g Accessory Pocket
Stores printer accessories.

Media Take-up Unit(Optional)

Media Take-up Unit(Optional)

a Left Media Take-up Unit
Load the Rewind Spool here.
b Right Media Take-up Unit
Load the Rewind Spool here. Includes the Media Take-up Unit Power button, ▲ and ▼ buttons to advance or
rewind paper, and a power cord.
c Rewind Spool
Winds documents printed on rolls.
d 3-inch Adapter
When rewinding rolls with 3-inch paper cores, attach the adapter to the Rewind Spool.
e Media Take-up Sensor
A sensor for automatically rewinding rolls.
User's Guide
Main Unit
Weight
Media Take-up Unit(Optional)
