Confirming Line Registration
Navigate to the Channels page and open the Phone Settings dialog by clicking
on the dialer control on the Channels page as shown on the left side of the fol-
lowing figure. On the phone settings page you should see a registered line icon
if the line is properly registered (see right side of the figure). See
Lines with the SoundStructure VoIP Interface
ister a line. In this example, extension 1029 has been defined and registered
successfully.
The following figure shows the two states the line registration icon may have
depending on whether the line is registered or unregistered. If your line is
unregistered, confirm the registration settings via the Web Configuration
Utility.
In this example, the dark phone icon on the phone settings page indicates that
extension 1029 has been properly registered.
The SoundStructure VoIP Interface
for information on how to reg-
Registered Line
Unregistered Line
Registering
