Analog Electronic Modules
12.10 2AI I 2WIRE High Speed analog electronic module
(6ES7 134-4GB51-0AB0)
Order number
6ES7 134-4GB51-0AB0
Properties
• 2 inputs for current measuring
• Current-limited sensor power supply (90 mA)
• Input ranges:
4 to 20 mA, resolution 13 bits
0 to 20 mA, resolution 13 bits
• Supports clock synchronized mode
-- Minimum possible time for the clock-synchronized DP cycle (T
-- Minimum possible conversion time of the input module (T
Terminal assignment
The following table shows the terminal assignment of the 2AI I 2WIRE High Speed
for the various terminal modules:
Table 12-41 Terminal assignment of the 2AI I 2WIRE High Speed
View
CH0
M
0+
1
5
M
0--
2 6
M
ana
3 7
A A
AUX1 (e.g. PE)
4 8
12-62
Terminal assignment
TM-E15S24-A1 and 2AI I 2WIRE High Speed
CH1
M
1+
mA
M
1--
M
ana
AUX1 (e.g. PE)
AUX1 must be
assigned to PE.
WEmin
Remarks
Channel 0: Terminals 1 to A4
Channel 1: Terminals 5 to A8
M+: Input signal "+"
M--: Input signal "--"
M : Ground (from power
ana
mA
module)
The 2-wire transducers are
powered over the
measurement leads.
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
): 2.5 ms
DPmin
): 1.1 ms
