System Cpu/Real Time Impact; System Serial Data Access; Mechanical Overview - Avaya Communication Server 1000M Single Group Manual

Description
Phone Type
M2008HF
M2009
M2018
M2112
M2216
M2317
M2616
M2250
M3901
M3902
M3903
M3904
M3905

System CPU/real time impact

MCR consumes the same real time as if remote IPE cards were used in an IPE shelf at the
host site. This means the real impact is calculated as if the cards were located at the host
site.

System serial data access

Each LMI and RMI card allows a TTY-type terminal to be connected for communicating with
the MMI processor on the LMI or RMI card or the system processor in the local system through
a standard SDI interface.

Mechanical overview

The LMI and LMX packs have an information bus between the boards in a mother/
daughterboard configuration. The daughterboard is used to provide access to the second card
slot. The two circuit packs will mount with five stand-offs, using strip connectors similar to those
on the XPEC.
The RMI pack is a single-width card with the same LEDs as the LMI.
44 Mini-Carrier Remote Fundamentals
Normal Mode
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
All phases
All phases
All phases
All phases
All phases
Comments? infodev@avaya.com
ESAM
Yes
Not Supported
Not Supported
Not Supported
Yes
Not Supported
Yes
Yes
All phases
All phases
All phases
All phases
All phases
March 2013
