LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC)
Appendix B
Command
(Instruction
Parameter Type
Code and
Qualifier)
Set RTC Time TIM=
Temperature N/A
Retrieve Number N/A
of unread
E
Stored Alarms
Retrieve Number N/A
of unread Stored
Events
Terminal Status N/A
Change
Arguments for
Description of Arguments
Command or
(Note that all arguments are printable ASCII
Response to
Query
6 bytes Command or Query.
A command in the form hhmmss, indicating the time
from midnight, where hh = hours, between 00 and 23;
mm = minutes, between 00 and 59, and ss = seconds,
between 00 and 59
Example (time = 23 hours, 12 minutes and 59
seconds since midnight):
<1/TIM=231259'cr'
>0001/TIM='cr''lf'
5 bytes Query only.
Returns the temperatures of the Heatsink in the form
of a sign byte followed by 4 bytes for the temperature.
Example: TMP=+26.0
2 bytes Query only.
Returns the number of stored events, which remain
unread in the alarm log. A maximum of 255 events
may be stored in the alarm log. Numbers over 99 will
be reported as 99.
Example reply: <1/TNA? 'cr'
>0001/TNA=14'cr''lf'
2 bytes, numerical Query Only.
Returns the number of Stored Events, which remain
unread, in the form xx.
Example: <1/TNE? 'cr'
>0001/TNE=18'cr''lf'
1 byte Query only.
Indicates if there has been a change in the
configuration since the last time the command was
given. A value of 0 indicates no status change, and a
value of 1 indicates there has been a status change. A
status change is defined as any time a parameter is
changed. Such as when command is successfully
executed that changes a value. A status change also
results when there is a redundant switchover, or a fault
condition. A query does not set the status change flag.
The status change flag is cleared after being read.
Example: <1/TSC?'cr'
>0001/TSC=0'cr''lf'
characters)
TIM =
TIM?
TIM *
TMP=
TNA=
TNE=
TSC=
B–31
Query
Response to
(Instruction
Command
Code and
(Target to Controller)
qualifier)
TIM?
TMP?
TNA?
TNE?
TSC?
Revision 3
MN-LPOD
Response to
Query
(Target to
Controller)
TIM=xxxxxx
(Same format as
command
arguments)
TMP=sxxx
(See Description
of Arguments for
details)
TNA=xx
(See Description
of Arguments for
details)
TNE=xx
(same format as
command
arguments)
TSC=x
(See Description
of Arguments for
details)
