Design Guide for the Polycom SoundStructure C16, C12, C8, and SR12

Virtual Channels

the SoundStructure devices to more than one network. Multiple network con-

nections can be on the same network or on different subnets as shown in the

following figure.

The SoundStructure Ethernet interface can be configured to have either a static

IP address or can accept a dynamic IP address from a DHCP server. By default

the SoundStructure products will accept an IP address from a DHCP server.

As described in Chapter 3, a virtual channel is a representation of an individ-

ual physical input or output channel. A virtual channel may also be a stereo

pair of physical inputs or output channels. The virtual channel name that is

created when the virtual channel is defined by the A/V designer is used to

refer to that particular input or output instead of using the physical channel

number. For example, the designer would define the virtual channel "Podium

mic" that is connected, for example, to input physical channel 9 and then refer

the virtual channel as "Podium mic". Once a virtual channel is defined, it is

always used to reference that particular signal or signals.

The Virtual channel name is case-sensitive: "Podium Mic" and "PODIUM mic"

would represent two different virtual channels.
