CX-Process Monitor Plus System Requirements

FinsGateway
10
Use this screen to display the system status, and run/stop the Loop Control
Unit/Board.
Use this screen to display the run/stop history and Execution error history, and
to record the time at which they occurred.
As shown below, the CX-Process Monitor Plus uses the communications
driver FinsGateway (Embedded version) to communicate with the PLC (Pro-
grammable Controller) mounted to the Loop Control Unit/Board.
CX-Process Tool
Software
Hardware RS-232C port
CX-Process Monitor Plus
FinsGateway (Embedded version)
Controller Link
Support Board
Section 1-1
Ethernet board
