Table A-6. Kt-0000089 Lpod Ps-1 Ku-Band 1:1 Redundancy Kit Bom - Comtech EF Data LPOD Hardware Installation And Operation Manual
C-/ku-band outdoor amplifier/block up converter (buc)
Hide thumbs
Also See for LPOD:
- Installation and operation manual (224 pages) ,
- Installation and operation manual (250 pages)
Table of Contents
Advertisement
LPOD C-/Ku-Band Outdoor Amplifier/ Block Up Converter (BUC)
Appendix A
ITEM
QTY
CEFD PART NO.
1
4
FP-0000534
2
2
FP-0000542
3
1
FP-0000537
4
1
FP-0000548
5
1
FP-0000549
6
1
FP-0000544
7
2
FP-0000580
8
1
FP-0000645
11
2
CA/RF0097
12
1
HW/CAP-SS14
20
1
SW/WGS28V-75SB
21
1
RF/TERM-11923-5
22
1
RF-0000105
23
6
GA/WR75-R-H-C
24
12
HW/TW14.5HDBLK
30
8
HW/1/4-20X1/2FH
33
10
HW-0000070
34
10
HW/3/8SPRINGNUT
35
2
HW/4-FLT
36
2
HW/4-SPLIT
37
2
HW/4-40X1.38PH
39
28
HW/6-FLT
40
28
HW/6-SPLIT
41
4
HW/6-32X5/16P.H
42
20
HW/6-32X1/2SHCS
43
4
03P1111
44
2
HW/8-32X1/2SHCS
45
4
HW/8-FLT
46
2
HW/8-SPLIT
47
2
HW/8-32HEXNUT
Table A-6. KT-0000089 LPOD PS-1 Ku-Band 1:1 Redundancy Kit BOM
KT-0000089 LPOD PS-1 Ku-Band 1:1 Redundancy Kit (as per Figure A-6)
DESCRIPTION
BRACKET, MOUNTING, LPOD PS-1
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS-1
BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS-1
WAVEGUIDE, Ku, WR-75, GRVD FLGS, E TO H TO FLEX, LH, 1:1, PS-1
WAVEGUIDE, Ku, WR-75, GRVD FLGS, E TO H TO FLEX, RH, 1:1, PS-1
BRACKET, MOUNTING, CABLE, MOLDED JUNCTION
SPACER PLATE, RF SPLITTER / COMBINER
BRACKET, SUPPORT, 1:1 RED., LPOD PS-1
CABLE ASSY, ROHS CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,S.S,W/CHAIN & RING
WAVEGUIDE, WR75, +28VDC, SEALED//SIDE & BOT MNT
RF TERMINATION, WR75G, 14-14.5GHz, 1.05:1 VSWR, 150W
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
GASKET, O RING, WR-75, HALF THICKNESS, CONDUCTIVE
CABLE TIE, 14.5", HEAVY DUTY, BLACK
SCREW, 1/4-20 X 1/2 FH PHIL, 82, UCUT, S.S
SCREW, HEX, FLG, 0.375-16 X 0.750, S.S, SERR
SPRINGNUT, 3/8-16, SHORT SPRING, S.S (P3300)
#4 FLAT WASHER S.S.
#4 SPLIT LOCK WASHER S.S.
#4-40 X 1/38 P.H. PHIL SCREW S.S
#6 FLAT WASHER S.S.
#6 SPLIT LOCK WASHER S.S.
#6-32 X 5/16 PHILLIPS SCREW
#6-32X1/2 SOCKET HD CAP SCREW S.S
SCREW, 6-32x9/16, SOCKET HD S.S
#8-32 X 1/2 SOCKET HEAD CAP SCREW S.S.
#8 FLAT WASHER S.S.
#8 SPLIT LOCK WASHER S.S.
#8-32 HEX NUT S.S.
A–18
Revision 3
MN-LPOD
