Warning:
Following this procedure results in the loss of ESAM data.
To install or replace a daughterboard on an MCR card, follow the steps below:
1. Disable the card requiring the new daughterboard using LD32 (see xxx for
2. Remove the MCR card from the system.
3. Place the board on a work surface so that the faceplate is close to you, and
4. If metal covers are installed on the MCR board connectors or on the daughterboard
5. If replacing an existing daughterboard, hold the two opposing, outside edges of the
6. Align the new daughterboard with the connectors.
7. Push the daughterboard straight down into the connectors until the connectors snap
8. Reinstall the MCR card into the system.
9. Reconfigure the ESAM data (see xxx for procedure).
10. Return the card to service using LD 32 (see xxx for procedure).
Mini-Carrier Remote Fundamentals
procedure).
backplane connector away from you.
connector, remove and discard them.
daughterboard and lift it straight up.
Warning:
Failure to lift straight up could cause damage to the connectors.
into place.
Warning:
Once the connectors are snapped together, do not apply more force or the
components may be damaged.
