Problems With The Printing Quality; Printing Is Faint - Canon imagePROGRAF iPF8400S User Manual

Printing is faint

Problems with the printing quality

Problems with the printing quality
Printing is faint ....................................................................................................................................................................... 934
Paper rubs against the printhead .................................................................................................................................. 935
The edges of the paper are dirty ................................................................................................................................... 935
The surface of the paper is dirty ................................................................................................................................... 936
The back side of the paper is dirty ............................................................................................................................... 936
Immediately after borderless printing, the trailing edge margin is soiled during regular printing .................................... 937
Printed colors are inaccurate ........................................................................................................................................... 937
Banding in different colors occurs ................................................................................................................................ 938
Colors in printed images are uneven ............................................................................................................................ 938
Image edges are blurred or white banding occurs ................................................................................................ 939
Setting the Blue Switch on the Platen .................................................................................................................... 939
The contrast becomes uneven during printing ........................................................................................................ 942
The length of printed images is inaccurate in the feeding direction ............................................................. 942
Images are printed crooked ............................................................................................................................................. 943
Documents are printed in monochrome ..................................................................................................................... 943
Line thickness is not uniform ........................................................................................................................................... 943
Lines or colors are misaligned ......................................................................................................................................... 944
Borders appear in borderless printing ......................................................................................................................... 944
Printing is faint
Printing is faint
Cause
You may be printing on the wrong
side of the paper.
The Printhead nozzles are clogged.
Because the printer was left without
ink tanks installed for some time,
ink has become clogged in the ink
supply system.
Paper is jammed inside the Top
Cover.
The ink was not dry when paper
934
was cut.
Print on the printing surface.
Print a test pattern to check the nozzles and see if they are clogged.
(See "Checking for Nozzle Clogging.")
To check for nozzles after printing, set Frequency in Nozzle Check in the Control Panel menu to a set-
ting other than Off.
Furthermore, to have a warning displayed depending on the result of the nozzle check, set Warning in
Nozzle Check in the Control Panel menu to On.
Note that when Warning is set to On, printing may stop depending on the content of the warning.
(See "Menu Settings.")
P.641
➔
After the ink tanks have been installed for 24 hours, run Head Cleaning B from the Control Panel.
(See "Cleaning the Printhead.")
➔
Follow the steps below to remove the jammed piece of paper inside the Top Cover.
1.
Open the Top Cover and make sure the Carriage is not over the Platen.
2. Remove any scraps of paper inside the Top Cover.
(See "Clearing Jammed Roll Paper.")
(See "Clearing a Jammed Sheet.")
3. Close the Top Cover.
Specify a longer drying period in the Control Panel menu, in Paper Details > Roll DryingTime.
(See "Menu Settings.")
P.641
➔
Corrective Action
P.884
➔
P.885
P.922
➔
P.925
➔
