Comtech EF Data LPOD Hardware Installation And Operation Manual page 127

LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC)
Appendix B
Note: Where Parameter Type
obsolete and should not be used for new implementations. There generally will be a different command elsewhere that encapsulates the marked
functionality.
Command
(Instruction
Parameter Type
Code and
Qualifier)
Auto Fault AFR=
Recovery
RF Power AMP=
Amplifier State
Attenuation Offset AOF=
is in the format <description>
Arguments for
Description of Arguments
Command or
(Note that all arguments are printable ASCII
Response to
Query
1 byte Command or Query.
The LPOD output will automatically be muted if one of
the following fault conditions occurs: BUC lock detect
fault, LNB current fault (see Note), LNB voltage fault
(see Note). If auto fault recovery is enabled, it will
cause the output return to its pre-fault mute condition if
all faults are cleared. If disabled, the output will remain
muted even if all faults are cleared.
Example: <1/AFR=1'cr'
>0001/AFR='cr''lf'
Note: these faults can be user defined as faults,
alarms, or masked (see MSK command for more info).
Default Value: 1
1 byte Command or Query.
Turns ON or OFF the RF power amplifiers.
0 = Off
1 = On
Example: <1/AMP=1'cr'
>0001/AMP='cr''lf'
Note: turning the amplifier off will disable the +10V
supply, and mask it during fault checking.
Default Value: 0
5 bytes Command or Query.
Valid attenuation level (00.00 to 20.00), in dB, in 0.25 dB
steps as factory default. This value is not copied to the
offline unit in a redundant system, but will be added to
the attenuation value upon a switchover. This provides a
unit specific fine-tune to maintain power levels
appropriately in a redundant system.
Example: <1/AOF=12.25'cr'
>0001/AOF='cr''lf'
Default Value: 00.00
E
, while the underlying command will remain, the specific functionality will be
characters)
B–9
Query
Response to
(Instruction
Command
Code and
(Target to Controller)
qualifier)
AFR= AFR?
AFR?
AFR*
AMP= AMP?
AMP?
AMP*
AOF= AOF?
AOF?
AOF*
Revision 3
MN-LPOD
Response to
Query
(Target to
Controller)
AFR=x
(Same format as
command
arguments.)
AMP=x
(Same format as
command
arguments)
AOF=xx.xx
(Same format as
command
arguments.)
