LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC)
Appendix B
Command
(Instruction
Parameter Type
Code and
Qualifier)
Concise Alarm N/A
Status
Arguments for
Description of Arguments
Command or
(Note that all arguments are printable ASCII
Response to
Query
44 bytes Query only.
Used to Query the Alarm status of the unit, response is
semicolon delimited. This is the concise version of the
RAS command.
Example:
CAS=a;b;c;d;e;f;g;h;i;j;k;I;m;n;o;p;q;r;s;t;u;v;w;x;y;'cr''lf'
where: a thru z = 0, 1, 2, 3, 4, or 5
0 = FT, 1 = OK, 2 = AL, 3 = NO, 4 = YS, 5 = MS
a = +24V Power Supply
b = +24V Switch Power Supply
c = +13/18V LNB Power Supply (see Note)
d = +13.5V Power Supply
e = +10V Power Supply
f = +10V1 Amplifier Power Supply
g = +10V2 Amplifier Power Supply (see Note)
h = +7.8V Power Supply
i = +5.8V Power Supply
j = +2.5V Power Supply
k = +1.2V Power Supply
l = -5.8V Power Supply
m = Fan#1 State
n = Fan#2 State (see Note)
o = Heatsink Temp
p = Overtemp Shutdown
q = llC Status
r = Forward Power Alarm
s = Flash Checksum
t = FPGA Done
u = BUC Lock Detect (see Note)
v = External Ref Lock Detect (see Note)
w = LNB Current (see Note)
x = Redundant Switch Condition (see Note)
y = Redundant Link Status (see Note)
z = Terminal Status Change
Note: c, g, n, u, v, w, x, and y will appear if the
appropriate model/options have been selected/installed.
characters)
CAS=
B–11
Query
Response to
(Instruction
Command
Code and
(Target to Controller)
qualifier)
CAS?
Revision 3
MN-LPOD
Response to
Query
(Target to
Controller)
CAS=x....x
(See Description
of Arguments for
details)
