24. Remove the seven screws on the main board to separate it from the sub pan.
To migrate the processor to the spare system board:
1.
Take the iLO label off the system board information label and place it over the iLO information
pull tab on the front panel.
2.
Install the spare system board.
CAUTION:
require replacing the system board.
3.
Install the processors and heat sink or processor heat sink module on the system board
("Installing a processor" (page
4.
Install all components removed from the failed system board.
CAUTION:
as detailed below.
5.
Install the access panel
130 Removal and replacement procedures
The pins on the processor socket are very fragile. Any damage to them may
50)).
Do not replace hot-plug hard drives until you have configured the RAID controller
("Removing and replacing the access panel" (page
106)).
HP Confidential
