Loading Rolls in the Printer

4
Insert the Holder Stopper from the left in the Roll Holder
as shown. Holding it at the position shown (b), push it
firmly in until the flange (a) of the Holder Stopper touch-
es the roll. Lock the Holder Stopper lever (c) by pushing
it down toward the shaft side.

Loading Rolls in the Printer

Loading Rolls in the Printer
Follow these steps to load rolls in the printer.
• Always load rolls when the printer is on. If the printer is off when you load a roll, the paper may not be advanced correctly
when you turn the printer on.
Important
• Before loading a roll, confirm whether the inside of the Top Cover or the Ejection Guide is soiled. If soiled, we recommend
cleaning in advance. (See "Cleaning Inside the Top Cover.")
1
Press the Load button.
2
Press ▲ or ▼ to select "Load Roll Paper", and then press the OK button.
•
Note
510
If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press ▲ or ▼ to select Yes, and then press the OK button. Remove the paper and go to the next step.
P.907
➔
