Installation and configuration
(9.75 m). Install this cable kit, if applicable, between the CSU and the LMI at the local site
and the RMI at the remote site as a preinstallation procedure.
Note:
Mini-Carrier Remote is not intended for direct connection to the public switched network or
other exposed plant networks. Always connect this product to such networks through a
certified (by local, regional, or national safety agency and telecommunications authority),
isolating type network terminating device (such as CSU, DSU, NT1, or NCTE) that provides
overvoltage protection.
Route twisted-pair wires for T1 carrier links from the operating company demarcation point to
the MCR equipment. Use standard cable routing procedures to prevent cable exposure to
possible damage from contact with machine and human traffic. Terminate the twisted-pair wires
with an 8-pin modular plug.

Local site installation

• Install and verify the operation of the local system, if not already installed and operating
correctly.
• Identify the line card slots and install the LMI and LMXs in the system. (The LMI and LMXs
must all be in the same IPE shelf or cabinet.)
• Install the LMI/LMX cable.
• Connect the LMI Multi-I/O cable assembly (NT5D85) to the SDI and MMI ports, and the
T1 carrier links.
Installing the LMI
The LMI can be installed when the system is powered up and running.
(default) switch settings
LMI. Verify the switch settings before installation.
Warning:
DO NOT ALTER JUMPER SETTINGS!
The jumpers at J3 determine board type and should never be removed or changed. Refer
to Figure 11: Jumper settings on MCR circuit packs.
these jumpers.
58 Mini-Carrier Remote Fundamentals
on page 61, lists the default (factory provided) switch settings on the
Comments? infodev@avaya.com
Table 12: LMI standard
on page 59 for the proper settings for
