MCR::>
MCR::> HOS
Enter Password >
The Host SDI mode is accessed from the MMI mode by entering the HOST (HO) command
at the terminal or TTY. In this mode you can configure and maintain the entire system. For
example, LD 45 can be activated to perform loopback testing.
To exit this mode, enter @@@.
MMI mode
In the MMI mode, a terminal, or TTY, is connected to the local MMI port (P5 on the LMI Multi
I/O cable) at the LMI or at the remote MMI port (P5 on the RMI Multi I/O cable) at the RMI. The
MMI interface characteristics are based on the following switch settings:
Table 20: Default MMI characteristics (LMI and RMI SW3)
Setting
• Speed is configured using SW3 position 5:
- OFF = 9600 bps or
- ON = 2400 bps.
• Parity, character width, and stop bit are configured using SW3, position 6:
- OFF = parity-None, character width-8, stop bit-1 (N, 8, 1) or
- ON = parity-Mark, character width-7, stop bit-1 (M, 7, 1).

Host MMI interface

An RS-232 Man Machine Interface (MMI) communication port is provided for maintenance,
configuration, and diagnostics. To begin working at the MMI, type L. MCR then prompts the
user for a password that, if entered correctly, will allow the user to interface with the MCR.
Table 21: MMI commands
Remote MMI interface with a brief description of each:
Mini-Carrier Remote Fundamentals
Command Line
HOST
OFF
ON
on page 72, lists the MMI commands available at the Mini-Carrier
Prompt after logging in
To access the Host SDI mode
Enter the SDI password
Position 5
9600
2400 mark parity, 7 data bits, and 1
Host MMI interface
Description
Position 6
no parity, 8 data bits, and 1
stop bit
stop bit
