Name Possible Values
IP Address Dotted-decimal IP address
Netmask Dotted-decimal subnet mask
Gateway Dotted-decimal IP address
DNS 1 Dotted-decimal IP address
DNS 2 Dotted-decimal IP address
VLAN ID -1, or 0 to 4095
If you select the Manual configuration option, you must enter the information
for the following fields to properly configure the IP address of the SoundStruc-
ture VoIP Interface.
DHCP Boot Server Settings
If you are using DHCP to set the IP address of the SoundStructure VoIP Inter-
face, then the DHCP server can also supply additional settings to the
SoundStructure VoIP Interface to simplify setup and configuration. Enter the
parameters described in section
Provisioning Server Settings
If you are using a central provisioning server or temporarily setting up a
manual FTP server for a firmware update, you may enter the server informa-
tion on this page including the type of access to the provisioning server, the
Description
Enter the IP address to be used for the SoundStructure
VoIP Interface. This IP address should be unique to the
SoundStructure VoIP Interface.
Enter the subnet netmask to be used with the IP
address. Typically this is equal to 255.255.255.0.
Enter the IP address of the router that is the address the
SoundStructure VoIP Interface will go to when seeking
IP addresses outside of the local subnet.
Enter the IP address of the primary domain name
server.
Enter the IP address of the secondary domain name
server.
Set the VLAN ID to -1 to indicate no VLAN ID, or to the
value of the desired VLAN ID.
Setting the Provisioning Server
The SoundStructure VoIP Interface
Information.
