Page 1: Software Version
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 NETGEAR, Inc. 350 Plumeria Dr. San Jose, CA 95124 USA 202-10530-03 May 2010...
Page 2: Statement Of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Page 3 Product and Publication Details Model Number: GSM7228PS and GSM752PS Publication Date: May 2010 Product Family: managed switch Product Name: ProSafe 7200 Series Stackable Managed Switches Home or Business Product: Business Language: English Publication Part Number: 202-10530-03 Publication Version Number v1.0, May 2010...
Page 4 v1.0, May 2010...
Page 5: Table Of Contents
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Contents About This Manual Audience ........................... ix About the Software ......................ix Scope .......................... x Product Concept ......................x Chapter 1 Using the Command-Line Interface Command Syntax ......................1-1 Command Conventions ....................1-2 Common Parameter Values ...................1-3 Unit/Slot/Port Naming Convention ..................1-3 Using the “No”...
Page 6 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Chapter 3 Switching Commands Port Configuration Commands ..................3-2 Spanning Tree Protocol (STP) Commands ..............3-10 VLAN Commands ......................3-30 Double VLAN Commands ....................3-45 Voice VLAN Commands ....................3-47 Provisioning (IEEE 802.1p) Commands ...............3-50 Protected Ports Commands ..................3-51 Private Group Commands ....................3-53 GARP Commands ......................3-55 GVRP Commands ......................3-58...
Page 7 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Chapter 4 Routing Commands Address Resolution Protocol (ARP) Commands ............4-1 IP Routing Commands ....................4-8 Router Discovery Protocol Commands ................4-20 Virtual LAN Routing Commands................... 4-24 DHCP and BOOTP Relay Commands .................4-25 IP Helper Commands ....................4-27 ICMP Throttling Commands ..................4-30 Chapter 5 Power Over Ethernet (PoE) Commands...
Page 8 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Dual Image Commands ....................7-4 System Information and Statistics Commands ...............7-6 Logging Commands .....................7-18 System Utility and Clear Commands ................7-24 Simple Network Time Protocol (SNTP) Commands .............7-34 DHCP Server Commands ....................7-40 DNS Client Commands ....................7-55 Packet Capture Commands ..................7-61 Serviceability Packet Tracing Commands ..............7-63 Cable Test Command ....................7-83...
Page 9 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 QoS ..........................9-16 Routing/IPv6 Routing ....................9-17 Multicast ........................9-21 Stacking ........................9-23 Technologies ........................9-23 O/S Support ........................9-26 Chapter 10 Captive Portal Commands Capitve Portal Global Commands ................10-1 Captive Portal Configuration Commands ..............10-5 Captive Portal Status Commands ................10-14 Captive Portal Client Connection Commands ............10-19 Captive Portal Interface Commands ................10-23 Captive Portal Local User Commands ...............10-24...
Page 10: Prosafe 7200 Managed Switches Cli Manual, Software Version 8
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 v1.0, May 2010...
Page 11: About This Manual
About This Manual This document describes command-line interface (CLI) commands you use to view and configure 7200 Series Switches software. You can access the CLI by using a direct connection to the serial port or by using telnet or SSH over a remote network connection. Note: This document contains both standalone and stacking commands.
Page 12: Scope
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Scope The software encompasses both hardware and software support. The software is partitioned to run in the following processors: • CPU – This code runs the networking device management portfolio and controls the overall networking device hardware.
Page 13 • Scope. This manual is written for the 7200 Series Switches. Product Version ProSafe 7200 Series Stackable Managed Switches Manual Publication Date May 2010 Note: Product updates are available on the NETGEAR, Inc. website at http://kbserver.netgear.com -xiii v1.0, May 2010...
Page 14: How To Print This Manual
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 How to Print This Manual To print this manual, your computer must have the free Adobe Acrobat reader installed in order to view and print PDF files. The Acrobat reader is available on the Adobe Web site at http://www.adobe.com.
Page 15: Using The Command-Line Interface
Chapter 1 Using the Command-Line Interface The command-line interface (CLI) is a text-based way to manage and monitor the system. You can access the CLI by using a direct serial connection or by using a remote logical connection with telnet or SSH. This chapter describes the CLI syntax, conventions, and modes.
Page 16: Command Conventions
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 • network parms is the command name. • <ipaddr> and <netmask> are parameters and represent required values that you must enter after you type the command keywords. • [gateway] is an optional parameter, so you are not required to enter a value in place of the parameter. The CLI Command Reference lists each command by the command name and provides a brief description of the command.
Page 17: Common Parameter Values
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Common Parameter Values Parameter values might be names (strings) or numbers.To use spaces as part of a name parameter, enclose the name value in double quotes. For example, the expression “System Name with Spaces”...
Page 18: Using The "No" Form Of A Command
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The slot number has two uses. In the case of physical ports, it identifies the card containing the ports. In the case of logical and CPU ports it also identifies the type of interface or port. Table 3.
Page 19: Managed Switch Modules
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 shutdown configuration command reverses the shutdown of an interface. Use the command without the keyword no to re-enable a disabled feature or to enable a feature that is disabled by default. Only the configuration commands are available in the no form. Managed Switch Modules Managed switch software consists of flexible modules that can be applied in various combinations to develop advanced Layer 2/3/4+ products.
Page 20 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 5. CLI Command Modes Command Mode Prompt Mode Description User EXEC Contains a limited set of commands to view Switch> basic system information. Privileged EXEC Allows you to issue any EXEC command, enter Switch# the VLAN mode, or enter the Global Configuration mode.
Page 21 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 5. CLI Command Modes (continued) Command Mode Prompt Mode Description TACACS Config Switch (Tacacs)# Contains commands to configure properties for the TACACS servers. DHCP Pool Switch (Config dhcp-pool)# Contains the DHCP server IP address pool Config configuration commands.
Page 22 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 6. CLI Mode Access and Exit (continued) Command Mode Access Method Exit or Access Previous Mode Class-Map From the Global Config mode, To exit to the Global Config mode, enter exit. To Config enter return to the Privileged EXEC mode, enter Ctrl-...
Page 23: Command Completion And Abbreviation
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 6. CLI Mode Access and Exit (continued) Command Mode Access Method Exit or Access Previous Mode DHCPv6 Pool From the Global Config mode, To exit to the Global Config mode, enter exit. To Config enter return to the Privileged EXEC mode, enter Ctrl-...
Page 24: Cli Line-Editing Conventions
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 7. CLI Error Messages Message Text Description Command not found / Incomplete Indicates that you did not enter the required keywords or values. command. Use ? to list commands. Ambiguous command Indicates that you did not enter enough letters to uniquely identify the command.
Page 25: Using Cli Help
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 8. CLI Editing Conventions (continued) Key Sequence Description Exit Go to next lower command prompt List available commands, keywords, or parameters Using CLI Help Enter a question mark (?) at the command prompt to display the commands available in the current mode.
Page 26: Accessing The Cli
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 (switch) #show m? mac-addr-table mac-address-table monitor Accessing the CLI You can access the CLI by using a direct console connection or by using a telnet or SSH connection from a remote management host. For the initial connection, you must use a direct connection to the console port.
Page 27: Stacking Commands
Chapter 2 Stacking Commands The Stacking Commands chapter includes the following sections: • “Dedicated Port Stacking” on page 2-1 • “Front Panel Stacking Commands” on page 2-10 Note: The commands in this chapter are in one of two functional groups: Note: Show commands display switch settings, statistics, and other information.
Page 28 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 member This command configures a switch. The <unit> is the switch identifier of the switch to be added/removed from the stack. The <switchindex> is the index into the database of the supported switch types, indicating the type of the switch being preconfigured.
Page 29 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 switch renumber This command changes the switch identifier for a switch in the stack. The <oldunit> is the current switch identifier on the switch whose identifier is to be changed. The <newunit> is the updated value of the switch identifier.
Page 30 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 slot This command configures a slot in the system. The <unit/slot> is the slot identifier of the slot. The <cardindex> is the index into the database of the supported card types, indicating the type of the card being preconfigured in the specified slot.
Page 31: Set Slot Power
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If a card or other module is present in the slot, this administrative mode will effectively be applied to the contents of the slot. If the slot is empty, this administrative mode will be applied to any module that is inserted into the slot.
Page 32: Reload (Stack)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no set slot power This command unconfigures the power mode of the slot(s) and prohibits power from being supplied to a card located in the slot. If you specify [all], the command prohibits power to all slots, otherwise the command prohibits power to the slot identified by <unit/slot>.
Page 33: Show Supported Cardtype
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Pluggable Cards are pluggable or non-pluggable in the slot. Power Down Indicates whether the slot can be powered down. If you supply a value for <unit/slot>, the following additional information appears: Term Definition Inserted Card...
Page 34: Show Switch
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show switch This command displays information about all units in the stack or a single unit when you specify the unit value. Format show switch [<unit>] Mode Privileged EXEC Term Definition Switch The unit identifier assigned to the switch.
Page 35: Show Supported Switchtype
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Switch Status The switch status. Possible values are OK, Unsupported, Code Mismatch, Config Mismatch, or Not Present. Switch The switch description. Description Expected Code The expected code version. Version Detected Code The version of code running on this switch.
Page 36: Front Panel Stacking Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Model Identifier The model identifier for the supported switch type. Switch The description for the supported switch type. Description Front Panel Stacking Commands This section describes the commands you use to view and configure front panel stacking information.
Page 37: Show Stack-Port Counters
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 For Each Interface: Term Definition Unit The unit number. Interface The slot and port numbers. Configured Stack Stack or Ethernet. Mode Running Stack Stack or Ethernet. Mode Link Status Status of the link. Link Speed Speed (Gbps) of the stack port link.
Page 38: Show Stack-Port Diag
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show stack-port diag This command shows front panel stacking diagnostics for each port and is only intended for Field Application Engineers (FAEs) and developers. An FAE will advise on the necessity to run this command and capture this information.
Page 39 Chapter 3 Switching Commands This chapter describes the switching commands available in the managed switch CLI. The Switching Commands chapter includes the following sections: • “Port Configuration Commands” on page 3-2 • “show port description” on page 3-9 • “VLAN Commands” on page 3-30 •...
Page 40: Switching Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 • “LLDP-MED Commands” on page 3-168 • “Denial of Service Commands” on page 3-179 • “MAC Database Commands” on page 3-191 • “ISDP Commands” on page 3-193 Warning: The commands in this chapter are in one of three functional groups: •...
Page 41: Interface Vlan
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 interface vlan This command gives you access to to the vlan virtual interface mode, which allows certain port configurations (for example, the IP address) to be applied to the VLAN interface. Type a question mark (?) after entering the interface configuration mode to see the available options.
Page 42: Auto-Negotiate All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no auto-negotiate This command disables automatic negotiation on a port. Note: Automatic sensing is disabled when automatic negotiation is disabled. auto-negotiate all Format no auto-negotiate Mode Interface Config This command enables automatic negotiation on all ports. Default enabled Format...
Page 43 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Use the mtu command to set the maximum transmission unit (MTU) size, in bytes, for frames that ingress or egress the interface. You can use the mtu command to configure jumbo frame support for physical and port-channel (LAG) interfaces.
Page 44: Shutdown All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format shutdown Mode Interface Config no shutdown This command enables a port. Format no shutdown Mode Interface Config shutdown all This command disables all ports. Note: You can use the shutdown all command on physical and port-channel (LAG) interfaces, but not on VLAN routing interfaces.
Page 45: Speed All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 speed This command sets the speed and duplex setting for the interface. Format speed {<100 | 10> <half-duplex | full-duplex>} Mode Interface Config Acceptable Definition Values 100h 100BASE-T half duplex 100f 100BASE-T full duplex 10BASE-T half duplex 10BASE-T full duplex...
Page 46: Show Port Protocol
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Interface Valid slot and port number separated by forward slashes. Type If not blank, this field indicates that this port is a special type of port. The possible values are: •...
Page 47: Show Port Description
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show port description This command displays the port description for every port. Format show port description <unit/slot/port> Mode Privileged EXEC Term Definition Interface Valid slot and port number separated by forward slashes Description Shows the port description configured via the “description”...
Page 48: Spanning Tree Protocol (Stp) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Spanning Tree Protocol (STP) Commands This section describes the commands you use to configure Spanning Tree Protocol (STP). STP helps prevent network loops, duplicate messages, and network instability. spanning-tree This command sets the spanning-tree operational mode to enabled. Default enabled Format...
Page 49: Spanning-Tree Bpduflood
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default enabled Format no spanning-tree bpdufilter default Mode Global Config spanning-tree bpduflood Use this command to enable BPDU Flood on the interface. Default disabled Format spanning-tree bpduflood Mode Interface Config no spanning-tree bpduflood Use this command to disable BPDU Flood on the interface.
Page 50: Spanning-Tree Bpdumigrationcheck
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no spanning-tree bpduguard Mode Global Config spanning-tree bpdumigrationcheck Use this command to force a transmission of rapid spanning tree (RSTP) and multiple spanning tree (MSTP) BPDUs. Use the <unit/slot/port> parameter to transmit a BPDU from a specified interface, or use the all keyword to transmit BPDUs from all interfaces.
Page 51: Spanning-Tree Configuration Revision
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 spanning-tree configuration revision This command sets the Configuration Identifier Revision Level for use in identifying the configuration that this switch is currently using. The Configuration Identifier Revision Level is a number in the range of 0 to 65535. Default Format spanning-tree configuration revision <0-65535>...
Page 52: Spanning-Tree Forceversion
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 spanning-tree forceversion This command sets the Force Protocol Version parameter to a new value. Default 802.1s Format spanning-tree forceversion <802.1d | 802.1s | 802.1w> Mode Global Config • Use 802.1d to specify that the switch transmits ST BPDUs rather than MST BPDUs (IEEE 802.1d functionality supported).
Page 53: Spanning-Tree Guard
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no spanning-tree forward-time This command sets the Bridge Forward Delay parameter for the common and internal spanning tree to the default value. Format no spanning-tree forward-time Mode Global Config spanning-tree guard This command selects whether loop guard or root guard is enabled on an interface.
Page 54: Spanning-Tree Max-Hops
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no spanning-tree max-age This command sets the Bridge Max Age parameter for the common and internal spanning tree to the default value. Format no spanning-tree max-age Mode Global Config spanning-tree max-hops This command sets the MSTP Max Hops parameter to a new value for the common and internal spanning tree.
Page 55 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If you specify the cost option, the command sets the path cost for this port within a multiple spanning tree instance or the common and internal spanning tree instance, depending on the <mstid>...
Page 56: Spanning-Tree Mst Instance
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no spanning-tree mst <mstid> <cost | external-cost | port-priority> Mode Interface Config spanning-tree mst instance This command adds a multiple spanning tree instance to the switch. The parameter <mstid> is a number within a range of 1 to 4094, that corresponds to the new instance ID to be added.
Page 57: Spanning-Tree Mst Vlan
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If you specify 0 (defined as the default CIST ID) as the <mstid>, this command sets the Bridge Priority parameter to a new value for the common and internal spanning tree. The bridge priority value is a number within a range of 0 to 61440.
Page 58: Spanning-Tree Port Mode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no spanning-tree mst vlan This command removes an association between a multiple spanning tree instance and one or more VLANs so that the VLAN(s) are again associated with the common and internal spanning tree. Format no spanning-tree mst vlan <mstid>...
Page 59: Spanning-Tree Edgeport All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no spanning-tree port mode all This command sets the Administrative Switch Port State for all ports to disabled. Format no spanning-tree port mode all Mode Global Config spanning-tree edgeport all This command specifies that every port is an Edge Port within the common and internal spanning tree.
Page 60: Show Spanning-Tree
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no spanning-tree bpduforwarding This command will cause the STP BPDU packets received from the network to be dropped if STP is disabled. Format no spanning-tree bpduforwarding Mode Global Config show spanning-tree This command displays spanning tree settings for the common and internal spanning tree.
Page 61: Show Spanning-Tree Brief
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Root Port Derived value. Bridge Forward Delay Hello Time Configured value of the parameter for the CST. Bridge Hold Minimum time between transmission of Configuration Bridge Protocol Data Units Time (BPDUs).
Page 62: Show Spanning-Tree Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show spanning-tree interface This command displays the settings and parameters for a specific switch port within the common and internal spanning tree. The <unit/slot/port> is the desired switch port. The following details are displayed on execution of the command.
Page 63: Show Spanning-Tree Mst Port Detailed
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show spanning-tree mst port detailed This command displays the detailed settings and parameters for a specific switch port within a particular multiple spanning tree instance. The parameter <mstid> is a number that corresponds to the desired existing multiple spanning tree instance.
Page 64 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Transitions Into The number of times this interface has transitioned into loop inconsistent state. Loop Inconsistent State Transitions Out The number of times this interface has transitioned out of loop inconsistent state. of Loop Inconsistent State...
Page 65: Show Spanning-Tree Mst Port Summary
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Topology Value of flag in next Configuration Bridge Protocol Data Unit (BPDU) transmission Change indicating if a topology change is in progress for this port. Acknowledgem Hello Time The hello time in use for this port. Edge Port The configured value indicating if this port is an edge port.
Page 66: Show Spanning-Tree Mst Summary
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition MST Instance ID The MST instance associated with this port. Interface Valid slot and port number separated by forward slashes. STP Mode Indicates whether spanning tree is enabled or disabled on the port. Type Currently not used.
Page 67: Show Spanning-Tree Summary
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show spanning-tree summary This command displays spanning tree settings and parameters for the switch. The following details are displayed on execution of the command. Format show spanning-tree summary Mode • Privileged EXEC •...
Page 68: Vlan Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition VLAN Identifier The VLANs associated with the selected MST instance. Associated Identifier for the associated multiple spanning tree instance or “CST” if associated with Instance the common and internal spanning tree. VLAN Commands This section describes the commands you use to configure VLAN settings.
Page 69: Vlan Acceptframe
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan This command creates a new VLAN and assigns it an ID. The ID is a valid VLAN identification number (ID 1 is reserved for the default VLAN). The vlan-list contains VlanId's in range <1- 4093>.
Page 70: Vlan Ingressfilter
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no vlan acceptframe This command resets the frame acceptance mode for the interface to the default value. Format no vlan acceptframe Mode Interface Config vlan ingressfilter This command enables ingress filtering. If ingress filtering is disabled, frames received with VLAN IDs that do not match the VLAN membership of the receiving interface are admitted and forwarded to ports that are members of that VLAN.
Page 71: Vlan Name
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan name This command changes the name of a VLAN. The name is an alphanumeric string of up to 32 characters, and the ID is a valid VLAN identification number. ID range is 1-4093. Default •...
Page 72: Vlan Participation All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan participation all This command configures the degree of participation for all interfaces in a VLAN. The ID is a valid VLAN identification number. Format vlan participation all {exclude | include | auto} <1-4093> Mode Global Config You can use the following participation options:...
Page 73: Vlan Port Ingressfilter All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no vlan port acceptframe all This command sets the frame acceptance mode for all interfaces to Admit All. For Admit All mode, untagged frames or priority frames received on this interface are accepted and assigned the value of the interface VLAN ID for this port.
Page 74: Vlan Port Tagging All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no vlan port pvid all This command sets the VLAN ID for all interfaces to 1. Format no vlan port pvid all Mode Global Config vlan port tagging all This command configures the tagging behavior for all interfaces in a VLAN to enabled. If tagging is enabled, traffic is transmitted as tagged frames.
Page 75 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan protocol group add protocol This command adds the <protocol> to the protocol-based VLAN identified by <groupid>. A group may have more than one protocol associated with it. Each interface and protocol combination can only be associated with one group.
Page 76: Protocol Vlan Group
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default none Format protocol group <groupid> <vlanid> Mode VLAN Config no protocol group This command removes the <vlanid> from this protocol-based VLAN group that is identified by this <groupid>. Format no protocol group <groupid> <vlanid> Mode VLAN Config protocol vlan group...
Page 77: Protocol Vlan Group All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 protocol vlan group all This command adds all physical interfaces to the protocol-based VLAN identified by <groupid>. You can associate multiple interfaces with a group, but you can only associate each interface and protocol combination with one group.
Page 78: Vlan Tagging
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan tagging This command configures the tagging behavior for a specific interface in a VLAN to enabled. If tagging is enabled, traffic is transmitted as tagged frames. If tagging is disabled, traffic is transmitted as untagged frames.
Page 79: Vlan Association Mac
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan association mac This command associates a MAC address to a VLAN. Format vlan association mac <macaddr> <1-4093> Mode VLAN database no vlan association mac This command removes the association of a MAC address to a VLAN. Format no vlan association mac <macaddr>...
Page 80: Show Vlan Brief
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show vlan <vlanid> Mode • Privileged EXEC • User EXEC Term Definition VLAN ID There is a VLAN Identifier (VID) associated with each VLAN. The range of the VLAN ID is 1 to 3965.
Page 81: Show Vlan Port
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show vlan brief Mode • Privileged EXEC • User EXEC Term Definition VLAN ID There is a VLAN Identifier (vlanid) associated with each VLAN. The range of the VLAN ID is 1 to 3965. VLAN Name A string associated with this VLAN as a convenience.
Page 82: Show Vlan Association Subnet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition GVRP May be enabled or disabled. Default Priority The 802.1p priority assigned to tagged packets arriving on the port. show vlan association subnet This command displays the VLAN associated with a specific configured IP-Address and net mask. If no IP address and net mask are specified, the VLAN associations of all the configured IP- subnets are displayed.
Page 83: Double Vlan Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Double VLAN Commands This section describes the commands you use to configure double VLAN (DVLAN). Double VLAN tagging is a way to pass VLAN traffic from one customer domain to another through a Metro Core in a simple and cost effective manner.
Page 84: Mode Dvlan-Tunnel
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 mode dvlan-tunnel Use this command to enable Double VLAN Tunneling on the specified interface. Note: When you use the mode dvlan-tunnel command on an interface, it becomes a service provider port. Ports that do not have double VLAN tunneling enabled are customer ports.
Page 85: Voice Vlan Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition EtherType A 2-byte hex EtherType to be used as the first 16 bits of the DVLAN tunnel. There are three different EtherType tags. The first is 802.1Q, which represents the commonly used value of 0x8100.
Page 86: Voice Vlan (Interface Config)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Also the inherent isolation provided by VLANs ensures that inter-VLAN traffic is under management control and that network- attached clients cannot initiate a direct attack on voice components. QoS-based on IEEE 802.1P class of service (CoS) uses classification and scheduling to sent network traffic from the switch in a predictable manner.
Page 87: Voice Vlan Data Priority
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Parameter Description none Allow the IP phone to use its own configuration to send untagged voice traffic. untagged Configure the phone to send untagged voice traffic. no voice vlan (Interface Config) Use this command to disable the Voice VLAN capability on the interface.
Page 88: Provisioning (Ieee 802.1P) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Voice VLAN Interface Mode The admin mode of the Voice VLAN on the interface. Voice VLAN ID The Voice VLAN ID Voice VLAN Priority The do1p priority for the Voice VLAN on the port. Voice VLAN Untagged The tagging option for the Voice VLAN traffic.
Page 89: Protected Ports Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Protected Ports Commands This section describes commands you use to configure and view protected ports on a switch. Protected ports do not forward traffic to each other, even if they are on the same VLAN. However, protected ports can forward traffic to all unprotected ports in their group.
Page 90: Switchport Protected (Interface Config)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 switchport protected (Interface Config) Use this command to add an interface to a protected port group. The <groupid> parameter identifies the set of protected ports to which this interface is assigned. You can only configure an interface as protected in one group.
Page 91: Private Group Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Name An optional name of the protected port group. The name can be up to 32 alphanumeric characters long, including blanks. The default is blank. List of Physical List of ports, which are configured as protected for the group identified with <groupid>. If Ports no port is configured as protected for this group, this field is blank.
Page 92: Private-Group Name
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 By default, a port does not belong to any private group. A port cannot be in more than one private group. An error message should return when that occurred. To change a port’s private group, first the port must be removed from its private group.
Page 93: Garp Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no private-group name This command is used to remove the specified private group. Format private-group name <privategroup-name> Mode Global Config show private-group This command displays the private groups’ information. Format show private-groupname [<private-group-name>|<private-group- id>|port <unit/slot/port>] Mode Priviledged EXEC...
Page 94: Set Garp Timer Join
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set garp timer join This command sets the GVRP join time for one port (Interface Config mode) or all (Global Config mode) and per GARP. Join time is the interval between the transmission of GARP Protocol Data Units (PDUs) registering (or re-registering) membership for a VLAN or multicast group.
Page 95: Set Garp Timer Leaveall
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no set garp timer leave This command sets the GVRP leave time on all ports or a single port to the default and only has an effect when GVRP is enabled. Format no set garp timer leave Mode...
Page 96: Gvrp Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show garp Mode • Privileged EXEC • User EXEC Term Definition GMRP Admin Mode The administrative mode of GARP Multicast Registration Protocol (GMRP) for the system. GVRP Admin Mode The administrative mode of GARP VLAN Registration Protocol (GVRP) for the system.
Page 97: Set Gvrp Interfacemode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no set gvrp adminmode Mode Privileged EXEC set gvrp interfacemode This command enables GVRP on a single port (Interface Config mode) or all ports (Global Config mode). Default disabled Format set gvrp interfacemode Mode •...
Page 98: Gmrp Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Join Timer The interval between the transmission of GARP PDUs registering (or re-registering) membership for an attribute. Current attributes are a VLAN or multicast group. There is an instance of this timer on a per-Port, per-GARP participant basis. Permissible values are 10 to 100 centiseconds (0.1 to 1.0 seconds).
Page 99 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default disabled Format set gmrp adminmode Mode Privileged EXEC no set gmrp adminmode This command disables GARP Multicast Registration Protocol (GMRP) on the system. Format no set gmrp adminmode Mode Privileged EXEC set gmrp interfacemode This command enables GARP Multicast Registration Protocol on a single interface (Interface Config mode) or all interfaces (Global Config mode).
Page 100: Show Gmrp Configuration
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no set gmrp interfacemode Mode • Interface Config • Global Config show gmrp configuration This command displays Generic Attributes Registration Protocol (GARP) information for one or all interfaces. Format show gmrp configuration {<unit/slot/port> | all} Mode •...
Page 101: Port-Based Network Access Control Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show mac-address-table gmrp This command displays the GMRP entries in the Multicast Forwarding Database (MFDB) table. Format show mac-address-table gmrp Mode Privileged EXEC Term Definition Mac Address A unicast MAC address for which the switch has forwarding and or filtering information. The format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for example 01:23:45:67:89:AB.
Page 102: Dot1X Guest-Vlan
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format clear radius statistics Mode Privileged EXEC dot1x guest-vlan This command configures VLAN as guest vlan on a per port basis. The command specifies an active VLAN as an IEEE 802.1x guest VLAN. The range is 1 to the maximumVLAN ID supported by the platform.
Page 103: Dot1X Max-Req
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dot1x max-req This command sets the maximum number of times the authenticator state machine on this port will transmit an EAPOL EAP Request/Identity frame before timing out the supplicant. The <count> value must be in the range 1 - 10.
Page 104 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dot1x port-control This command sets the authentication mode to use on the specified port. Select force- unauthorized to specify that the authenticator PAE unconditionally sets the controlled port to unauthorized. Select force-authorized to specify that the authenticator PAE unconditionally sets the controlled port to authorized.
Page 105: Dot1X Re-Authenticate
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no dot1x port-control all This command sets the authentication mode on all ports to the default value. Format no dot1x port-control all Mode Global Config dot1x re-authenticate This command begins the re-authentication sequence on the specified port. This command is only valid if the control mode for the specified port is “auto”...
Page 106: Dot1X Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dot1x system-auth-control Use this command to enable the dot1x authentication support on the switch. While disabled, the dot1x configuration is retained and can be changed, but is not activated. Default disabled Format dot1x system-auth-control Mode...
Page 107: No Dot1X Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Tokens Definition supp-timeout The value, in seconds, of the timer used by the authenticator state machine on this port to timeout the supplicant. The supp-timeout must be a value in the range 1 - 65535. server-timeout The value, in seconds, of the timer used by the authenticator state machine on this port to timeout the authentication server.
Page 108: Dot1X User
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default Format dot1x unauthenticated-vlan <vlan id> Mode Interface Config no dot1x unauthenticated-vlan This command resets the unauthenticated-vlan associated with the port to its default value. Format no dot1x unauthenticated-vlan Mode Interface Config dot1x user This command adds the specified user to the list of users with access to the specified port or all ports.
Page 109: Show Authentication Methods
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show authentication methods This command displays information about the authentication methods. Format show authentication methods Mode Privileged EXEC The following is an example of this command: Login Authentication Method Lists ________________________________ Console_Default: None Network_Default:Local Enable Authentication Lists...
Page 110 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Administrative Indicates whether authentication control on the switch is enabled or disabled. Mode VLAN Indicates whether assignment of an authorized port to a RADIUS assigned VLAN is Assignment allowed (enabled) or not (disabled). Mode If you use the optional parameter summary {<unit/slot/port>...
Page 111 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Backend Current state of the backend authentication state machine. Possible values are Request, Authentication Response, Success, Fail, Timeout, Idle, and Initialize. When MAC-based authentication State is enabled on the port, this parameter is deprecated. Quiet Period The timer used by the authenticator state machine on this port to define periods of time in which it will not attempt to acquire a supplicant.
Page 112 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Maximum Users The maximum number of clients that can get authenticated on the port in the MAC-based dot1x authentication mode. This value is used only when the port control mode is not MAC-based.
Page 113: Show Dot1X Clients
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Port The interface whose statistics are displayed. EAPOL Frames The number of valid EAPOL frames of any type that have been received by this Received authenticator. EAPOL Frames The number of EAPOL frames of any type that have been transmitted by this Transmitted authenticator.
Page 114: Show Dot1X Users
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show dot1x clients {<unit/slot/port> | all} Mode Privileged EXEC Term Definition Logical The logical port number associated with a client. Interface Interface The physical port to which the supplicant is associated. User Name The user name used by the client to authenticate to the server.
Page 115: Storm-Control Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Storm-Control Commands This section describes commands you use to configure storm-control and view storm-control configuration information. A traffic storm is a condition that occurs when incoming packets flood the LAN, which creates performance degredation in the network. The Storm-Control feature protects against this condition.
Page 116: Storm-Control Broadcast Level
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default enabled Format storm-control broadcast Mode Interface Config no storm-control broadcast Use this command to disable broadcast storm recovery mode for a specific interface. Format no storm-control broadcast Mode Interface Config storm-control broadcast level Use this command to configure the broadcast storm recovery threshold for an interface as a percentage of link speed and enable broadcast storm recovery.
Page 117: Storm-Control Broadcast Rate
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 storm-control broadcast rate Use this command to configure the broadcast storm recovery threshold for an interface in packets per second. If the mode is enabled, broadcast storm recovery is active, and if the rate of L2 broadcast traffic ingressing on an interface increases beyond the configured threshold, the traffic is dropped.
Page 118 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no storm-control broadcast Mode Global Config storm-control broadcast level (Global) This command configures the broadcast storm recovery threshold for all interfaces as a percentage of link speed and enables broadcast storm recovery. If the mode is enabled, broadcast storm recovery is active, and if the rate of L2 broadcast traffic ingressing on an interface increases beyond the configured threshold, the traffic will be dropped.
Page 119: Storm-Control Multicast
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format storm-control broadcast rate <0-14880000> Mode Global Config no storm-control broadcast rate This command sets the broadcast storm recovery threshold to the default value for all interfaces and disables broadcast storm recovery. Format no storm-control broadcast rate Mode...
Page 120: Storm-Control Multicast Level
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 storm-control multicast level This command configures the multicast storm recovery threshold for an interface as a perecentage of link speed and enables multicast storm recovery mode. If the mode is enabled, multicast storm recovery is active, and if the rate of L2 multicast traffic ingressing on an interface increases beyond the configured threshold, the traffic will be dropped.
Page 121 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no storm-control multicast rate Mode Interface Config storm-control multicast (Global) This command enables multicast storm recovery mode for all interfaces. If the mode is enabled, multicast storm recovery is active, and if the rate of L2 multicast traffic ingressing on an interface increases beyond the configured threshold, the traffic will be dropped.
Page 122: Storm-Control Unicast
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no storm-control multicast level This command sets the multicast storm recovery threshold to the default value for all interfaces and disables multicast storm recovery. Format no storm-control multicast level Mode Global Config storm-control multicast rate (Global) Use this command to configure the multicast storm recovery threshold for all interfaces in packets per second.
Page 123: Storm-Control Unicast Level
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default disabled Format storm-control unicast Mode Interface Config no storm-control unicast This command disables unicast storm recovery mode for an interface. Format no storm-control unicast Mode Interface Config storm-control unicast level This command configures the unicast storm recovery threshold for an interface as a percentage of link speed, and enables unicast storm recovery.
Page 124: Storm-Control Unicast Rate
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 storm-control unicast rate Use this command to configure the unicast storm recovery threshold for an interface in packets per second. If the mode is enabled, unicast storm recovery is active, and if the rate of L2 broadcast traffic ingressing on an interface increases beyond the configured threshold, the traffic is dropped.
Page 125 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no storm-control unicast Mode Global Config storm-control unicast level (Global) This command configures the unicast storm recovery threshold for all interfaces as a percentage of link speed, and enables unicast storm recovery. If the mode is enabled, unicast storm recovery is active, and if the rate of unknown L2 unicast (destination lookup failure) traffic ingressing on an interface increases beyond the configured threshold, the traffic will be dropped.
Page 126 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no storm-control unicast rate This command sets the multicast storm recovery threshold to the default value for an interface and disables multicast storm recovery. Format no storm-control unicast rate Mode Global Config storm-control flowcontrol This command enables 802.3x flow control for the switch and only applies to full-duplex mode ports.
Page 127: Port-Channel/Lag (802.3Ad) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show storm-control This command displays switch configuration information. If you do not use any of the optional parameters, this command displays global storm control configuration parameters: • Broadcast Storm Control Mode may be enabled or disabled. The factory default is disabled. •...
Page 128 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 shares traffic based upon the source and destination MAC address.Assign the port-channel (LAG) VLAN membership after you create a port-channel. If you do not assign VLAN membership, the port-channel might become a member of the management VLAN which can result in learning and switching issues.
Page 129: Deleteport (Global Config)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 addport This command adds one port to the port-channel (LAG). The interface is a logical unit/slot/port number or a group ID of a configured port-channel. Note: Before adding a port to a port-channel, set the physical mode of the port. For more information, see “speed”...
Page 130: Lacp Admin Key
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lacp admin key Use this command to configure the administrative value of the key for the port-channel. The value range of <key> is 0 to 65535. Default 0x8000 Format lacp admin key <key> Mode Interface Config Note: This command is only applicable to port-channel interfaces.
Page 131: Lacp Actor Admin
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lacp collector max delay Use this command to configure the default port-channel collector max delay. Format no lacp collector max-delay Mode Interface Config lacp actor admin Use this command to configure the LACP actor admin parameters. lacp actor admin key Use this command to configure the administrative value of the LACP actor admin key.
Page 132: Lacp Actor Admin State Individual
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lacp actor admin state individual Use this command to set LACP actor admin state to individual. Format lacp actor admin state individual Mode Interface Config Note: This command is only applicable to physical interfaces. no lacp actor admin state individual Use this command to set the LACP actor admin state to aggregation.
Page 133: Lacp Actor Admin State Passive
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lacp actor admin state longtimeout Use this command to set the LACP actor admin state to short timeout. Format no lacp actor admin state longtimeout Mode Interface Config Note: This command is only applicable to physical interfaces. lacp actor admin state passive Use this command to set the LACP actor admin state to passive.
Page 134: Lacp Actor Port Priority
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lacp actor port priority Use this command to configure the priority value assigned to the Aggregation Port. The valid range for <priority> is 0 to 255. Default 0x80 Format lacp actor port priority <priority> Mode Interface Config Note: This command is only applicable to physical interfaces.
Page 135: Lacp Partner Admin Key
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lacp actor system priority Use this command to configure the priority value associated with the Actor’s SystemID. Format no lacp actor system priority Mode Interface Config lacp partner admin key Use this command to configure the administrative value of the Key for the protocol partner.
Page 136: Lacp Partner Admin State Longtimeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: This command is only applicable to physical interfaces. no lacp partner admin state individual Use this command to set the LACP partner admin state to aggregation. Format no lacp partner admin state individual Mode Interface Config lacp partner admin state longtimeout...
Page 137: Lacp Partner Admin State Passive
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lacp partner admin state passive Use this command to set the LACP partner admin state to passive. Format lacp partner admin state passive Mode Interface Config Note: This command is only applicable to physical interfaces. no lacp partner admin state passive Use this command to set the LACP partner admin state to active.
Page 138: Lacp Partner Port Priority
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lacp partner port id Use this command to set the LACP partner port id to the default. Format no lacp partner portid Mode Interface Config lacp partner port priority Use this command to configure the LACP partner port priority. The valid range for <priority> is 0 to 255.
Page 139 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lacp partner system id Use this command to configure the 6-octet MAC Address value representing the administrative value of the Aggregation Port’s protocol Partner’s System ID. The valid range of <system-id> is 00:00:00:00:00:00 - FF:FF:FF:FF:FF.
Page 140: Port-Channel Static
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: This command is only applicable to physical interfaces. no lacp partner system priority Use this command to configure the default administrative value of priority associated with the Partner’s System ID. Format no lacp partner system priority Mode...
Page 141: Port Lacpmode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port lacpmode This command enables Link Aggregation Control Protocol (LACP) on a port. Default enabled Format port lacpmode Mode Interface Config no port lacpmode This command disables Link Aggregation Control Protocol (LACP) on a port. Format no port lacpmode Mode...
Page 142: Port Lacptimeout (Global Config)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port lacptimeout (Interface Config) This command sets the timeout on a physical interface of a particular device type (actor or partner) to either long or short timeout. Default long Format port lacptimeout {actor | partner} {long | short} Mode Interface Config no port lacptimeout...
Page 143 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port-channel adminmode This command enables a port-channel (LAG). This command sets every configured port-channel with the same administrative mode setting. Format port-channel adminmode all Mode Global Config no port-channel adminmode This command disables a port-channel (LAG). This command clears every configured port- channel with the same administrative mode setting.
Page 144 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 hashing-mode This command sets the hashing algorithm on Trunk ports. The command is available in the interface configuration mode for a port-channel. The mode range is in the range 1-6 as follows: 1.
Page 145 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Load-balancing is not supported on every device. The range of options for load-balancing may vary per device. Default Format port-channel load-balance { 1 | 2 | 3 | 4 | 5 | 6 } {<unit/slot/ port>...
Page 146: Port-Channel Name
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port-channel name This command defines a name for the port-channel (LAG). The interface is a logical unit/slot/port for a configured port-channel, and <name> is an alphanumeric string up to 15 characters. Format port-channel name {<logical unit/slot/port>...
Page 147: Show Lacp Partner
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Parameter Description Admin Key The administrative value of the Key. Port Priority The priority value assigned to the Aggregation Port. Admin State The administrative values of the actor state as transmitted by the Actor in LACPDUs. show lacp partner Use this command to display LACP partner attributes.
Page 148: Show Port-Channel
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 For each port-channel the following information is displayed: Term Definition Logical The unit/slot/port of the logical interface. Interface Port-channel The name of port-channel (LAG) interface. Name Link-State Shows whether the link is up or down. Trap Flag Shows whether trap flags are enabled or disabled.
Page 149: Show Port-Channel System Priority
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show port-channel This command displays an overview of all port-channels (LAGs) on the switch. Format show port-channel {<logical unit/slot/port> | all} Mode • Privileged EXEC • User EXEC Term Definition Logical Valid slot and port number separated by forward slashes.
Page 150: Port Mirroring
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Port Mirroring Port mirroring, which is also known as port monitoring, selects network traffic that you can analyze with a network analyzer, such as a SwitchProbe device or other Remote Monitoring (RMON) probe.
Page 151: No Monitor
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no monitor session <session-id> [{source interface <unit/slot/port> | destination interface <unit/slot/port> | mode}] Mode Global Config no monitor This command removes all the source ports and a destination port for the and restores the default value for mirroring session mode for all the configured sessions.
Page 152: Static Mac Filtering
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Admin Mode Indicates whether the Port Mirroring feature is enabled or disabled for the session identified with <session-id>. The possible values are Enabled and Disabled. Probe Port Probe port (destination port) for the session identified with <session-id>. If probe port is not set then this field is blank.
Page 153 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 • Multicast MAC and source ports and destination ports (max=20) Format macfilter <macaddr> <vlanid> Mode Global Config no macfilter This command removes all filtering restrictions and the static MAC filter entry for the MAC address <macaddr>...
Page 154 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no macfilter adddest This command removes a port from the destination filter set for the MAC filter with the given <macaddr> and VLAN of <vlanid>. The <macaddr> parameter must be specified as a 6- byte hexadecimal number in the format of b1:b2:b3:b4:b5:b6.
Page 155 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 macfilter addsrc This command adds the interface to the source filter set for the MAC filter with the MAC address of <macaddr> and VLAN of <vlanid>. The <macaddr> parameter must be specified as a 6-byte hexadecimal number in the format of b1:b2:b3:b4:b5:b6.
Page 156: Show Mac-Address-Table Static
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The <vlanid> parameter must identify a valid VLAN. Format no macfilter addsrc all <macaddr> <vlanid> Mode Global Config show mac-address-table static This command displays the Static MAC Filtering information for all Static MAC Filters. If you select <all>, all the Static MAC Filters in the system are displayed.
Page 157: Dhcp Snooping Configuration Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Mac Address A unicast MAC address for which the switch has forwarding and or filtering information. As the data is gleaned from the MFDB, the address will be a multicast address. The format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for example 01:23:45:67:89:AB.
Page 158: Ip Dhcp Snooping Verify Mac-Address
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default disabled Format ip dhcp snooping vlan <vlan-list> Mode Global Config no ip dhcp snooping vlan Use this command to disable DHCP Snooping on VLANs. Format no ip dhcp snooping vlan <vlan-list> Mode Global Config ip dhcp snooping verify mac-address...
Page 159: Ip Dhcp Snooping Database Write-Delay
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default local Format ip dhcp snooping database {local|tftp://hostIP/filename} Mode Global Config ip dhcp snooping database write-delay Use this command to configure the interval in seconds at which the DHCP Snooping database will be persisted.
Page 160: Ip Verify Binding
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no ip dhcp snooping binding <mac-address> Mode Global Config ip verify binding Use this command to configure static IP source guard (IPSG) entries. Format ip verify binding <mac-address> vlan <vlan id> <ip address> interface <interface id>...
Page 161: Ip Dhcp Snooping Log-Invalid
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no ip dhcp snooping limit Mode Interface Config ip dhcp snooping log-invalid Use this command to control the logging DHCP messages filtration by the DHCP Snooping application. Default disabled Format ip dhcp snooping log-invalid Mode Interface Config...
Page 162: Ip Verify Source
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no ip dhcp snooping trust Mode Interface Config ip verify source Use this command to configure the IPSG source ID attribute to filter the data traffic in the hardware. Source ID is the combination of IP address and MAC address. Normal command allows data traffic filtration based on the IP address.
Page 163: Show Ip Dhcp Snooping Binding
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Interface The interface for which data is displayed. Trusted If it is enabled, DHCP snooping considers the port as trusted. The factory default is disabled. Log Invalid Pkts If it is enabled, DHCP snooping application logs invalid packets on the specified interface.
Page 164: Show Ip Dhcp Snooping Database
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition MAC Address Displays the MAC address for the binding that was added. The MAC address is the key to the binding database. IP Address Displays the valid IP address for the binding rule. VLAN The VLAN for the binding rule.
Page 165: Show Ip Dhcp Snooping Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 agent url: /10.131.13.79:/sai1.txt write-delay: 5000 show ip dhcp snooping statistics Use this command to list statistics for DHCP Snooping security violations on untrusted ports. Format show ip dhcp snooping statistics Mode •...
Page 166: Clear Ip Dhcp Snooping Binding
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 1/0/14 1/0/15 1/0/16 1/0/17 1/0/18 1/0/19 1/0/20 clear ip dhcp snooping binding Use this command to clear all DHCP Snooping bindings on all interfaces or on a specific interface. Format clear ip dhcp snooping binding [interface <unit/slot/port>] Mode •...
Page 167: Show Ip Source Binding
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Filter Type Is one of two values: • ip-mac: User has configured MAC address filtering on this interface. • ip: Only IP address filtering on this interface. IP Address IP address of the interface MAC Address If MAC address filtering is not configured on the interface, the MAC Address field is...
Page 168: Dynamic Arp Inspection Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Example: The following shows example CLI display output for the command. (switch) #show ip source binding MAC Address IP Address Type Vlan Interface ----------------- --------------- ------------- ----- ------------- 00:00:00:00:00:08 1.2.3.4 dhcp-snooping 1/0/1 00:00:00:00:00:09 1.2.3.4...
Page 169: Ip Arp Inspection Validate
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no ip arp inspection vlan vlan-list Mode Global Config ip arp inspection validate Use this command to enable additional validation checks like source-mac validation, destination- mac validation, and ip address validation on the received ARP packets. Each command overrides the configuration of the previous command.
Page 170: Ip Arp Inspection Trust
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip arp inspection vlan logging Use this command to disable logging of invalid ARP packets on a list of comma-separated VLAN ranges. Format no ip arp inspection vlan vlan-list logging Mode Global Config ip arp inspection trust...
Page 171: Ip Arp Inspection Filter
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default 15 pps for rate and 1 second for burst-interval Format ip arp inspection limit {rate pps [burst interval seconds] | none} Mode Interface Config no ip arp inspection limit Use this command to set the rate limit and burst interval values for an interface to the default values of 15 pps and 1 second, respectively.
Page 172: Arp Access-List
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 arp access-list Use this command to create an ARP ACL. Format arp access-list acl-name Mode Global Config no arp access-list Use this command to delete a configured ARP ACL. Format no arp access-list acl-name Mode Global Config permit ip host mac host...
Page 173: Show Ip Arp Inspection
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip arp inspection Use this command to display the Dynamic ARP Inspection global configuration and configuration on all the VLANs. With the vlan-list argument (i.e. comma separated VLAN ranges), the command displays the global configuration and configuration on all the VLANs in the given VLAN list.
Page 174: Show Ip Arp Inspection Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip arp inspection statistics Use this command to display the statitstics of the ARP packets processed by Dynamic ARP Inspection. Give the vlan-list argument and the command displays the statistics on all DAI-enabled VLANs in that list.
Page 175: Clear Ip Arp Inspection Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 clear ip arp inspection statistics Use this command to reset the statistics for Dynamic ARP Inspection on all VLANs. Default none Format clear ip arp inspection statistics Mode Privileged EXEC show ip arp inspection interfaces Use this command to display the Dynamic ARP Inspection configuration on all the DAI-enabled interfaces.
Page 176: Igmp Snooping Configuration Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Untrusted show arp access-list Use this command to display the configured ARP ACLs with the rules. Giving an ARP ACL name as the argument will display on ly the rules in that ARP ACL. Format show arp access-list [acl-name] Mode...
Page 177 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If an interface has IGMP Snooping enabled and you enable this interface for routing or enlist it as a member of a port-channel (LAG), IGMP Snooping functionality is disabled on that interface. IGMP Snooping functionality is re-enabled if you disable routing or remove port-channel (LAG) membership from an interface that has IGMP Snooping enabled.
Page 178: Set Igmp Interfacemode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set igmp interfacemode This command enables IGMP Snooping on all interfaces. If an interface has IGMP Snooping enabled and you enable this interface for routing or enlist it as a member of a port-channel (LAG), IGMP Snooping functionality is disabled on that interface.
Page 179: Set Igmp Groupmembership-Interval
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no set igmp fast-leave This command disables IGMP Snooping fast-leave admin mode on a selected interface. Format no set igmp fast-leave Mode Interface Config Format no set igmp fast-leave <vlan_id> Mode VLAN Config set igmp groupmembership-interval This command sets the IGMP Group Membership Interval time on a VLAN, one interface or all...
Page 180: Set Igmp Maxresponse
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set igmp maxresponse This command sets the IGMP Maximum Response time for the system, or on a particular interface or VLAN. The Maximum Response time is the amount of time in seconds that a switch will wait after sending a query on an interface because it did not receive a report for a particular group in that interface.
Page 181: Set Igmp Mrouter
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format set igmp mcrtrexpiretime <0-3600> Mode • Global Config • Interface Config Format set igmp mcrtrexpiretime <vlan_id> <0-3600> Mode VLAN Config no set igmp mcrtrexpiretime This command sets the Multicast Router Present Expiration time to 0. The time is set for the system, on a particular interface or a VLAN.
Page 182: Set Igmp Mrouter Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set igmp mrouter interface This command configures the interface as a multicast router interface. When configured as a multicast router interface, the interface is treated as a multicast router interface in all VLANs. Default disabled Format...
Page 183: Show Igmpsnooping
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show igmpsnooping This command displays IGMP Snooping information. Configured information is displayed whether or not IGMP Snooping is enabled. Format show igmpsnooping [<unit/slot/port> | <vlan_id>] Mode Privileged EXEC When the optional arguments <unit/slot/port> or <vlan_id> are not used, the command displays the following information: Term Definition...
Page 184: Show Igmpsnooping Mrouter Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 When you specify a value for <vlan_id>, the following information appears: Term Definition VLAN ID The VLAN ID. IGMP Snooping Indicates whether IGMP Snooping is active on the VLAN. Admin Mode Fast Leave Indicates whether IGMP Snooping Fast-leave is active on the VLAN.
Page 185: Igmp Snooping Querier Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show igmpsnooping mrouter vlan <unit/slot/port> Mode Privileged EXEC Term Definition Interface The port on which multicast router information is being displayed. VLAN ID The list of VLANs of which the interface is a member. show mac-address-table igmpsnooping This command displays the IGMP Snooping entries in the MFDB table.
Page 186: Set Igmp Querier
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 This section describes commands used to configure and display information on IGMP Snooping Queriers on the network and, separately, on VLANs. set igmp querier Use this command to enable IGMP Snooping Querier on the system, using Global Config mode, or on a VLAN.
Page 187: Set Igmp Querier Query-Interval
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set igmp querier query-interval Use this command to set the IGMP Querier Query Interval time. It is the amount of time in seconds that the switch waits before sending another general query. Default disabled Format...
Page 188: Set Igmp Querier Version
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set igmp querier version Use this command to set the IGMP version of the query that the snooping switch is going to send periodically. Default Format set igmp querier version <1-2> Mode Global Config no set igmp querier version...
Page 189: Show Igmpsnooping Querier
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show igmpsnooping querier Use this command to display IGMP Snooping Querier information. Configured information is displayed whether or not IGMP Snooping Querier is enabled. Format show igmpsnooping querier [{detail | vlan <vlanid>}] Mode Privileged EXEC When the optional argument <vlanid>...
Page 190 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description Last Querier Indicates the IP address of the most recent Querier from which a Query was received. Address Last Querier Indicates the IGMP version of the most recent Querier from which a Query was received Version on this VLAN.
Page 191: Port Security Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no set mld maxresponse Mode • Global Config • Interface Config Default Format set mld mcrtexpiretime <0-3600> Mode • Global Config • Interface Config Format no set mld mcrtexpiretime Mode •...
Page 192: Port-Security Max-Dynamic
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port-security This command enables port locking at the system level (Global Config) or port level (Interface Config) Default disabled Format port-security Mode • Global Config • Interface Config no port-security This command disables port locking for one (Interface Config) or all (Global Config) ports. Format no port-security Mode...
Page 193: Port-Security Max-Static
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port-security max-static This command sets the maximum number of statically locked MAC addresses allowed on a port. Default Format port-security max-static <maxvalue> Mode Interface Config no port-security max-static This command sets maximum number of statically locked MAC addresses to the default value. Format no port-security max-static Mode...
Page 194: Port-Security Mac-Address Move
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 port-security mac-address move This command converts dynamically locked MAC addresses to statically locked addresses. Format port-security mac-address move Mode Interface Config show port-security This command displays the port-security settings. If you do not use a parameter, the command displays the settings for the entire system.
Page 195: Lldp (802.1Ab) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition MAC Address MAC Address of dynamically locked MAC. show port-security static This command displays the statically locked MAC addresses for port. Format show port-security static <unit/slot/port> Mode Privileged EXEC Term Definition MAC Address...
Page 196 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lldp transmit Use this command to enable the LLDP advertise capability. Default enabled Format lldp transmit Mode Interface Config no lldp transmit Use this command to return the local data transmission capability to the default. Format no lldp transmit Mode...
Page 197: Lldp Transmit-Tlv
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 multiplier on the transmit interval that sets the TTL in local data LLDPDUs. The multiplier range is 2-10. The <reinit-seconds> is the delay before re-initialization, and the range is 1-0 seconds. Default •...
Page 198: Lldp Transmit-Mgmt
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lldp transmit-tlv Use this command to remove an optional TLV from the LLDPDUs. Use the command without parameters to remove all optional TLVs from the LLDPDU. Format no lldp transmit-tlv [sys-desc] [sys-name] [sys-cap] [port-desc] Mode Interface Config lldp transmit-mgmt...
Page 199: Lldp Notification-Interval
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lldp notification Use this command to disable notifications. Default disabled Format no lldp notification Mode Interface Config lldp notification-interval Use this command to configure how frequently the system sends remote data change notifications. The <interval>...
Page 200: Clear Lldp Remote-Data
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 clear lldp remote-data Use this command to delete all information from the LLDP remote data table, including MED- related information. Format clear lldp remote-data Mode Global Config show lldp Use this command to display a summary of the current LLDP configuration. Format show lldp Mode...
Page 201: Show Lldp Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Transmit Shows whether the interface transmits LLDPDUs. Receive Shows whether the interface receives LLDPDUs. Notify Shows whether the interface sends remote data change notifications. TLVs Shows whether the interface sends optional TLVs in the LLDPDUs. The TLV codes can be 0 (Port Description), 1 (System Name), 2 (System Description), or 3 (System Capability).
Page 202: Show Lldp Remote-Device
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Errors The number of invalid LLDP frames received on the port. Ageouts Total number of times a complete remote data entry was deleted for the port because the Time to Live interval expired. TLV Discards The number of TLVs discarded.
Page 203 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 (switch) #show lldp remote-device all LLDP Remote Device Summary Local Interface RemID Chassis ID Port ID System Name ------- ------- -------------------- ------------------ ------------------ 00:FC:E3:90:01:0F 00:FC:E3:90:01:11 00:FC:E3:90:01:0F 00:FC:E3:90:01:12 00:FC:E3:90:01:0F 00:FC:E3:90:01:13 00:FC:E3:90:01:0F 00:FC:E3:90:01:14 00:FC:E3:90:01:0F 00:FC:E3:90:03:11 00:FC:E3:90:01:0F...
Page 204 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Port ID The port number that transmitted the LLDPDU. System Name The system name of the remote device. System Describes the remote system by identifying the system name and versions of hardware, Description operating system, and networking software supported in the device.
Page 205: Show Lldp Local-Device
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show lldp local-device Use this command to display summary information about the advertised LLDP local data. This command can display summary information or detail for each interface. Format show lldp local-device {<unit/slot/port> | all} Mode Privileged EXEC Term...
Page 206: Lldp-Med Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition System Shows which of the supported system capabilities are enabled. Capabilities Enabled Management The type of address and the specific address the local LLDP agent uses to send and Address receive information.
Page 207: Lldp Med Confignotification
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lldp med confignotification Use this command to configure all the ports to send the topology change notification. Default enabled Format lldp med confignotification Mode Interface Config no ldp med confignotification Use this command to disable notifications. Format no lldp med confignotification Mode...
Page 208: Lldp Med All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lldp med transmit-tlv Use this command to remove a TLV. Format no lldp med transmit-tlv [capabilities] [network-policy] [ex-pse] [ex-pd] [location] [inventory] Mode Interface Config lldp med all Use this command to configure LLDP-MED on all the ports Format lldp med all Mode...
Page 209: Lldp Med Faststartrepeatcount
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lldp med faststartrepeatcount Use this command to set the value of the fast start repeat count. [count] is the number of LLDP PDUs that will be transmitted when the product is enabled. The range is 1 to 10. Default Format lldp med faststartrepeatcount [count]...
Page 210: Show Lldp Med
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no lldp med transmit-tlv Use this command to remove a TLV. Format no lldp med transmit-tlv all [capabilities] [network-policy] [ex-pse] [ex-pd] [location] [inventory] Mode Global Config show lldp med Use this command to display a summary of the current LLDP MED configuration. Format show lldp med Mode...
Page 211: Show Lldp Med Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show lldp med interface Use this command to display a summary of the current LLDP MED configuration for a specific interface. <unit/slot/port> indicates a specific physical interface. all indicates all valid LLDP interfaces.
Page 212: Show Lldp Med Local-Device Detail
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 TLV Codes: 0- Capabilities, 1- Network Policy 2- Location, 3- Extended PSE 4- Extended Pd, 5- Inventory --More-- or (q)uit (Switch) #show lldp med interface 1/0/2 Interface Link configMED operMED ConfigNotify TLVsTx --------- ------ --------- --------...
Page 213 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Example: The following shows example CLI display output for the command. (Switch) #show lldp med local-device detail 1/0/8 LLDP MED Local Device Detail Interface: 1/0/8 Network Policies Media Policy Application Type : voice Vlan ID: 10 Priority: 5 DSCP: 1...
Page 214: Show Lldp Med Remote-Device
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Source: local Priority: low show lldp med remote-device This command displays summary information about remote devices that transmit current LLDP MED data to the system. You can show information about LLDP remote data received on all ports or on a specific port.
Page 215: Show Lldp Med Remote-Device Detail
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show lldp med remote-device detail Use this command to display detailed information about remote devices that transmit current LLDP MED data to an interface on the system. Format show lldp med remote-device detail <unit/slot/port> Mode Privileged EXEC Term...
Page 216 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Sub Type Shows the type of location information. Location Shows the location information as a string for a given type of location id Information Device Type Shows the remote device’s PoE device type connected to this port. Available Shows the romote port’s PSE power value in tenths of a watt.
Page 217: Denial Of Service Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Software Rev: xxx xxx xxx Serial Num: xxx xxx xxx Mfg Name: xxx xxx xxx Model Name: xxx xxx xxx Asset ID: xxx xxx xxx Location Subtype: elin Info: xxx xxx xxx Extended POE Device Type: pseDevice Extended POE PSE...
Page 218: Dos-Control All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dos-control all This command enables Denial of Service protection checks globally. Default disabled Format dos-control all Mode Global Config no dos-control all This command disables Denial of Service prevention checks globally. Format no dos-control all Mode...
Page 219: Dos-Control Firstfrag
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dos-control firstfrag This command enables Minimum TCP Header Size Denial of Service protection. If the mode is enabled, Denial of Service prevention is active for this type of attack. If packets ingress having a TCP Header Size smaller then the configured value, the packets will be dropped if the mode is enabled.The default is disabled.
Page 220: Dos-Control Tcpflag
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dos-control tcpflag This command enables TCP Flag Denial of Service protections. If the mode is enabled, Denial of Service prevention is active for this type of attacks. If packets ingress having TCP Flag SYN set and a source port less than 1024 or having TCP Control Flags set to 0 and TCP Sequence Number set to 0 or having TCP Flags FIN, URG, and PSH set and TCP Sequence Number set to 0 or having TCP Flags SYN and FIN both set, the packets will be dropped if the mode is enabled.
Page 221: Dos-Control Icmp
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no dos-control l4port This command disables L4 Port Denial of Service protections. Format no dos-control l4port Mode Global Config dos-control icmp This command enables Maximum ICMP Packet Size Denial of Service protections. If the mode is enabled, Denial of Service prevention is active for this type of attack.
Page 222 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no dos-control smacdmac This command disables Source MAC address = Destination MAC address (SMAC=DMAC) Denial of Service protection. This command is only available on FSM72xxRS switches. Format no dos-control smacdmac Mode Global Config dos-control tcpport This command enables TCP L4 source = destination port number (Source TCP Port =Destination...
Page 223: Dos-Control Tcpflagseq
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default disabled Format dos-control udppport Mode Global Config no dos-control udpport This command disables UDP L4 source = destination port number (Source UDP Port =Destination UDP Port) Denial of Service protection. This command is only available on FSM72xxRS switches.
Page 224: Dos-Control Tcpoffset
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dos-control tcpoffset This command enables TCP Offset Denial of Service protection. If the mode is enabled, Denial of Service prevention is active for this type of attack. If packets ingress having TCP Header Offset equal to one (1), the packets will be dropped if the mode is enabled.
Page 225: Dos-Control Tcpsynfin
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no dos-control tcpsyn Mode Global Config dos-control tcpsynfin This command enables TCP SYN and FIN Denial of Service protection. If the mode is enabled, Denial of Service prevention is active for this type of attack. If packets ingress having TCP flags SYN and FIN set, the packets will be dropped if the mode is enabled.
Page 226: Dos-Control Icmpv
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format dos-control tcpfinurgpsh Mode Global Config no dos-control tcpfinurgpsh This command sets disables TCP FIN and URG and PSH and SEQ=0 checking Denial of Service protections. This command is only available on FSM72xxRS switches. dos-control icmpv4 Format no dos-control tcpfinurgpsh...
Page 227 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dos-control icmpv6 This command enables Maximum ICMPv6 Packet Size Denial of Service protections. If the mode is enabled, Denial of Service prevention is active for this type of attack. If ICMPv6 Echo Request (PING) packets ingress having a size greater than the configured value, the packets will be dropped if the mode is enabled.
Page 228: Show Dos-Control
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no dos-control icmpfrag Mode Global Config show dos-control This command displays Denial of Service configuration information. Format show dos-control Mode Privileged EXEC Note: Not all messages below are available in all 7000series managed switches. Term Definition First Fragment...
Page 229: Mac Database Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition TCP FIN&URG& May be enabled or disabled. The factory default is disabled. PSH Mode TCP Flag & May be enabled or disabled. The factory default is disabled. Sequence Mode TCP SYN Mode May be enabled or disabled.
Page 230: Show Forwardingdb Agetime
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show forwardingdb agetime This command displays the timeout for address aging. Default Format show forwardingdb agetime Mode Privileged EXEC Term Definition Address Aging • This parameter displays the address aging timeout for the associated forwarding Timeout database.
Page 231: Isdp Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show mac-address-table stats This command displays the Multicast Forwarding Database (MFDB) statistics. Format show mac-address-table stats Mode Privileged EXEC Term Definition Max MFDB The total number of entries that can possibly be in the Multicast Forwarding Database Table Entries table.
Page 232: Isdp Holdtime
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 isdp holdtime This command configures the hold time for ISDP packets that the switch transmits. The hold time specifies how long a receiving device should store information sent in the ISDP packet before discarding it.
Page 233: Isdp Enable
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 isdp enable This command enables ISDP on the interface. Default Enabled Format isdp enable Mode Interface Config no isdp enable This command disables ISDP on the interface. Format no isdp enable Mode Interface Config clear isdp counters...
Page 234: Show Isdp Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Timer The frequency with which this device sends ISDP packets. This value is given in seconds. Hold Time The length of time the receiving device should save information sent by this device. This value is given in seconds.
Page 235: Show Isdp Entry
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show isdp entry This command displays ISDP entries. If the device id is specified, then only entries for that device are shown. Format show isdp entry {all | deviceid} Mode Privileged EXEC Term Definition Device ID...
Page 236: Show Isdp Traffic
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Port ID The port ID of the interface from which the neighbor sent the advertisement. Hold Time The hold time advertised by the neighbor. Advertisement The version of the advertisement packet received from the neighbor. Version Entry Last Displays when the entry was last modified.
Page 237: Debug Isdp Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition ISDPv2 Packets Total number of ISDPv2 packets transmitted Transmitted ISDP Bad Header Number of packets received with a bad header ISDP Checksum Error Number of packets received with a checksum error ISDP Transmission Failure Number of packets which failed to transmit ISDP Invalid Format...
Page 238: Routing Commands
Chapter 4 Routing Commands This chapter describes the routing commands available in the 7000 series CLI. The Routing Commands chapter contains the following sections: • “Address Resolution Protocol (ARP) Commands” on page 4-1 • “IP Routing Commands” on page 4-8 •...
Page 239: Ip Proxy-Arp
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The format of the MAC address is 6 two-digit hexadecimal numbers that are separated by colons, for example 00:06:29:32:81:40. Format arp <ipaddress> <macaddr> Mode Global Config no arp This command deletes an ARP entry. The value for <arpentry> is the IP address of the interface.
Page 240: Arp Cachesize
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 arp cachesize This command configures the ARP cache size. The ARP cache size value is a platform specific integer value. The default size also varies depending on the platform. Format arp cachesize <platform specific integer value> Mode Global Config no arp cachesize...
Page 241 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 arp purge This command causes the specified IP address to be removed from the ARP cache. Only entries of type dynamic or gateway are affected by this command. Format arp purge <ipaddr> Mode Privileged EXEC arp resptime...
Page 242: Arp Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no arp retries This command configures the default ARP count of maximum request for retries. Format no arp retries Mode Global Config arp timeout This command configures the ARP entry ageout time. The value for <seconds>...
Page 243: Clear Arp-Switch
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 clear arp-switch Use this command to clear the contents of the switch’s Address Resolution Protocol (ARP) table that contains entries learned through the Management port. To observe whether this command is successful, ping from the remote system to the DUT.
Page 244: Show Arp Brief
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition MAC Address The hardware MAC address of that device. Interface The routing unit/slot/port associated with the device ARP entry. Type The type that is configurable. The possible values are Local, Gateway, Dynamic and Static.
Page 245: Ip Routing Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition IP Address The IP address of a device on a subnet attached to the switch. MAC Address The hardware MAC address of that device. Interface The routing unit/slot/port associated with the device’s ARP entry. IP Routing Commands This section describes the commands you use to enable and configure IP routing on the switch.
Page 246: Ip Address
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip routing This command disables the IP Router Admin Mode for the master switch. Format no ip routing Mode Global Config ip address This command configures an IP address on an interface. You can also use this command to configure one or more secondary IP addresses on the interface.The value for <ipaddr>...
Page 247: Ip Route Default
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 entered into the forwarding database. By specifying the preference of a static route, you control whether a static route is more or less preferred than routes from dynamic routing protocols. The preference also controls whether a static route is more or less preferred than other static routes to the same destination.
Page 248: Ip Route Distance
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip route default This command deletes all configured default routes. If the optional <nexthopip> parameter is designated, the specific next hop is deleted from the configured default route and if the optional preference value is designated, the preference of the configured default route is reset to its default.
Page 249: Ip Mtu
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format ip netdirbcast Mode Interface Config no ip netdirbcast This command disables the forwarding of network-directed broadcasts. When disabled, network directed broadcasts are dropped. Format no ip netdirbcast Mode Interface Config ip mtu This command sets the IP Maximum Transmission Unit (MTU) on a routing interface.
Page 250: Clear Ip Route All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip mtu This command resets the ip mtu to the default value. Format no ip mtu <mtu> Mode Interface Config encapsulation This command configures the link layer encapsulation type for the packet. The encapsulation type can be ethernet or snap.
Page 251: Show Ip Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show ip brief Modes • Privileged EXEC • User EXEC Term Definition Default Time to Live The computed TTL (Time to Live) of forwarding a packet from the local router to the final destination.
Page 252 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Routing Determine the operational status of IPv4 routing Interface. The possible values are Up or Interface Status Down. Primary IP The primary IP address and subnet masks for the interface. This value appears only if you Address configure it.
Page 253: Show Ip Interface Brief
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Routing Mode........Disable Administrative Mode......Enable Forward Net Directed Broadcasts....Disable Proxy ARP........Enable Local Proxy ARP........ Disable Active State........Inactive Link Speed Data Rate......Inactive MAC Address........00:10:18:82:0C:68 Encapsulation Type......Ethernet IP MTU.........
Page 254 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 prefixes keyword, the <ip-address> and <mask> pair becomes the prefix, and the command displays the routes to the addresses that match that prefix. Use the <protocol> parameter to specify the protocol that installed the routes. The value for <protocol> can be connected, ospf, rip, or static.
Page 255: Show Ip Route Summary
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 To administratively control the traffic destined to a particular network and prevent it from being forwarded through the router, you can configure a static reject route on the router. Such traffic would be discarded and the ICMP destination unreachable message is sent back to the source.
Page 256: Show Ip Route Preferences
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Reject Routes Total number of reject routes installed by all protocols. Total Routes Total number of routes in the routing table. The following shows example CLI display output for the command. (Switch) #show ip route summary Connected Routes......1 Static Routes.........7...
Page 257: Virtual Lan Routing Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip stats This command displays IP statistical information. Refer to RFC 1213 for more information about the fields that are displayed. Format show ip stats Modes • Privileged EXEC • User EXEC Virtual LAN Routing Commands This section describes the commands you use to view and configure VLAN routing and to view VLAN routing status information.
Page 258: Dhcp And Bootp Relay Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition MAC Address The MAC Address associated with the internal bridge-router interface (IBRI). The same used by Routing MAC Address is used by all VLAN routing interfaces. It will be displayed above the per- VLANs VLAN information.
Page 259: Bootpdhcprelay Maxhopcount
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 bootpdhcprelay maxhopcount This command configures the maximum allowable relay agent hops for BootP/DHCP Relay on the system. The <hops> parameter has a range of 1 to 16. Default Format bootpdhcprelay maxhopcount <1-16> Mode Global Config no bootpdhcprelay maxhopcount...
Page 260: Ip Helper Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show bootpdhcprelay This command displays the BootP/DHCP Relay information. Format show bootpdhcprelay Modes • Privileged EXEC • User EXEC Term Definition Maximum Hop The maximum allowable relay agent hops. Count Minimum Wait The minimum wait time.
Page 261: Ip Helper-Address (Global Config)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip helper-address (Global Config) Use the Global Configuration ip helper-address command to have the switch forward User Datagram Protocol (UDP) broadcasts received on an interface. To disable the forwarding of broadcast packets to specific addresses, use the no form of this command. The ip helper-address command forwards specific UDP broadcast from one interface to another.
Page 262: Ip Helper-Address
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip helper-address Use this command to add a unicast helper address to the list of helper addresses on an interface. This is the address of a DHCP server. This command can be applied multiple times on the routing interface to form the helper addresses list until the list reaches the maximum supported helper addresses.
Page 263: Icmp Throttling Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no ip helper-address discard {<1-65535>|dhcp|domain|isakmp|mobile-ip|nameserver| netbios-dgm|netbios-ns|ntp|pim-auto-rip|rip|tacacs|tftp|time} Mode Interface Config show ip helper-address Use this command to display the configured helper addresses on the given interface. Format show ip helper-address <interface> Mode •...
Page 264: Ip Redirects
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip unreachables Use this command to prevent the generation of ICMP Destination Unreachable messages. Format no ip unreachables Mode Interface Config ip redirects Use this command to enable the generation of ICMP Redirect messages by the router. By default, the generation of ICMP Redirect messages is enabled.
Page 265: Ip Icmp Error-Interval
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip icmp echo-reply Use this command to prevent the generation of ICMP Echo Reply messages by the router. Format no ip icmp echo-reply Mode Global Config ip icmp error-interval Use this command to limit the rate at which IPv4 ICMP error messages are sent. The rate limit is configured as a token bucket, with two configurable parameters, burst-size and burst-interval.
Page 266: Power Over Ethernet (Poe) Commands
Power Over Ethernet Commands This chapter provides information on the Power Over Ethernet Commands available in the GSM7228PS and GSM7252PS Switch software. The IEEE 802.3 Ethernet standard body has a task force called the 802.3af/802.3at, which specifies the method to deliver power over the LAN. 802.3af/802.3at, also known as Power over Ethernet, defines a way to build Ethernet power-sourcing equipment and powered terminals.
Page 267: Power Over Ethernet (Poe) Commands
This section shows the additional CLI commands required to provide the management interface to the Power-over-Ethernet (PoE) function. These commands only apply to GSM728PS and GSM7252PS switches. Note: For the GSM7228PS, only ports 1-24 are support the PoE function. For the GSM7252PS, only ports 1-48 support the PoE function. Power Over Ethernet Commands...
Page 268: Poe Detection
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 This command enables the Power over Ethernet (PoE) functionality on a global basis or per interface. Format Mode Global Config Interface Config Default enabled no poe This command disables the Power over Ethernet (PoE) functionality on a global basis or per interface.
Page 269: Poe High-Power
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no poe detection This command sets the detection mode to default on a global basis or per interface. Format no poe detection Mode Global Config Interface Config poe high-power This command switches a port from 802.3af mode to High Powere mode. This mode is used to power up devices that require more power than the current IEEE 802.3af power (more than 12.95 Watts at the PD).
Page 270: Poe Power Limit
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 poe power limit This command configures the type of power limit for a port. If the power limit type is "user- defined", the command will also allow you to configure a maximum power limit. The possible options are: •...
Page 271: Poe Priority
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Where Total Allocated Power is calculated as the power limit configured on the port. • Dynamic Power Management Available Power = Power limit of the Source - Total Allocated power Where Total Allocated Power is calculated as the amount of power consumed by the port. For example, Consider that Power limit at the Source is 300 Watts.
Page 272: Poe Reset
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Low - Low Priority Format poe priority {Crit | High | Low} Mode Global Config Interface Config Default no poe priority This command sets the priority to default. Format no poe priority Mode Global Config Intrerface Config...
Page 273: Poe Usagethreshold
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no poe reset auto This command is used to clear Autoreset mode. Format no poe reset auto {<unit>|all} Mode Global Config poe usagethreshold This command sets a threshold (in percentage) for the total amount of power that can be delivered by the switch.
Page 274: Poe Traps
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 poe traps This command is used enable logging of specific PoE related events like a PoE port powering a device or the threshold being exceeded etc. Format poe traps Mode Global Config Default Enable no poe traps...
Page 275: Show Poe Port Configuration
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Unit The unit id Firmware This is firmware version of the PoE controller on the switch. It is displayed in terms of version Major.Minor Revision. PSE Main This indicates the status of the PoE controller. Operational ON -This indicates that the PoE controller is actively delivering power.
Page 276: Show Poe Port Info
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show poe port info This command displays the status for the ports that support the PoE function.You can display information on a per port basis or all the ports at the same time. Format show poe port info {<unit/slot/port>|all} Mode...
Page 277: Quality Of Service (Qos) Commands
Chapter 6 Quality of Service (QoS) Commands This chapter describes the Quality of Service (QoS) commands available in the managed switch CLI. The QoS Commands chapter contains the following sections: • “Class of Service (CoS) Commands” on page 6-2 • “Differentiated Services (DiffServ) Commands”...
Page 278: Class Of Service (Cos) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Class of Service (CoS) Commands This section describes the commands you use to configure and view Class of Service (CoS) settings for the switch. The commands in this section allow you to control the priority and transmission rate of traffic.
Page 279: Classofservice Trust
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The <trafficclass> values can range from 0-6, although the actual number of available traffic classes depends on the platform. Format classofservice ip-dscp-mapping <ipdscp> <trafficclass> Mode Global Config no classofservice ip-dscp-mapping This command maps each IP DSCP value to its default internal traffic class value. Format no classofservice ip-dscp-mapping Mode...
Page 280: Cos-Queue Min-Bandwidth
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 cos-queue min-bandwidth This command specifies the minimum transmission bandwidth guarantee for each interface queue. The total number of queues supported per interface is platform specific. A value from 0-100 (percentage of link rate) must be specified for each supported queue, with 0 indicating no guaranteed minimum bandwidth.
Page 281: Show Classofservice Dot1P-Mapping
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 traffic-shape This command specifies the maximum transmission bandwidth limit for the interface as a whole. Also known as rate shaping, traffic shaping has the effect of smoothing temporary traffic bursts over time so that the transmitted traffic rate is bounded. Format traffic-shape <bw>...
Page 282: Show Classofservice Ip-Precedence-Mapping
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show classofservice ip-precedence-mapping This command displays the current IP Precedence mapping to internal traffic classes for a specific interface. The unit/slot/port parameter is optional and is only valid on platforms that support independent per-port class of service mappings.
Page 283: Show Classofservice Trust
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show classofservice trust This command displays the current trust mode setting for a specific interface. The <unit/slot/ port> parameter is optional and is only valid on platforms that support independent per-port class of service mappings.
Page 284: Differentiated Services (Diffserv) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If you specify the interface, the command also displays the following information. Term Definition Interface The unit/slot/port of the interface. If displaying the global configuration, this output line is replaced with a Global Config indication. Interface The maximum transmission bandwidth limit for the interface as a whole.
Page 285 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 A given class definition can contain a maximum of one reference to another class. You can combine the reference with other match criteria. The referenced class is truly a reference and not a copy since additions to a referenced class affect all classes that reference it.
Page 286: Diffserv Class Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 DiffServ Class Commands Use the DiffServ class commands to define traffic classification. To classify traffic, you specify Behavior Aggregate (BA), based on DSCP and Multi-Field (MF) classes of traffic (name, match criteria) This set of commands consists of class creation/deletion and matching, with the class match commands specifying Layer 3, Layer 2, and general match criteria.
Page 287: Class-Map Rename
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: The CLI mode is changed to Class-Map Config or Ipv6-Class-Map Config when this command is successfully executed depending on the [{ipv4 | ipv6}] keyword specified. Format class-map match-all <class-map-name> [{ipv4 | ipv6}] Mode Global Config no class-map...
Page 288: Match Ethertype
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 match ethertype This command adds to the specified class definition a match condition based on the value of the ethertype. The <ethertype> value is specified as one of the following keywords: appletalk, arp, ibmsna, ipv4, ipv6, ipx, mplsmcast, mplsucast, netbios, novell, pppoe, rarp or as a custom ethertype value in the range of 0x0600-0xFFFF.
Page 289: Match Cos
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: • The parameters <refclassname> and <class-map-name> can not be the same. • Only one other class may be referenced by a class. • Any attempts to delete the <refclassname> class while the class is still referenced by any <class- map-name>...
Page 290: Match Ip6Flowlbl
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 match ip6flowlbl This command adds to the specified class definition a match condition based on the IP6flowlbl of a packet. The label is the value to match in the Flow Label field of the IPv6 header (range 0- 1048575).
Page 291: Match Dstl4Port
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 match dstip6 This command adds to the specified class definition a match condition based on the destination IPv6 address of a packet. Default none Format match dstip6 <destination-ipv6-prefix/prefix-length> Mode Ipv6-Class-Map Config match dstl4port This command adds to the specified class definition a match condition based on the destination layer 4 port of a packet using a single keyword or numeric notation.
Page 292: Match Ip Precedence
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default none Format match ip dscp <dscpval> Mode Class-Map Config Ipv6-Class-Map Config match ip precedence This command adds to the specified class definition a match condition based on the value of the IP Precedence field in a packet, which is defined as the high-order three bits of the Service Type octet in the IP header (the low-order five bits are not checked).
Page 293: Match Protocol
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: This “free form” version of the IP DSCP/Precedence/TOS match specification gives the user complete control when specifying which bits of the IP Service Type field are checked. Default none Format match ip tos <tosbits>...
Page 294: Match Source-Address Mac
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 match source-address mac This command adds to the specified class definition a match condition based on the source MAC address of a packet. The <address> parameter is any layer 2 MAC address formatted as six, two-digit hexadecimal numbers separated by colons (e.g., 00:11:22:dd:ee:ff).
Page 295: Diffserv Policy Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 (listed below). The currently supported <portkey> values are: domain, echo, ftp, ftpdata, http, smtp, snmp, telnet, tftp, www. Each of these translates into its equivalent port number, which is used as both the start and end of a port range. To specify the match condition as a numeric value, one layer 4 port number is required.
Page 296 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 assign-queue This command modifies the queue id to which the associated traffic stream is assigned. The queueid is an integer from 0 to n-1, where n is the number of egress queues supported by the device.
Page 297 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 redirect This command specifies that all incoming packets for the associated traffic stream are redirected to a specific egress interface (physical port or port-channel). Note: This command is not available on the GSM7328Sv1 or GSM7352Sv1 platforms. Format redirect <unit/slot/port>...
Page 298: Mark Cos
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: The CLI mode is changed to Policy-Class-Map Config when this command is successfully executed. Format class <classname> Mode Policy-Map Config no class This command deletes the instance of a particular class and its defined treatment from the specified policy.
Page 299: Mark Ip-Precedence
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The <dscpval> value is specified as either an integer from 0 to 63, or symbolically through one of the following keywords: af11, af12, af13, af21, af22, af23, af31, af32, af33, af41, af42, af43, be, cs0, cs1, cs2, cs3, cs4, cs5, cs6, cs7, ef.
Page 300 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 For set-cos-transmit an 802.1p priority value is required and is specified as an integer from 0-7. Format police-simple {<1-4294967295> <1-128> conform-action {drop | set- prec-transmit <0-7> | set-dscp-transmit <0-63> | set-cos-transmit <0-7>...
Page 301: Diffserv Service Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 policy-map rename This command changes the name of a DiffServ policy. The <policyname> is the name of an existing DiffServ class. The <newpolicyname> parameter is a case-sensitive alphanumeric string from 1 to 31 characters uniquely identifying the policy. Format policy-map rename <policyname>...
Page 302: Diffserv Show Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format service-policy in <policymapname> Modes • Global Config • Interface Config Note: Each interface can have one policy attached. no service-policy This command detaches a policy from an interface in the inbound direction. The <policyname> parameter is the name of an existing DiffServ policy.
Page 303: Show Diffserv
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If the class-name is specified the following fields are displayed: Term Definition Class Name The name of this class. Class Type A class type of ‘all’ means every match criterion defined for the class is evaluated simultaneously and must all be true to indicate a class match.
Page 304: Show Policy-Map
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition DiffServ Admin mode The current value of the DiffServ administrative mode. Class Table Size The current number of entries (rows) and the maximum allowed entries (rows) in Current /Max the Class Table.
Page 305 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Committed Burst The committed burst size, used in simple policing. Size (KB) Committed Rate The committed rate, used in simple policing, (Kbps) Conform Action The current setting for the action taken on a packet considered to conform to the policing parameters.
Page 306: Show Diffserv Service
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If the Policy Name is not specified this command displays a list of all defined DiffServ policies. The following fields are displayed: Definition Term Policy Name The name of this policy. (The order in which the policies are displayed is not necessarily the same order in which they were created.) Policy Type The policy type (Only inbound is supported).
Page 307: Show Policy-Map Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition DiffServ Admin The current setting of the DiffServ administrative mode. An attached policy is only active Mode on an interface while DiffServ is in an enabled mode. The following information is repeated for interface and direction (only those interfaces configured with an attached policy are shown): Term Definition...
Page 308: Mac Access Control List (Acl) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition In Discarded A count of the packets discarded for this class instance for any reason due to DiffServ Packets treatment of the traffic class. show service-policy This command displays a summary of policy-oriented statistics information for all interfaces in the specified direction.
Page 309 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 mac access-list extended This command creates a MAC Access Control List (ACL) identified by <name>, consisting of classification fields defined for the Layer 2 header of an Ethernet frame. The <name> parameter is a case-sensitive alphanumeric string from 1 to 31 characters uniquely identifying the MAC access list.
Page 310: Deny | Permit} (Mac Acl)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 {deny | permit} (MAC ACL) This command creates a new rule for the current MAC access list. Each rule is appended to the list of configured rules for the list. Note: The 'no' form of this command is not supported, since the rules within a MAC ACL cannot be deleted individually.
Page 311: Mac Access-Group
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The vlan and cos parameters refer to the VLAN identifier and 802.1p user priority fields, respectively, of the VLAN tag. For packets containing a double VLAN tag, this is the first (or outer) tag.
Page 312: Show Mac Access-Lists
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format mac access-group <name> [vlan <vlan-id>] [in|out] [sequence <1- 4294967295>] Modes • Global Config • Interface Config no mac access-group This command removes a MAC ACL identified by <name> from the interface in a given direction.
Page 313: Ip Access Control List (Acl) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Redirect The unit/slot/port to which packets matching this rule are forwarded. Interface IP Access Control List (ACL) Commands This section describes the commands you use to configure IP ACL settings. IP ACLs ensure that only authorized users have access to specific resources and block any unwarranted attempts to reach network resources.
Page 314 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 IP Extended ACL: Format access-list <100-199> {deny | permit} {every | {{icmp | igmp | ip | tcp | udp | <number>} <srcip> <srcmask>[{eq {<portkey> | <0-65535>} <dstip> <dstmask> [{eq {<portkey>| <0-65535>}] [precedence <precedence>...
Page 315 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no access-list This command deletes an IP ACL that is identified by the parameter <accesslistnumber> from the system. The range for <accesslistnumber> 1-99 for standard access lists and 100- 199 for extended access lists. Format no access-list <accesslistnumber>...
Page 316 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip access-list rename This command changes the name of an IP Access Control List (ACL). The <name> parameter is the names of an existing IP ACL. The <newname> parameter is a case-sensitive alphanumeric string from 1 to 31 characters uniquely identifying the IP access list.
Page 317: Ip Access-Group
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 keyword ‘ ’ to indicate a match on any value in that field. The remaining command parameters are all optional, but the most frequently used parameters appear in the same relative order as shown in the command format.
Page 318: Show Ip Access-Lists
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip access-group This command removes a specified IP ACL from an interface. Default none Format no ip access-group <accesslistnumber> [vlan <vlan-id>] in Mode • Interface Config • Global Config acl-trapflags This command enables the ACL trap mode.
Page 319: Show Access-Lists
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Rule Number The number identifier for each rule that is defined for the IP ACL. Action The action associated with each rule. The possible values are Permit or Deny. Match All Indicates whether this access list applies to every packet.
Page 320: Ipv6 Access Control List (Acl) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition ACL ID Access List name for a MAC or IPv6 access list or the numeric identifier for an IP access list. Sequence An optional sequence number may be specified to indicate the order of this access list Number relative to other access lists already assigned to this interface and direction.
Page 321: Ipv6 Access-List Rename
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If an IPv6 ACL by this name already exists, this command enters IPv6-Access-List config mode to allow updating the existing IPv6 ACL. Note: The CLI mode changes to IPv6-Access-List Config mode when you successfully execute this command.
Page 322 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: An implicit ‘deny all’ IPv6 rule always terminates the access list. A rule may either deny or permit traffic according to the specified classification fields. At a minimum, either the ‘every’ keyword or the protocol, source address, and destination address values must be specified.
Page 323: Show Ipv6 Access-Lists
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 This command specified in Interface Config mode only affects a single interface, whereas the Global Config mode setting is applied to all interfaces. The vlan keyword is only valid in the Global Config mode.
Page 324: Auto-Voice Over Ip Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Match All Indicates whether this access list applies to every packet. Possible values are True or False. Protocol The protocol to filter for this rule. Source IP The source IP address for this rule. Address Source L4 Port The source port for this rule.
Page 325: Show Auto-Voip
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default disabled Format auto-voip all Mode Global Config no auto-voip all Use this command to disable VoIP Profile on the interfaces of the switch. Format no auto-voip all Mode Global Config auto-voip Use this command to enable VoIP Profile on the interface.
Page 326 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description AutoVoIP Mode The Auto VoIP mode on the interface. Traffic Class The CoS Queue or Traffic Class to which all VoIP traffic is mapped to. This is not configurable and defaults to the highest CoS queue available in the system for data traffic. Quality of Service (QoS) Commands 6-50 v1.0, May 2010...
Page 327: Utility Commands
Chapter 7 Utility Commands This chapter describes the utility commands available in the CLI. The Utility Commands chapter includes the following sections: • “Auto Install Commands” on page 7-2 • “Dual Image Commands” on page 7-4 • “System Information and Statistics Commands” on page 7-6 •...
Page 328: Auto Install Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Auto Install Commands This section describes the Auto Install Commands. Auto Install is a software feature which provides for the configuration of a switch automatically when the device is initialized and no configuration file is found on the switch.
Page 329 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 boot autoinstall auto-save This command is used to enable automatically saving the downloaded configuration on the switch. Default Disabled Format boot autoinstall auto-save Mode Privileged EXEC no boot autoinstall auto-save This command is used to disable automatically saving the downloaded configuration on the switch..
Page 330: Dual Image Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 boot autoinstall retry-count This command is used to set the number of attempts to download a configuration. The valid range is from 1 to 6. Default Format boot autoinstall retry-count Mode Privileged EXEC no boot autoinstall retry-count This command is used to reset the number to the default.
Page 331: Boot System
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 boot system This command activates the specified image. It will be the active-image for subsequent reboots and will be loaded by the boot loader. The current active-image is marked as the backup-image for subsequent reboots.
Page 332: System Information And Statistics Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 update bootcode This command updates the bootcode (boot loader) on the switch. The bootcode is read from the active-image for subsequent reboots.The optional <unit> parameter is valid only on Stacks. Error will be returned, if this parameter is provided, on Standalone systems. For Stacking, the <unit>...
Page 333: Show Eventlog
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show eventlog This command displays the event log, which contains error messages from the system. The event log is not cleared on a system reset. The <unit> is the switch identifier. Format show eventlog [<unit>] Mode...
Page 334: Show Version
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show version This command displays inventory information for the switch. Note: The show version command will replace the show hardware command in future releases of the software. Format show version Mode Privileged EXEC Term Definition...
Page 335 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The display parameters, when the argument is <unit/slot/port>, are as follows: Parameters Definition Packets The total number of packets (including broadcast packets and multicast packets) received Received by the processor. Without Error Packets The number of inbound packets that contained errors preventing them from being Received With...
Page 336: Show Interface Ethernet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Address Entries The total number of Forwarding Database Address Table entries now active on the Currently In Use switch, including learned and static entries. VLAN Entries The number of VLAN entries presently occupying the VLAN table. Currently In Use Time Since The elapsed time, in days, hours, minutes, and seconds since the statistics for this switch...
Page 337: Show Mac-Addr-Table
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Octets The total number of octets transmitted out of the interface, including framing characters. Transmitted Packets The total number of packets transmitted out of the interface. Transmitted without Errors Unicast Packets The total number of packets that higher-level protocols requested be transmitted to a Transmitted...
Page 338 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Enter all or no parameter to display the entire table. Enter a MAC Address and VLAN ID to display the table entry for the requested MAC address on the specified VLAN. Enter the count parameter to view summary information about the forwarding database table.
Page 339: Show Process Cpu
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If you enter the interface <unit/slot/port> parameter, in addition to the MAC Address and Status fields, the following field appears: Term Definition VLAN ID The VLAN on which the MAC address was learned. The following information displays if you enter the count parameter: Term Definition...
Page 340: Show Mbuf Total
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ------ ---------- free 192980480 alloc 53409968 Task Utilization Report Task Utilization ----------------------- ----------- bcmL2X.0 0.75% bcmCNTR.0 0.20% bcmLINK.0 0.35% DHCP snoop 0.10% Dynamic ARP Inspection 0.10% dot1s_timer_task 0.10% dhcpsPingTask 0.20% show mbuf total This command shows the total system buffer pools status.
Page 341 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show running-config Use this command to display or capture the current setting of different protocol packages supported on the switch. This command displays or captures commands with settings and configurations that differ from the default value. To display or capture the commands with settings and configurations that are equal to the default value, include the [all] option.
Page 342: Show Running-Config Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show running-config interface This command shows the current configuration on a particular interface. The interface could be a physical port or a virtual port—like a LAG or VLAN. The output captures how the configuration differs from the factory default value.
Page 343 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 • show port all • show isdp neighbors • show logging • show event log • show logging buffered • show trap log Format show tech-support Mode Privileged EXEC terminal length Use this command to set the number of lines of output to be displayed on the screen, i.e.
Page 344: Logging Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show terminal length Use this command to display the value of the user-configured terminal length size. Format show terminal length Mode Privileged EXEC Logging Commands This section describes the commands you use to configure system logging, and to view logs and the logging settings.
Page 345: Logging Cli-Command
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no logging buffered wrap This command disables wrapping of in-memory logging and configures logging to stop when the log file capacity is full. Format no logging buffered wrap Mode Privileged EXEC logging cli-command This command enables the CLI command logging feature, which enables the 7000 series software to log all CLI commands issued on the system.
Page 346: Logging Host
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no logging console This command disables logging to the console. Format no logging console Mode Global Config logging host This command enables logging to a host. You can configure up to eight hosts. The <ipaddr|hostname>...
Page 347: Show Logging
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no logging syslog This command disables syslog logging. Format no logging syslog Mode Global Config show logging This command displays logging configuration information. Format show logging Mode Privileged EXEC Term Definition Logging Client Port on the collector/relay to which syslog messages are sent.
Page 348: Show Logging Hosts
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Buffered (In- Shows whether the In-Memory log is enabled or disabled. Memory) Logging Buffered The behavior of the In Memory log when faced with a log full situation. Logging Wrapping Behavior Buffered Log...
Page 349: System Utility And Clear Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Number of Traps The number of traps since the last boot. Since Last Reset Trap Log The number of traps the system can retain. Capacity Number of Traps The number of new traps since the command was last executed. Since Log Last Viewed The log number.
Page 350 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 traceroute Use the traceroute command to discover the routes that packets actually take when traveling to their destination through the network on a hop-by-hop basis. Traceroute continues to provide a synchronous response when initiated from the CLI. Default •...
Page 351: Traceroute Ipv6
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Example: The following are examples of the CLI command. traceroute Success: (Switch) # traceroute 10.240.10.115 initTtl 1 maxTtl 4 maxFail 0 interval 1 count 3 port 33434 size 43 Traceroute to 10.240.10.115 ,4 hops max 43 byte packets: 1 10.240.4.1 708 msec 41 msec...
Page 352: Clear Config
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 clear config This command resets the configuration to the factory defaults without powering off the switch. When you issue this command, a prompt appears to confirm that the reset should proceed. When you enter y, you automatically reset the current configuration on the switch to the default values.
Page 353: Clear Igmpsnooping
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 clear igmpsnooping This command clears the tables managed by the IGMP Snooping function and attempts to delete these entries from the Multicast Forwarding Database. Format clear igmpsnooping Mode Privileged EXEC clear pass This command resets all user passwords to the factory defaults without powering off the switch.
Page 354: Enable Password
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 enable password This command prompts you to change the Privileged EXEC password. Passwords are a maximum of 64 alphanumeric characters. The password is case sensitive. The option [encrypted] allows the administrator to transfer the enable password between devices without having to know the password.
Page 355 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Using the options described below, you can specify the number and size of Echo Requests and the interval between Echo Requests. Parameter Description count Use the count parameter to specify the number of ping packets (ICMP Echo requests) that are sent to the destination address specified by the <ip-address>...
Page 356 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 1 packets transmitted,0 packets received, 100% packet loss round-trip (msec) min/avg/max = 0/0/0 quit This command closes the current telnet connection or resets the current serial connection. The system asks you whether to save configuration changes before quitting. Format quit Modes...
Page 357 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 copy The copy command uploads and downloads files to and from the switch. You can also use the copy command to manage the dual images (image1 and image2) on the file system. Upload and download files from a server by using TFTP or Xmodem.
Page 358 When you use this option, the copy command will not <destfilename> noval validate the downloaded script file. An example of the CLI command follows: (NETGEAR Switch CLI Routing) #copy tftp://1.1.1.1/file.scr nvram:script file.scr <url> nvram:sshkey-dsa Downloads an SSH key file. For more information, see “Secure Shell (SSH) Commands”...
Page 359: Simple Network Time Protocol (Sntp) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Source Destination Description <url> {image1 | image2} Download an image from the remote server to either image. In a stacking environment, the downloaded image is distributed to the stack nodes. {image1 | image2} <url>...
Page 360: Sntp Client Mode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 sntp client mode This command enables Simple Network Time Protocol (SNTP) client mode and may set the mode to either broadcast or unicast. Default disabled Format sntp client mode [broadcast | unicast] Mode Global Config no sntp client mode...
Page 361: Sntp Unicast Client Poll-Interval
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 sntp unicast client poll-interval This command sets the poll interval for SNTP unicast clients in seconds as a power of two where <poll-interval> can be a value from 6 to 10. Default Format sntp unicast client poll-interval <poll-interval>...
Page 362: Sntp Server
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format sntp unicast client poll-retry <poll-retry> Mode Global Config no sntp unicast client poll-retry This command will reset the poll retry for SNTP unicast clients to its default value. Format no sntp unicast client poll-retry Mode Global Config sntp server...
Page 363: Show Sntp
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Zone name: A name to associate with the time zone Hours-offset: Number of hours difference with UTC Minutes-offset: Number of minutes difference with UTC no clock timezone This command sets the switch to UTC time. Format no clock timezone Mode...
Page 364: Show Sntp Server
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Client Supported Supported SNTP Modes (Broadcast, Unicast, or Multicast). Modes SNTP Version The highest SNTP version the client supports. Port SNTP Client Port. Client Mode Configured SNTP Client Mode. show sntp server This command is used to display SNTP server settings and configured servers.
Page 365: Dhcp Server Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Last Attempt Last server attempt time for the specified server. Time Last Update Last server attempt status for the server. Status Total Unicast Number of requests to the server. Requests Failed Unicast Number of failed requests from server.
Page 366: Ip Dhcp Pool
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip dhcp pool This command configures a DHCP address pool name on a DHCP server and enters DHCP pool configuration mode. Default none Format ip dhcp pool <name> Mode Global Config no ip dhcp pool This command removes the DHCP address pool.
Page 367 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 client-name This command specifies the name for a DHCP client. Name is a string consisting of standard ASCII characters. Default none Format client-name <name> Mode DHCP Pool Config no client-name This command removes the client name. Format no client-name Mode...
Page 368 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dns-server This command specifies the IP servers available to a DHCP client. Address parameters are valid IP addresses; each made up of four decimal bytes ranging from 0 to 255. IP address 0.0.0.0 is invalid. Default none Format...
Page 369 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 host This command specifies the IP address and network mask for a manual binding to a DHCP client. Address and Mask are valid IP addresses; each made up of four decimal bytes ranging from 0 to 255.
Page 370: Network (Dhcp Pool Config)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 network (DHCP Pool Config) Use this command to configure the subnet number and mask for a DHCP address pool on the server. Network-number is a valid IP address, made up of four decimal bytes ranging from 0 to 255.
Page 371 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 domain-name This command specifies the domain name for a DHCP client. The <domain> specifies the domain name string of the client. Default none Format domain-name <domain> Mode DHCP Pool Config no domain-name This command removes the domain name.
Page 372 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 netbios-node-type The command configures the NetBIOS node type for Microsoft Dynamic Host Configuration Protocol (DHCP) clients.type Specifies the NetBIOS node type. Valid types are: • b-node—Broadcast • p-node—Peer-to-peer • m-node—Mixed • h-node—Hybrid (recommended) Default none...
Page 373: Ip Dhcp Excluded-Address
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 option The option command configures DHCP Server options. The <code> parameter specifies the DHCP option code and ranges from 1-254. The <ascii string> parameter specifies an NVT ASCII character string. ASCII character strings that contain white space must be delimited by quotation marks.
Page 374: Ip Dhcp Ping Packets
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip dhcp excluded-address This command removes the excluded IP addresses for a DHCP client. Low-address and high- address are valid IP addresses; each made up of four decimal bytes ranging from 0 to 255. IP address 0.0.0.0 is invalid.
Page 375: Ip Dhcp Bootp Automatic
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no service dhcp This command disables the DHCP server. Format no service dhcp Mode Global Config ip dhcp bootp automatic This command enables the allocation of the addresses to the bootp client. The addresses are from the automatic address pool.
Page 376: Clear Ip Dhcp Binding
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip dhcp conflict logging This command disables conflict logging on DHCP server. Format no ip dhcp conflict logging Mode Global Config clear ip dhcp binding This command deletes an automatic address binding from the DHCP server database. If “*” is specified, the bindings corresponding to all the addresses are deleted.
Page 377: Show Ip Dhcp Binding
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip dhcp binding This command displays address bindings for the specific IP address on the DHCP server. If no IP address is specified, the bindings corresponding to all the addresses are displayed. Format show ip dhcp binding [<address>] Modes...
Page 378: Show Ip Dhcp Pool Configuration
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip dhcp pool configuration This command displays pool configuration. If all is specified, configuration for all the pools is displayed. Format show ip dhcp pool configuration {<name> | all} Modes •...
Page 379: Show Ip Dhcp Server Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip dhcp server statistics This command displays DHCP server statistics. Format show ip dhcp server statistics Modes • Privileged EXEC • User EXEC Field Definition Automatic The number of IP addresses that have been automatically mapped to the MAC addresses Bindings of hosts that are found in the DHCP database.
Page 380: Dns Client Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip dhcp conflict This command displays address conflicts logged by the DHCP Server. If no IP address is specified, all the conflicting addresses are displayed. Format show ip dhcp conflict [<ip-address>] Modes •...
Page 381: Ip Domain Name
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip domain name Use this command to define a default domain name that the software uses to complete unqualified host names (names with a domain name). By default, no default domain name is configured in the system.
Page 382: Ip Name Server
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip domain list Use this command to delete a name from a list. Format no ip domain list <name> Mode Global Config ip name server Use this command to configure the available name servers. Up to eight servers can be defined in one command or by using multiple commands.
Page 383: Ipv6 Host
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip host Use this command to remove the name-to-address mapping. Format no ip host <name> Mode Global Config ipv6 host Use this command to define static host name-to-IPv6 address mapping in the host cache. <name> is host name.
Page 384: Ip Domain Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip domain retry Use this command to return to the default. Format no ip domain retry <number> Mode Global Config ip domain timeout Use this command to specify the amount of time to wait for a response to a DNS query. The parameter <seconds>...
Page 385: Show Hosts
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show hosts Use this command to display the default domain name, a list of name server hosts, the static and the cached list of host names and addresses <ame> ranges from 1-255 characters. This command displays both IPv4 and IPv6 entries.
Page 386: Packet Capture Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 www.stanford.edu 171.64.14.203 Packet Capture Commands Packet capture commands assist in troubleshooting protocol-related problems with the management CPU. The packets to and from the management CPU can be captured in an internally allocated buffer area for export to a PC host for protocol analysis.
Page 387: Capture Wrap
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no capture receive packet This command disables the capturing of receive packets. Format no capture receive packet Mode Global Config capture all packets This command enables the capturing of receive packets. Format capture all packet Mode...
Page 388: Serviceability Packet Tracing Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Mode Global Config Default Enabled Serviceability Packet Tracing Commands These commands improve the capability of network engineers to diagnose conditions affecting their managed switch product. Caution! The output of “debug” commands can be long and may adversely affect system performance.
Page 389: Debug Clear
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug auto-voip Use this command to disable Auto VOIP debug messages. Format no debug auto-voip Mode Privileged EXEC debug clear This command disables all previously enabled “debug” traces. Default disabled Format debug clear Mode...
Page 390: Debug Dot1X Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 debug dot1x packet Use this command to enable dot1x packet debug trace. Default disabled Format debug dot1x Mode Privileged EXEC no debug dot1x packet Use this command to disable dot1x packet debug trace. Format no debug dot1x Mode...
Page 391: Debug Igmpsnooping Packet Transmit
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 debug igmpsnooping packet transmit This command enables tracing of IGMP Snooping packets transmitted by the switch. Snooping should be enabled on the device and the interface in order to monitor packets for a particular interface.
Page 392: Debug Igmpsnooping Packet Receive
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug igmpsnooping transmit This command disables tracing of transmitted IGMP snooping packets. Format no debug igmpsnooping transmit Mode Privileged EXEC debug igmpsnooping packet receive This command enables tracing of IGMP Snooping packets received by the switch. Snooping should be enabled on the device and the interface in order to monitor packets for a particular interface.
Page 393: Debug Ip Acl
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Parameter Definition Group Multicast group address in the IGMP header. no debug igmpsnooping receive This command disables tracing of received IGMP Snooping packets. Format no debug igmpsnooping receive Mode Privileged EXEC debug ip acl Use this command to enable debug of IP Protocol packets matching the ACL criteria.
Page 394: Debug Ip Igmp Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug ip dvmrp packet Use this command to disable debug tracing of DVMRP packet reception and transmission. Format no debug ip dvmrp packet [receive|transmit] Mode Privileged EXEC debug ip igmp packet Use this command to trace IGMP packet reception and transmission.
Page 395: Debug Ip Pimdm Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format debug ip mcache packet [receive|transmit] Mode Privileged EXEC no debug ip mcache packet Use this command to disable debug tracing of MDATA packet reception and transmission. Format no debug ip mcache packet [receive|transmit] Mode Privileged EXEC debug ip pimdm packet...
Page 396: Debug Ip Pimsm Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 debug ip pimsm packet Use this command to trace PIMSM packet reception and transmission. receive traces only received PIMSM packets and transmit traces only transmitted PIMSM packets. When neither keyword is used in the command, then all PIMSM packet traces are dumped. Vital information such as source address, destination address, control packet type, packet length, and the interface on which the packet is received or transmitted is displayed on the console.
Page 397: Debug Ipv6 Mcache Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 debug ipv6 mcache packet Use this command for tracing MDATAv6 packet reception and transmission. receive traces only received data packets and transmit traces only transmitted data packets. When neither keyword is used in the command, then all data packet traces are dumped.
Page 398: Debug Ipv6 Pimdm Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no debug ipv6 mld packet [receive|transmit] Mode Privileged EXEC debug ipv6 pimdm packet Use this command to trace PIMDMv6 packet reception and transmission. receive traces only received PIMDMv6 packets and transmit traces only transmitted PIMDMv6 packets. When neither keyword is used in the command, then all PIMDMv6 packet traces are dumped.
Page 399: Debug Lacp Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no debug ipv6 pimsm packet [receive|transmit] Mode Privileged EXEC debug lacp packet This command enables tracing of LACP packets received and transmitted by the switch. Default disabled Format debug lacp packet Mode Privileged EXEC A sample output of the trace message is shown below.
Page 400: Debug Ospf Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug mldsnooping packet Use this command to disable debug tracing of MLD snooping packet reception and transmission. debug ospf packet This command enables tracing of OSPF packets received and transmitted by the switch. Default disabled Format...
Page 401 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Parameter Definition Intf The interface that the packet came in or went out on. Format used is unit/slot/port (internal interface number). SrcIp The source IP address in the IP header of the packet. DestIp The destination IP address in the IP header of the packet.
Page 402: Debug Ospfv3 Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 LS_UPD packet field definitions. Field Definition Length Length of packet LS_ACK packet field definitions. Field Definition Length Length of packet no debug ospf packet This command disables tracing of OSPF packets. Format no debug ospf packet Mode...
Page 403: Debug Ping Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 debug ping packet This command enables tracing of ICMP echo requests and responses. The command traces pings on the network port/ serviceport for switching packages. For routing packages, pings are traced on the routing ports as well.
Page 404: Debug Rip Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 debug rip packet This command turns on tracing of RIP requests and responses. This command takes no options. The output is directed to the log file. Default disabled Format debug rip packet Mode Privileged EXEC A sample output of the trace message is shown below.
Page 405: Debug Sflow Packet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug rip packet This command disables tracing of RIP requests and responses. Format no debug rip packet Mode Privileged EXEC debug sflow packet Use this command to enable sFlow debug packet trace. Default disabled Format...
Page 406: Debug Spanning-Tree Bpdu Receive
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug spanning-tree bpdu This command disables tracing of spanning tree BPDUs. Format no debug spanning-tree bpdu Mode Privileged EXEC debug spanning-tree bpdu receive This command enables tracing of spanning tree BPDUs received by the switch. Spanning tree should be enabled on the device and on the interface in order to monitor packets for a particular interface.
Page 407: Debug Spanning-Tree Bpdu Transmit
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug spanning-tree bpdu receive This command disables tracing of received spanning tree BPDUs. Format no debug spanning-tree bpdu receive Mode Privileged EXEC debug spanning-tree bpdu transmit This command enables tracing of spanning tree BPDUs transmitted by the switch. Spanning tree should be enabled on the device and on the interface in order to monitor packets on a particular interface.
Page 408: Cable Test Command
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no debug spanning-tree bpdu transmit This command disables tracing of transmitted spanning tree BPDUs. Format no debug spanning-tree bpdu transmit Mode Privileged EXEC Cable Test Command The cable test feature enables you to determine the cable connection status on a selected port. Note: The cable test feature is supported only for copper cable.
Page 409: Sflow Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description Cable Length If this feature is supported by the PHY for the current link speed, the cable length is displayed as a range between the shortest estimated length and the longest estimated length.
Page 410: Sflow Sampler
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description Receiver Max The maximum number of data bytes that can be sent in a single sample datagram. The Datagram Size management entity should set this value to avoid fragmentation of the sFlow datagrams. The allowed range is 200 to 9116).
Page 411: Sflow Poller
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description Sampling Rate The statistical sampling rate for packet sampling from this source. A sampling rate of 1 counts all packets. A value of zero (0) disables sampling. A value of N means that out of N incoming packets, 1 packet will be sampled.
Page 412: Show Sflow Agent
Uniquely identifies the version and implementation of this MIB. The version string must have the following structure: MIB Version; Organization; Software Revision where: • MIB Version: ‘1.3’, the version of this MIB. • Organization: Netgear. • Revision: 1.0 IP Address The IP address associated with this agent.
Page 413: Show Sflow Receivers
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description Poller Data The sFlowDataSource (slot/port) for this sFlow sampler. This agent will support Physical Source ports only. Receiver Index The sFlowReceiver associated with this sFlow counter poller. Poller Interval The number of seconds between successive samples of the counters associated with this data source.
Page 414: Software License Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Datagram Version....... 5 Maximum Datagram Size......1400 show sflow samplers Use this command to display the sFlow sampling instances created on the switch. Format show sflow samplers Mode Privileged EXEC Field Description Sampler Data The sFlowDataSource (slot/port) for this sFlow sampler.
Page 415: Show License
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: Software license will allow the user to download a license file only on the Master unit. The file cannot be downloaded on a Slave unit (even if the Slave unit is a Licensable switch like GSM72xxPS or GSM73xxSv1) Note: There are two options to download the license file to the switch: 1).
Page 416 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 OSPFV3 IPV6 Utility Commands 7-90 v1.0, May 2010...
Page 417: Management Commands
Chapter 8 Management Commands This chapter describes the management commands available in the managed switch CLI. The Management Commands chapter contains the following sections: • “Configuring the Switch Management CPU” on page 8-2. • “Console Port Access Commands” on page 8-8.
Page 418: Configuring The Switch Management Cpu
To manage the switch via the web GUI or telnet, an IP address needs to be assigned to the switch management CPU. Whereas there are CLI commands that can be used to do this, ezconfig simplifies the task. The tool is applicable to all NETGEAR 7000-series managed switches, and allows you to configure the following parameters: 1.
Page 419 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 The following is an example of an ezconfig session. NETGEAR EZ Configuration Utility -------------------------------- Hello and Welcome! This utility will walk you thru assigning the IP address for the switch management CPU. It will allow you to save the changes at the end. After the session, simply use the newly assigned IP address to access the Web GUI using any public domain Web browser.
Page 420: Network Interface Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 There are changes detected, do you wish to save the changes permanently (Y/N)? The configuration changes have been saved succesfully. Please enter 'show running-config' to see the final configuration. Thanks for using EzConfig! Network Interface Commands This section describes the commands you use to configure a logical interface for management access.
Page 421: Network Protocol
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 network protocol This command specifies the network configuration protocol to be used. If you modify this value, change is effective immediately. If you use the bootp parameter, the switch periodically sends requests to a BootP server until a response is received.
Page 422: Network Javamode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no network mac-type This command resets the value of MAC address to its default. Format no network mac-type Mode Privileged EXEC network javamode This command specifies whether or not the switch should allow access to the Java applet in the header frame of the Web interface.
Page 423 Locally Administered address. The factory default is to use the burned in MAC address. The following shows example CLI display output for the network port. (Netgear Switch) #show network Interface Status....... Always Up IP Address........10.250.3.1 Subnet Mask........
Page 424: Console Port Access Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Management VLAN ID......1 Web Mode........Enable Java Mode........Enable Console Port Access Commands This section describes the commands you use to configure the console port. You can use a serial cable to connect a management host directly to the console port of the switch.
Page 425: Serial Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no serial baudrate This command sets the communication rate of the terminal interface. Format no serial baudrate Mode Line Config serial timeout This command specifies the maximum connect time (in minutes) without console activity. A value of 0 indicates that a console can be connected indefinitely.
Page 426: Enable Authentication
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 enable authentication To specify authentication method list when the user accesses a higher privilege level in remote telnet or console, use the command in line configuration mode.. enable authentication Format enable authentication {default | list-name} Mode Line Config no enable authentication...
Page 427: Telnet Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Telnet Commands This section describes the commands you use to configure and view Telnet settings. You can use Telnet to manage the device from a remote management host. ip telnet server enable Use this command to enable Telnet connections to the system and to enable the Telnet Server Admin Mode.
Page 428: Transport Input Telnet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 transport input telnet This command regulates new Telnet sessions. If enabled, new Telnet sessions can be established until there are no more sessions available. An established session remains active until the session is ended or an abnormal network error ends the session.
Page 429 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no transport output telnet Use this command to prevent new outbound Telnet connection from being established. Format no transport output telnet Mode Line Config session-limit This command specifies the maximum number of simultaneous outbound Telnet sessions. A value of 0 indicates that no outbound Telnet session can be established.
Page 430: Telnetcon Maxsessions
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no session-timeout This command sets the Telnet session timeout value to the default. The timeout value unit of time is minutes. Format no session-timeout Mode Line Config telnetcon maxsessions This command specifies the maximum number of Telnet connection sessions that can be established.
Page 431: Show Telnet
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no telnetcon timeout This command sets the Telnet connection session timeout value to the default. Note: Changing the timeout value for active sessions does not become effective until the session is reaccessed. Also, any keystroke activates the new timeout duration. Format no telnetcon timeout Mode...
Page 432: Secure Shell (Ssh) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show telnetcon This command displays the current inbound Telnet settings. In other words, these settings apply to Telnet connections initiated from a remote system to the switch. Format show telnetcon Modes •...
Page 433: Ip Ssh Protocol
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format ip ssh Mode Privileged EXEC ip ssh protocol This command is used to set or remove protocol levels (or versions) for SSH. Either SSH1 (1), SSH2 (2), or both SSH 1 and SSH 2 (1 and 2) can be set. Default 1 and 2 Format...
Page 434: Sshcon Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no sshcon maxsessions This command sets the maximum number of allowed SSH connection sessions to the default value. Format no sshcon maxsessions Mode Privileged EXEC sshcon timeout This command sets the SSH connection session timeout value, in minutes. A session is active as long as the session has been idle for the value set.
Page 435: Management Security Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Administrative This field indicates whether the administrative mode of SSH is enabled or disabled. Mode Protocol Level The protocol level may have the values of version 1, version 2 or both versions 1 and version 2.
Page 436: Hypertext Transfer Protocol (Http) Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 crypto key generate rsa Use this command to generate an RSA key pair for SSH. The new key files will overwrite any existing generated or downloaded RSA key files. Format crypto key generate rsa Mode Global Config no crypto key generate rsa...
Page 437: Ip Http Server
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip http server This command enables access to the switch through the Web interface. When access is enabled, the user can login to the switch from the Web interface. When access is disabled, the user cannot login to the switch's Web server.
Page 438: Ip Http Java
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip http java This command enables the Web Java mode. The Java mode applies to both secure and un-secure Web connections. Default Enabled Format ip http java Mode Privileged EXEC no ip http java This command disables the Web Java mode.
Page 439: Ip Http Authentication
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip http authentication This command specifies the authentication methods for http server users. The additional methods of authentication are used only if the previous method returns an error, not if it fails. To ensure that the authentication succeeds even if all methods return an error, specify none as the final method in the command line.
Page 440: Ip Http Session Soft-Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip http session maxsessions This command restores the number of allowable un-secure HTTP sessions to the default value. Format no ip http session maxsessions Mode Privileged EXEC ip http session soft-timeout This command configures the soft timeout for un-secure HTTP sessions in minutes.
Page 441: Ip Http Secure-Session Soft-Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip http secure-session maxsessions This command restores the number of allowable secure HTTP sessions to the default value. Format no ip http secure-session maxsessions Mode Privileged EXEC ip http secure-session soft-timeout This command configures the soft timeout for secure HTTP sessions in minutes.
Page 442: Ip Https Authentication
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no ip http secure-session hard-timeout This command resets the hard timeout for secure HTTP sessions to the default value. Format no ip http secure-session hard-timeout Mode Privileged EXEC ip https authentication This command specifies the authentication methods for http server users.
Page 443: Show Ip Http
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format ip http secure-port <portid> Mode Privileged EXEC no ip http secure-port This command is used to reset the SSL port to the default value. Format no ip http secure-port Mode Privileged EXEC ip http secure-protocol This command is used to set protocol levels (versions).
Page 444: Access Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Secure Protocol Level(s) The protocol level may have the values of SSL3, TSL1, or both SSL3 and TSL1. Maximum Allowable HTTPS The number of allowable secure http sessions. Sessions HTTPS Session Hard Timeout The hard timeout for secure http sessions in hours.
Page 445: User Account Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition User Name The name the user entered to log on to the system. Connection IP address of the remote client machine or EIA-232 for the serial port connection. From Idle Time Time this session has been idle.
Page 446: Username Nopassword
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no usermane This command removes a user account. Format no username <username> Mode Global Config Note: You cannot delete the “admin” user account. username nopassword This command removes the password from a user. Format username <name>...
Page 447: Username Snmpv3 Authentication
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format username snmpv3 accessmode <username> {readonly | readwrite} Mode Global Config no username snmpv3 accessmode This command sets the snmpv3 access privileges for the specified user as readwrite for the “admin” user and readonly for all other users. The <username> value is the user name for which the specified access mode will apply.
Page 448: Username Snmpv3 Encryption
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 username snmpv3 encryption This command specifies the encryption protocol used for the specified user. The valid encryption protocols are des or none. If you select des, you can specify the required key on the command line. The encryption key must be 8 to 64 characters long.
Page 449: Show Users Accounts
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Access Mode Shows whether the user is able to change parameters on the switch (Read/Write) or is only able to view them (Read Only). As a factory default, the “admin” user has Read/Write access and the “guest”...
Page 450: Show Users Login-History
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition User Name The full name of the user. show users login-history This command is used to display the users who have logged in previously. Format show users login-history [{user name}] Mode Privileged EXEC Term...
Page 451: Passwords History
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 passwords history Use this command to set the number of previous passwords that shall be stored for each user account. When a local user changes his or her password, the user will not be able to reuse any password stored in password history.
Page 452: Passwords Lock-Out
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 passwords lock-out Use this command to strengthen the security of the switch by locking user accounts that have failed login due to wrong passwords. When a lockout count is configured, a user that is logged in must enter the correct password within that count.
Page 453 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 aaa authentication login This command is used to set authentication at login. The default and optional list names that you create with the command are used with the aaa authentication login login command.
Page 454 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no aaa authenticaton login This command is used to remove authentication at login. . Format no aaa authentication login {default | list-name} Mode Global Config aaa authenticaton enable This command is used to set authentication when the user access higher privilege level, use the command in global configuration mode.
Page 455: Aaa Authentication Dot1X
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Keyword Description line Uses the line password for authentication. none Uses no authentication. radius Uses the list of all RADIUS servers for authentication. Uses username "$enabx$."where x is the privilege level. tacacs Uses the list of all TACACS servers for authentication.
Page 456: Snmp Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 method1 [method2…] At least one from the following table: Keyword Description local Uses the local username database for authentication. none Uses no authentication. radius Uses the list of all RADIUS servers for authentication. no aaa authentication dot1x This command is used to remove the authentication at login.
Page 457: Snmp-Server Community
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 snmp-server This command sets the name and the physical location of the switch, and the organization responsible for the network. The range for <name>, <loc> and <con> is from 1 to 31 alphanumeric characters.
Page 458: Snmp-Server Community Ipaddr
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 snmp-server community ipaddr This command sets a client IP address for an SNMP community. The address is the associated community SNMP packet sending address and is used along with the client IP mask value to denote a range of IP addresses from which SNMP clients may use that community to access the device.
Page 459: Snmp-Server Community Mode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no snmp-server community ipmask This command sets a client IP mask for an SNMP community to 0.0.0.0. The name is the applicable community name. The community name may be up to 16 alphanumeric characters. Format no snmp-server community ipmask <name>...
Page 460: Snmp-Server Community Rw
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 snmp-server community rw This command restricts access to switch information. The access mode is read/write (also called private). Format snmp-server community rw <name> Mode Global Config snmp-server enable traps violation This command enables the sending of new violation traps designating when a packet with a disallowed MAC address is received on a locked port.
Page 461: Snmp-Server Enable Traps Linkmode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no snmp-server enable traps This command disables the Authentication Flag. Format no snmp-server enable traps Mode Global Config snmp-server enable traps linkmode Note: This command may not be available on all platforms. This command enables Link Up/Down traps for the entire switch.
Page 462: Snmp-Server Enable Traps Stpmode
The SNMP trap address can be set using both an IPv4 address format as well as an IPv6 global address format. The following shows an example of the CLI command. (Netgear Switch)# snmptrap mytrap ip6addr 3099::2 Management Commands 8-46...
Page 463: Snmptrap Snmpversion
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: The <name> parameter does not need to be unique, however; the <name> and <ipaddr> pair must be unique. Multiple entries can exist with the same <name>, as long as they are associated with a different <ipaddr>. The reverse scenario is also acceptable.
Page 464: Snmptrap Ipaddr
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 snmptrap ipaddr This command assigns an IP address to a specified community name. The maximum length of name is 16 case-sensitive alphanumeric characters. Note: IP addresses in the SNMP trap receiver table must be unique. If you make multiple entries using the same IP address, the first entry is retained and processed.
Page 465: Snmp Trap Link-Status All
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format snmp trap link-status Mode Interface Config no snmp trap link-status This command disables link status traps by interface. Note: This command is valid only when the Link Up/Down Flag is enabled. Format no snmp trap link-status Mode...
Page 466: Show Snmpcommunity
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show snmpcommunity This command displays SNMP community information. Six communities are supported. You can add, change, or delete communities. The switch does not have to be reset for changes to take effect.
Page 467: Show Trapflags
The IPv6 address to receive SNMP traps from this device. SNMP Version SNMPv2 Status The receiver's status (enabled or disabled). The following shows an example of the CLI command. (Netgear Switch)#show snmptrap Community Name IpAddress IPv6 Address Snmp Version Mode Mytrap 0.0.0.0...
Page 468: Radius Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition DVMRP Traps Can be enabled or disabled. The factory default is disabled. Indicates whether DVMRP traps are sent. OSPFv2 Traps Can be enabled or disabled. The factory default is disabled. Indicates whether OSPF traps are sent.
Page 469: Radius Accounting Mode
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 radius accounting mode This command is used to enable the RADIUS accounting function. Default disabled Format radius accounting mode Mode Global Config no radius accounting mode This command is used to set the RADIUS accounting function to the default value - i.e. the RADIUS accounting function is disabled.
Page 470: Radius Server Host
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no radius server attribute <4> [<ipaddr>] Mode Global Config The following shows an example of the command. (Switch) (Config) #radius server attribute 4 192.168.37.60 (Switch) (Config) #radius server attribute 4 radius server host This command configures the IP address or DNS name to use for communicating with the RADIUS server of a selected server type.
Page 471 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 when connecting to the RADIUS accounting server. If a <port> is already configured for the accounting server, the new <port> replaces the previously configured <port>. The <port> must be a value in the range 0 - 65535, with 1813 being the default. Note: To re-configure a RADIUS accounting server to use the default UDP <port>, set the <port>...
Page 472: Radius Server Key
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 (Switch) (Config) #radius server host auth 192.168.37.60 name Network1_RADIUS_Auth_Server port 1813 (Switch) (Config) #radius server host acct 192.168.37.60 name Network2_RADIUS_Auth_Server (Switch) (Config) #no radius server host acct 192.168.37.60 radius server key This command configures the key to be used in RADIUS client communication with the specified server.
Page 473: Radius Server Msgauth
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 radius server msgauth This command enables the message authenticator attribute to be used for the specified RADIUS Authenticating server. Format radius server msgauth <ipaddr|dnsname> Mode Global Config Field Description ip addr The IP address of the server.
Page 474: Radius Server Retransmit
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description ip addr The IP address of the RADIUS Authenticating server. dnsname The DNS name of the server. radius server retransmit This command configures the global parameter for the RADIUS client that specifies the number of transmissions of the messages to be made before attempting the fall back server upon unsuccessful communication with the current RADIUS authenticating server.
Page 475: Show Radius
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default Format radius server timeout <seconds> Mode Global Config Field Description retries Maximum number of transmission attempts in the range <1-30>. no radius server timeout The no version of this command sets the timeout global parameter to the default value. Format no radius server timeout Mode...
Page 476: Show Radius Servers
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Number of Retransmits The configured value of the maximum number of times a request packet is retransmitted. Time Duration The configured timeout value, in seconds, for request re-transmissions. RADIUS Accounting Mode A global parameter to indicate whether the accounting mode for all the servers is enabled or not.
Page 477 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Field Description Host Address The IP address of the host. Server Name The name of the authenticating server. Port The port used for communication with the authenticating server. Type Specifies whether this server is a primary or secondary type. Current Host Address The IP address of the currently active authenticating server.
Page 478: Show Radius Accounting
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Server Name......Default_RADIUS_Server Host Address......192.168.37.58 Secret Configured...... No Message Authenticator ....Enable Number of Retransmits....4 Time Duration......10 RADIUS Accounting Mode....Disable RADIUS Attribute 4 Mode....Enable RADIUS Attribute 4 Value ....192.168.37.60 (Switch) #show radius servers 192.168.37.58 Server Name......
Page 479: Show Radius Accounting Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Server Name The name of the accounting server. Port The port used for communication with the accounting server. Secret Configured Yes or No Boolean value indicating whether this server is configured with a secret. The following shows example CLI display output for the command.
Page 480 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition RADIUS Accounting The name of the accounting server. Server Name Server Host Address The IP address of the host. Round Trip Time The time interval, in hundredths of a second, between the most recent Accounting- Response and the Accounting-Request that matched it from this RADIUS accounting server.
Page 481: Show Radius Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 (Switch) #show radius accounting statistics name Default_RADIUS_Server RADIUS Accounting Server Name....Default_RADIUS_Server Host Address........192.168.37.200 Round Trip Time....... 0.00 Requests........0 Retransmissions....... 0 Responses........0 Malformed Responses......0 Bad Authenticators......0 Pending Requests......
Page 482 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Malformed Access The number of malformed RADIUS Access-Response packets received from this Responses server. Malformed packets include packets with an invalid length. Bad authenticators or signature attributes or unknown types are not included as malformed access responses.
Page 483: Tacacs+ Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Timeouts........0 Unknown Types......... 0 Packets Dropped....... 0 TACACS+ Commands TACACS+ provides access control for networked devices via one or more centralized servers. Similar to RADIUS, this protocol simplifies authentication by making use of a single database that can be shared by many clients on a large network.
Page 484 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 tacacs-server key Use the tacacs-server key command to set the authentication and encryption key for all TACACS+ communications between the switch and the TACACS+ daemon. The <key- string> parameter has a range of 0 - 128 characters and specifies the authentication and encryption key for all TACACS communications between the switch and the TACACS+ server.
Page 485 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no tacacs-server timeout Use the no tacacs-server timeout command to restore the default timeout value for all TACACS servers. Format no tacacs-server timeout Mode Global Config Use the key command in TACACS Configuration mode to specify the authentication and encryption key for all TACACS communications between the device and the TACACS server.
Page 486: Show Tacacs
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 priority Use the priority command in TACACS Configuration mode to specify the order in which servers are used, where 0 (zero) is the highest priority. The <priority> parameter specifies the priority for servers. The highest priority is 0 (zero), and the range is 0 - 65535. Default Format priority <priority>...
Page 487: Configuration Scripting Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Configuration Scripting Commands Configuration Scripting allows you to generate text-formatted script files representing the current configuration of a system. You can upload these configuration script files to a PC or UNIX system and edit them.
Page 488: Script Apply
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Note: To specify a blank password for a user in the configuration script, you must specify it as a space within quotes. For example, to change the password for user jane from a blank password to hello, the script entry is as follows: users passwd jane "...
Page 489: Pre-Login Banner And System Prompt Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 script show This command displays the contents of a script file, which is named <scriptname>. Format script show <scriptname> Mode Privileged EXEC Term Definition Output Format line <number>: <line contents> script validate This command validates a script file by parsing each line in the script file where <scriptname>...
Page 490: Set Prompt
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default none Format copy <Code Sample Variable><tftp://<ipaddr>/<filepath>/ <filename>><Code Sample Variable> nvram:clibanner copy nvram:clibanner <Code Sample Variable><tftp://<ipaddr>/ <filepath>/<filename>><Code Sample Variable> Mode Privileged EXEC set prompt This command changes the name of the prompt. The length of name may be up to 64 alphanumeric characters.
Page 491: Log Messages
There is no specific action that can be taken per message. When there is a problem being diagnosed, a set of these messages in the event log, along with an understanding of the system configuration and details of the problem will assist NETGEAR, Inc. in determining the root cause of such a problem.
Page 492 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-1: BSP Log Messages Component Message Cause Event(0xaaaaaaaa) Switch has restarted. Starting code... BSP initialization complete, starting 7000 series application. Table 9-2: NIM Log Messages Component Message Cause NIM: L7_ATTACH out of order for Interface creation out of order intIfNum(x) unit x slot x port x NIM: Failed to find interface at unit x slot x...
Page 493 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-3: System Log Messages Component Message Cause SYSTEM Configuration file Switch CLI.cfg size is 0 The configuration file could not be read. (zero) bytes This message may occur on a system for which no configuration has ever been saved or for which configuration has been erased.
Page 494: Utilities
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Utilities Table 9-4: Trap Mgr Log Message Component Message Cause Trap Mgr Link Up/Down: unit/slot/port An interface changed link state. Table 9-5: DHCP Filtering Log Messages Component Message Cause DHCP Filtering Unable to create r/w lock for DHCP Filtering Unable to create semaphore used for dhcp filtering configuration structure .
Page 495 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-7: RADIUS Log Messages Component Message Cause RADIUS RADIUS: Invalid data length - xxx The RADIUS Client received an invalid message from the server. RADIUS RADIUS: Failed to send the request A problem communicating with the RADIUS server.
Page 496: Management
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-8: TACACS+ Log Messages Component Message Cause TACACS+ TACACS+: authentication error, no server to TACACS+ request needed, but no servers contact are configured. TACACS+ TACACS+: connection failed to server TACACS+ request sent to server x.x.x.x but x.x.x.x no response was received.
Page 497 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-12: EmWeb Log Messages Component Message Cause EmWeb EMWEB (Telnet): Max number of Telnet A user attempted to connect via telnet when login sessions exceeded the maximum number of telnet sessions were already active.
Page 498 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-14: WEB Log Messages Component Message Cause Max clients exceeded This message is shown when the maximum allowed java client connections to the switch is exceeded. Error on send to sockfd XXXX, closing Failed to send data to the java clients connection through the socket.
Page 499 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-16: SSHD Log Messages Component Message Cause SSHD SSHD: Unknown UI event in message, Failed to dispatch the UI event to the event=XXXX appropriate SSHD function as it’s an invalid event.
Page 500: Switching
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-18: User_Manager Log Messages Component Message Cause User_Manager User Login Failed for XXXX Failed to authenticate user login. XXXX indicates the username to be authenticated. User_Manager Access level for user XXXX could not be Invalid access level specified for the user.
Page 501 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-20: IP Subnet VLANS Log Messages Component Message Cause IPsubnet vlans ERROR vlanIpSubnetSubnetValid :Invalid This occurs when an invalid pair of subnet subnet and netmask has come from the CLI IPsubnet vlans IP Subnet Vlans: failed to save configuration This message appears when save configuration of subnet vlans failed...
Page 502 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-21: Mac-based VLANs Log Messages Component Message Cause Mac based vlanMacVlanChangeCallback: Failed to This appears when a dtl fails to delete an VLANS delete an entry entry for an vlan delete notify event. Table 9-22: 802.1x Log Messages Component Message...
Page 503 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-23: IGMP Snooping Log Messages Component Message Cause IGMP Snooping Failed to set igmp mrouter mode %d for Failed to set VLAN multicast router mode interface xxx on Vlan yyy due to IGMP Snooping message queue being full IGMP Snooping snoopCnfgrInitPhase1Process: Error...
Page 504 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-25: 802.3ad Log Messages Component Message Cause 802.3ad dot3adNimEventCompletionCallback, The event sent to NIM was not completed dot3adNimEventCreateCompletionCallback: successfully DOT3AD: notification failed for event(%d), intf(%d), reason(%d) Table 9-26: FDB Log Message Component Message Cause...
Page 505 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-30: 802.1Q Log Messages Component Message Cause 802.1Q dot1qIssueCmd: Unable to send message dot1qMsgQueue is full. %d to dot1qMsgQueue for vlan %d - %d msgs in queue 802.1Q dot1qVlanCreateProcess: Attempt to create This accommodates for reserved vlan ids.
Page 506: Qos
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-33: Protocol-based VLANs Log Messages Component Message Cause Protocol Based pbVlanCnfgrInitPhase2Process: Unable to Appears when nimRegisterIntfChange fails VLANs register NIM callback to register pbVlan for link state changes. Protocol Based pbVlanCnfgrInitPhase2Process: Unable to Appears when vlanRegisterForChange fails VLANs...
Page 507: Routing/Ipv6 Routing
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-35: CoS Log Message Component Message Cause cosCnfgrInitPhase3Process: Unable to The COS component was unable to apply apply saved config -- using factory defaults the saved configuration and has initialized to the factory default settings.
Page 508 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-38: OSPFv2 Log Messages Component Message Cause OSPFv2 Best route client deregistration failed for OSPFv2 registers with the IPv4 routing table OSPF Redist manager (“RTO”) to be notified of best route changes.
Page 509 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-39: OSPFv3 Log Messages Component Message Cause OSPFv3 Warning: OSPF LSDB is 90% full (15292 OSPFv3 limits the number of Link State LSAs). Advertisements (LSAs) that can be stored in the link state database (LSDB).
Page 510 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-41: VRRP Log Messages Component Message Cause VRRP Changing priority to 255 for virtual router When the router is configured with the with VRID 1 on interface 1/0/1 address being used as the virtual router ID, the router’s priority is automatically set to the maximum value to ensure that the address owner becomes the VRRP master.
Page 511: Multicast
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Multicast Table 9-45: Cache Log Messages Component Message Cause Cache Out of memory when creating entry. When we run out of memory while creating a new cache (MFC) entry Cache Out of memory when creating cache. When we run out of memory while creating the cache itself Table 9-46: IGMP Log Messages...
Page 512 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-48: PIM-SM Log Messages Component Message Cause PIM-SM PIM-SM not initialized This message arises when trying to activate pimsm interfaces or receiving pimsm packets when pimsm component is not initialized. PIM-SM Unable to take xxx semaphore This message is logged when failed to...
Page 513: Stacking
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-49: PIM-DM Log Messages Component Message Cause PIM-DM Error creating PIM-DM pipe This message is logged when the PIM-DM Pipe (that receives control messages) creation fails. Table 9-50: DVMRP Log Messages Component Message Cause...
Page 514 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-52: System General Error Messages Component Message Cause In hapiBroadSystemMacAddress call to Failed to add an L2 address to the MAC 'bcm_l2_addr_add' - FAILED : x table. This should only happen when a hash collision occurs or the table is full.
Page 515 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-52: System General Error Messages Component Message Cause USL: A Trunk being set doesn't exist in USL Possible synchronization issue between the application, hardware, and sync layer. USL: failed to sync trunk table on unit=x Could not synchronize unit x due to a transport failure or API issue on remote unit.
Page 516: O/S Support
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-52: System General Error Messages Component Message Cause USL: failed to sync initiator table on unit=x Could not synchronize unit x due to a transport failure or API issue on remote unit. A synchronization retry will be issued USL: failed to sync terminator table on Could not synchronize unit x due to a...
Page 517 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Table 9-53: OSAPI Log Messages (continued) Component Message Cause OSAPI osapiCleanupIf: NetIPGet During the call to remove the interface from the route table, the attempt to get an ipv4 interface address from the stack failed. OSAPI osapiCleanupIf: NetMaskGet During the call to remove the interface from...
Page 518: Captive Portal Commands
Chapter 10 Captive Portal Commands The Captive Portal feature is a software implementation that blocks clients from accessing the network until user verification has been established. Verification can be configured to allow access for both guest and authenticated users. Authenticated users must be validated against a database of authorized Captive Portal users before access is granted.
Page 519: Http Port
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no enable Use this command to globally disable captive portal. Default disabled Format no enable Mode Captive Portal Configuration mode http port Use this command to configure an additional HTTP port for captive portal to monitor. The valid range is from 0 to 65535.
Page 520: Authentication Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no https port Use this command to reset the HTTPs port to the default HTTPS port 443. Format no https port Mode Captive Portal Configuration mode authentication timeout Use this command to configure the authentication timeout. If the user does not enter valid credentials within this time limit, the authentication page needs to be served again in order for the client to gain access to the network.
Page 521: Show Captive-Portal Status
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition The administrative mode is enabled or disabled. Administrative Mode The Operational status is enabled or disabled. Operational Status If the operational status is disabled. This field shows the reason why the operational is Disable Reason disabled.
Page 522: Captive Portal Configuration Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition The number of active captive portal instances. Active Captive Portals System Supported The maximum number of user can be authenticated. Users The maximum number of local user can be created. Local Supported Users The number of the authenticated users.
Page 523: Enable (Instance)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no configuration Use this command to to delete a CP configuration. The default configuration cannot be deleted. Format no configuration <1-10> Mode Captive Portal Configuration mode enable (Instance) Use this command to enable a captive portal configuration. Default enable Format...
Page 524 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no name Use this command to remove a configuration name. Format no name Mode Captive Portal Instance mode protocol Use this command to configure the protocol mode for a captive portal configuration. The default protocol is http.
Page 525: Redirect (Captive Portal)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 group Use this command to configure a group ID for this captive portal configuration. If a group number is configured, the user entry (Local or RADIUS) must be configured with the ame name and the group to authenticate to this captive portal instance.
Page 526 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no redirect Mode Captive Portal Instance mode redirect-url Use this command to configure the redirect URL for a captive portal configuration. The url is the URL for redirection which can be up to 512 characters in length. Format redirect-url url Mode...
Page 527 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default Format max-bandwidth-up <0-536870911> Mode Captive Portal Instance mode no max-bandwidth-up Use this command to reset the maximum rate to the default Format no max-bandwidth-up Mode Captive Portal Instance mode max-input-octets Use this command to configure the maximum number of octets the user is allowed to transmit.
Page 528 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 max-output-octets Use this command to configure the maximum number of octets the user is allowed to receive. After this limit has been reached the user will be disconnected. The number of octets is in bytes. 0 indicates limit not enforced Use the “no”.
Page 529 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format max-total-octets <0-4294967295> Mode Captive Portal Instance mode session-timeout (Captive Portal) Use this command to configure the session timeout for a captive portal configuration. After this limit has been reached, the user will be disconnected. Timeout is time in seconds.
Page 530: Interface (Captive Portal)
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no idle-timeout Mode Captive Portal Instance mode locale This command is not intended to be a user command. The administrator must use the WEB UI to create and customize captive portal web content. This command is primarily used by the show running-config command and process as it provides the ability to save and restore configurations using a text based format.
Page 531: Captive Portal Status Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format no interface <unit/slot/port> Mode Captive Portal Instance Config mode block Use this command to block all traffic for a captive portal configuration. The administrator can block access to a captive portal configuration. When an instance is blocked no client traffic is allowed through any interfaces associated with that captive portal configuration.
Page 532: Show Captive-Portal Configuration Interface
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show captive-portal configuration <1-10> Mode Privileged EXEC mode Term Definition CP ID The captive portal ID CP Name The captive portal instance name Operational Status The operational status is enabled or disabled. Disable Reason If the operational status is disabled, this field shows the reason.
Page 533 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition CP ID The captive portal ID. CP Name The captive portal name. Interface The interface associated with the CP ID Interface The interface description Description Operational Status The operational status is enabled or disabled. Disable Reason The reason if the operational status is disabled.
Page 534: Show Captive-Portal Configuration Status
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show captive-portal configuration status Use this command to display information about all configured captive portal configurations or about a specific captive portal configuration. The <1-10> is captive portal ID. If <1-10> is not entered, all the configurations are displayed.
Page 535: Show Captive-Portal Configuration Locales
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Example (switch)#show captive-portal configuration status CP ID CP Name Mode Protocol Verification ----- ---------- -------- -------- ------------ Enable https Guest Enable http Local Disable https Guest (switch)#show captive-portal configuration 1 status CP ID..........
Page 536: Captive Portal Client Connection Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show captive-portal trapflags Use this command to display which captive portal traps are enabled. Format show captive-portal trapflags Mode Privileged EXEC mode Example (switch)#show captive-portal trapflags Client Authentication Failure Traps.... Disable Client Connection Traps......
Page 537: Show Captive-Portal Client Statistics
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If the macaddr is specified, the following terms are displayed. Term Definition CP ID The captive portal ID associated with the client CP Name The captive portal name associated with the client Interface The interface on which the client authenticated.
Page 538: Show Captive-Portal Interface Client Status
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Client MAC The MAC address of the authenticated client address Bytes Received The number of bytes received from the client Bytes Transmitted The number of bytes transmitted to the client Packets Received The number of packets received from the client Packets The number of packets transmitted from the client...
Page 539: Show Captive-Portal Configuration Client Status
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Term Definition Verification The user verification mode Example (switch) #show captive-portal interface client status Client Client Intf Intf Description MAC Address IP Address ------ ----------------------------------- ----------------- -------------- 1/0/1 Unit: 1 Slot: 0 Port: 1 Gigabit 0002.BC00.1290 10.254.96.47 1/0/2...
Page 540: Captive Portal Interface Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 If the CP ID is specified, the following terms are displayed. Term Definition Interface The description of the interace Description Example (switch)#show captive-portal configuration client status CP ID CP Name Client MAC Address Client IP Address Interface -----...
Page 541: Captive Portal Local User Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show captive-portal interface configuration [ <1-10>] status Mode Privileged EXEC mode Term Definition CP ID The captive portal ID CP Name The captive portal name Interface The interface associated with the CP ID. Interface The description of the interface Description...
Page 542 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format user user-id password { password | encrypted enc-password } Mode Captive Portal Configuration mode no user Use this command to delete a user from the local user database. If the user has an existing session, it is disconnected.
Page 543: User Session-Timeout
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no user group Use this command to dis-associate a group and user. Format no user <1-128> group <1-10> Mode Captive Portal Configuration mode user session-timeout Use this command to set the session timeout value for a captive portal user. Use the “no” form of this command to reset the session timeout to the default.
Page 544: User Max-Bandwidth-Down
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no user idle-timeout Use this command to reset the idle timeout to the default value. Format no user <1-128> idle-timeout timeout Mode Captive Portal Configuration mode user max-bandwidth-down Use this command to configure the bandwidth at which the client can receive data from the network.
Page 545: User Max-Input-Octets
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no user max-bandwidth-up Use this command to reset the limit to the default. Format user <1-128> max-bandwidth-up Mode Captive Portal Configuration mode user max-input-octets Use this command to limit the number of octets the user is allowed to transmit. After this limit has been reached the user will be disconnected.
Page 546: User Max-Total-Octets
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 no user max-output-octets Use this command to reset the limit to the default. Default Format no user <1-128> max-output-octets Mode Captive Portal Configuration mode user max-total-octets Use this command to limit the number of bytes the user is allowed to transmit and receive. The maximum number of octets is the sum of octets transmitted and received.
Page 547 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Format show captive-portal user [ <1-128> ] Mode Privileged EXEC mode Term Definition User ID The user ID User Name The user name Session Timeout Logout once session timeout is reached (seconds). If the value is 0 then use the value configured for the captive portal.
Page 548: Captive Portal User Group Commands
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Session Idle User ID User Name Timeout Timeout Group ID Group Name ------- -------------- -------- -------- -------- ----------- user123 Default user234 Default (switch)#show captive-portal user 1 User ID........1 User Name........user123 Password Configured......
Page 549: User Group Name
ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 Default Format user group <1-10> Mode Captive Portal Configuration mode no user group Use this command to delete a user group. The default user group (1) cannot be deleted. Format user group <1-10> Mode Captive Portal Configuration mode user group name...
Page 550: Command List
Chapter 11 Command List {deny | permit} (IP ACL) ...........................6-40 {deny | permit} (IPv6) ............................6-45 {deny | permit} (MAC ACL) ..........................6-34 aaa authentication dot1x .............................8-39 aaa authentication login ............................8-37 aaa authenticaton enable .............................8-38 access-list .................................6-37 acl-trapflags ................................6-42 addport ..................................3-91 ....................................4-2 arp access-list ................................3-134 arp cachesize...
Page 551 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 bridge aging-time ..............................3-191 cablestatus ................................7-83 captive-portal client deauthenticate .......................10-23 captive-portal ................................10-1 capture wrap ................................7-62 class ....................................6-21 class-map ..................................6-10 class-map rename ..............................6-11 classofservice dot1p-mapping ..........................6-2 classofservice ip-dscp-mapping ..........................6-2 classofservice trust ..............................6-3 clear arp-cache ................................4-5 clear arp-switch ................................4-6...
Page 552 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 configuration ................................8-8 configuration (Captive Portal) ..........................10-5 conform-color .................................6-21 copy ....................................7-32 copy (pre-login banner) ............................8-73 cos-queue min-bandwidth ............................6-4 cos-queue strict ................................6-4 crypto certificate generate ..........................8-19 crypto key generate dsa ............................8-20 crypto key generate rsa ............................8-20 debug arp ..................................7-63...
Page 553 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 default-router ................................7-42 delete ....................................7-4 deleteport (Global Config) ..........................3-91 deleteport (Interface Config) ..........................3-91 description ..................................3-4 diffserv ..................................6-9 disconnect ................................8-28 dns-server .................................7-43 domain-name ................................7-46 dos-control all ...............................3-180 dos-control firstfrag ............................3-181 dos-control icmp ..............................3-183 dos-control icmpfrag ............................3-189 dos-control icmpv4...
Page 554 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 dvlan-tunnel ethertype ............................3-45 enable (Privileged EXEC access) ........................8-4 enable authentication ............................8-10 enable password ..............................7-29 enable ..................................10-1 enable (Instance) ..............................10-6 encapsulation ................................4-13 ezconfig ..................................8-2 filedescr ..................................7-5 group ..................................10-8 hardware-address ..............................7-43 hashing-mode ................................3-106 host .....................................7-44 http port...
Page 555 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip dhcp snooping limit ............................3-122 ip dhcp snooping log-invalid ...........................3-123 ip dhcp snooping trust ............................3-123 ip dhcp snooping verify mac-address ......................3-120 ip dhcp snooping vlan ............................3-119 ip domain list ................................7-56 ip domain lookup ..............................7-55 ip domain name ..............................7-56...
Page 556 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 ip ssh protocol ................................8-17 ip ssh server enable ...............................8-17 ip telnet server enable ............................8-11 ip unreachables ...............................4-26 ip verify binding ..............................3-122 ip verify source ..............................3-124 ipv6 access-list ...............................6-44 ipv6 access-list rename ............................6-45 ipv6 host ...................................7-58...
Page 557 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 lldp med transmit-tlv ............................3-169 lldp med transmit-tlv all ............................3-171 lldp notification ..............................3-160 lldp notification-interval ...........................3-161 lldp receive ................................3-158 lldp timers ................................3-158 lldp transmit ................................3-158 lldp transmit-mgmt .............................3-160 lldp transmit-tlv ..............................3-159 locale ..................................10-13 logging buffered ..............................7-18...
Page 558 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 match ip tos ................................6-16 match ip6flowlbl ..............................6-14 match protocol ................................6-17 match source-address mac ..........................6-18 match srcip ................................6-18 match srcip6 ................................6-18 match srcl4port ...............................6-18 max-bandwidth-down ............................10-9 max-bandwidth-up ..............................10-9 max-input-octets ..............................10-10 max-output-octets ..............................10-11 max-total-octets ..............................10-11 member...
Page 559 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 poe high-power ................................5-4 poe power limit ................................5-5 poe power management ............................5-5 poe priority ................................5-6 poe reset ..................................5-7 poe reset auto ................................5-7 poe traps ..................................5-9 poe usagethreshold ..............................5-8 police-simple ................................6-23 policy-map ................................6-24 policy-map rename ...............................6-25 port...
Page 560 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 radius server primary ............................8-57 radius server retransmit ............................8-58 radius server timeout ............................8-58 redirect ..................................7-21 redirect (Captive Portal) ............................10-8 redirect-url ................................10-9 reload ..................................7-31 reload (Stack) ................................2-6 routing ..................................4-8 save .....................................7-31 script apply ................................8-72 script delete ................................8-72...
Page 561 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 set igmp querier timer expiry ..........................3-149 set igmp querier version ............................3-150 set prompt .................................8-74 set slot disable ................................2-4 set slot power ................................2-5 sflow poller ................................7-86 sflow receiver .................................7-84 sflow sampler ................................7-85 show access-lists ..............................6-43 show arp...
Page 562 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show diffserv service ............................6-30 show diffserv service brief ..........................6-30 show dos-control ..............................3-190 show dot1q-tunnel ..............................3-46 show dot1x ................................3-71 show dot1x clients ..............................3-75 show dot1x users ..............................3-76 show dvlan-tunnel ..............................3-47 show eventlog ................................7-7 show forwardingdb agetime ..........................3-192...
Page 563 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show ip interface brief ............................4-16 show ip irdp ................................4-23 show ip route ................................4-16 show ip route preferences ...........................4-19 show ip route summary ............................4-18 show ip source binding ............................3-129 show ip ssh ................................8-18 show ip stats ................................4-20...
Page 564 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show mac-address-table multicast .........................3-192 show mac-address-table static .........................3-118 show mac-address-table staticfiltering ......................3-118 show mac-address-table stats ..........................3-193 show mac-addr-table ............................7-12 show mbuf total ..............................7-14 show monitor session ............................3-113 show network ................................8-6 show passwords configuration ..........................8-36 show poe ..................................5-9...
Page 565 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show sflow samplers ............................7-89 show slot ..................................2-6 show snmpcommunity ............................8-50 show snmptrap ................................8-50 show sntp ..................................7-38 show sntp client ..............................7-38 show sntp server ..............................7-39 show spanning-tree ...............................3-22 show spanning-tree brief .............................3-23 show spanning-tree interface ..........................3-24 show spanning-tree mst port detailed...
Page 566 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 show vlan port ................................3-43 show voice vlan ..............................3-49 shutdown ..................................3-5 shutdown all ................................3-6 slot ....................................2-4 snmp trap link-status ............................8-48 snmp trap link-status all ............................8-49 snmp-server ................................8-41 snmp-server community ............................8-41 snmp-server community ipaddr ........................8-42 snmp-server community ipmask ........................8-42...
Page 567 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 spanning-tree forceversion ..........................3-14 spanning-tree forward-time ..........................3-14 spanning-tree guard ..............................3-15 spanning-tree max-age ............................3-15 spanning-tree max-hops ............................3-16 spanning-tree mst ..............................3-16 spanning-tree mst instance ..........................3-18 spanning-tree mst priority ..........................3-18 spanning-tree mst vlan ............................3-19 spanning-tree port mode .............................3-20 spanning-tree port mode all ..........................3-20...
Page 568 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 switchport protected (Interface Config) ......................3-52 tacacs-server host ..............................8-67 tacacs-server key ..............................8-68 tacacs-server timeout ............................8-68 telnet ..................................8-11 telnetcon maxsessions ............................8-14 telnetcon timeout ..............................8-14 terminal length ................................7-17 timeout ..................................8-70 traceroute ..................................7-25 traceroute ipv6 ................................7-26 traffic-shape ................................6-5...
Page 569 ProSafe 7200 Managed Switches CLI Manual, Software Version 8.0.3 vlan ingressfilter ..............................3-32 vlan makestatic ...............................3-32 vlan name .................................3-33 vlan participation ..............................3-33 vlan participation all .............................3-34 vlan port acceptframe all .............................3-34 vlan port ingressfilter all .............................3-35 vlan port priority all ..............................3-50 vlan port pvid all ..............................3-35 vlan port tagging all...

This manual is also suitable for:

Gsm7252ps - prosafe 52 ports gigabit ethernet l2 managed stackable switch Prosafe gsm752ps

NETGEAR ProSafe GSM7228PS Cli Manual

Table of Contents

Chapter 1 Using the Command-Line Interface

Chapter 2 Stacking Commands

Chapter 3 Switching Commands

Chapter 4 Routing Commands

Chapter 5 Power over Ethernet (Poe) Commands

Chapter 6 Quality of Service (Qos) Commands

Chapter 7 Utility Commands

Chapter 8 Management Commands

Chapter 9 Log Messages

Chapter 10 Captive Portal Commands

Quick Links

Software Version 8.0.3

Chapters

Related Manuals for NETGEAR ProSafe GSM7228PS

Summary of Contents for NETGEAR ProSafe GSM7228PS
