Set Configuration Dialog Box

Set Configuration Dialog Box

This dialog box appears when you click the Set Configuration button on the Main Sheet. You can set the adjustment
of image sharpness and image enlargement method.
• Sharpen
Performs adjustment of the sharpness (outline) settings.
• Image Enlargement Method
You can select the image enlargement method.
The following settings are available for the image enlargement method.
Setting
Nearest Neighbor
Bilinear
Bicubic
• Perform printing in the background
When you place a checkmark here, the plug-in performs printing with the Plug-In in the background.
• Close Plug-in After Printing
When you place a checkmark here, the plug-in closes after printing finishes.
• If printing does not finish correctly because it was canceled or an error occurred, the plug-in does not close.
Note
• Output Method
You can select the output method.
The following settings are available for the output method.
Setting
Print
Save in mail box
Print after reception is complete
User's Guide
Performs simple enlargement.
Performs line vector enlargement.
Adjust pixels with calculation of elements such as a color or brightness of neighboring pixels.
Normal printing. The print job data is stored temporarily in the box as the job prints.
Saves the print data in the mail box.
If you select Save in mail box, you must specify Name of data to be saved.
When you place a checkmark here, you can print after saving jobs in the temporary storage
space. This cannot be used when Save in mail box is selected.
Set Configuration Dialog Box
Details
Details
