LPOD C-/Ku-Band Outdoor Amplifier/Block Up Converter
System Connections, Installation, and Operation
ITEM
QTY
CEFD PART NO.
1
2
FP-0000677
2
1
FP/BR0078
3
2
HW-0000070
4
2
HW/3/8SPRINGNUT
5
4
HW/5/16-18X3/4B
6
4
HW/5/16-SPLIT
7
4
HW/5/16-FLT
Figure 2-5. LPOD PS-2 Single Unit Mounting Kit, KT-0000125
KT-0000125 LPOD PS-2 Single Unit Mounting Kit
DESCRIPTION
BRACKET, MOUNTING, S.S., HPOD-LPOD PS-2
BRACKET MODIFICATION POLE MOUNTING KIT
SCREW, HEX, FLG, 0.375-16 X 0.750, S.S., SERR
SPRINGNUT, 3/8-16, SHORT SPRING, S.S. (P3300)
5/16-18 X 3/4 HEX HEAD BOLT, S.S.
5/16 SPLIT LOCK WASHER
FLAT WASHER, 5/16
2–11
Revision 3
MN-LPOD
