Comtech EF Data LPOD Hardware Installation And Operation Manual page 146

LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC)
Appendix B
Command
(Instruction
Parameter Type
Code and
Qualifier)
Retrieve Next 5 N/A
unread stored
Statistics
E
Serial Number N/A
Retrieve Utility N/A
Status
Arguments for
Description of Arguments
Command or
(Note that all arguments are printable ASCII
Response to
Query
75 bytes Query only.
Unit returns the oldest 5 Stored Statistics entries which
have not yet been read over the remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body, where:
Sub-body=
ddmmyyhhmmssaaa.abbb.bccc.cdd.ddefghhh.hiii.i
ddmmyy = day/month/year
hhmmss = hour:minute:second
aaa.a = Operating Temperature (I.E. +40.0)
bbb.b = Amp Temperature (I.E. +40.0)
ccc.c = RF Power output
dd.dd = Attenuation Setting
e = Amp On/Off
f = Mute On/Off
g = Online/Offline Status
hhh.h = LNB Current (mA)
iii.i = BUC Tuning Voltage
If there are less than 5 entries to be retrieved, the
remaining positions are padded with zeros.
If there are no new entries, the response is RNS*.
9 bytes Query only.
Used to Query the unit's 9 digit serial number in the
form of RSN=xxxxxxxxx, where: xxxxxxxxx is the unit's
9-digit serial number.
Example: <1/RSN?'cr'
>0001/RSN=072282040'cr''lf'
23 bytes, Query only.
alpha- numeric Used to Query the utility status of the unit.
Example: <1/RUS='cr'
>0001/RUS='cr'
ADR=0001'cr'
BDR=09600'cr'
REF=087'cr''lf' (see Note)
Note: REF will only appear if a reference oscillator is
installed.
characters)
RNS=
RSN=
RUS=
B–28
Query
Response to
(Instruction
Command
Code and
(Target to Controller)
qualifier)
RNS?
RSN?
RUS?
Revision 3
MN-LPOD
Response to
Query
(Target to
Controller)
RNS={CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body
(See Description
of Arguments for
details)
RSN=xxxxxxxxx
(See Description
of Arguments for
details)
RUS=x....x
(See Description
of Arguments for
details)
