not show this screen again" be-
come displayed.
Setting
Performs simple enlargement.
Performs line vector enlargement.
Adjust pixels with calculation of elements such as a color or brightness of neighboring pixels.
Setting
Normal printing. The print job data is stored temporarily in the box as the job prints.
Saves the print data in the mail box.
If you select Save in mail box, you must specify Name of data to be saved.
When you place a checkmark here, you can print after saving jobs in the temporary storage
space. This cannot be used when Save in mail box is selected.
Details
Details
